Seat Cushion replacement parts for 2019 Yamaha SX240 High Output

OEM Parts Yamaha 2019 Yamaha SX240 High Output Seat Cushion

SEAT CUSHION Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BACKREST, FRONT, PORT Part #: F3F-U35B1-90-00 Required per assembly: 1 $781.01 - + Add to cart
2	WASHER, FENDER Part #: 90209-14SA3-00 Required per assembly: 1 ~~$6.11~~ $1.29 - + Add to cart
3	WASHER, 1/4", LOCK Part #: 90204-14S00-00 Required per assembly: 1 ~~$6.11~~ $1.13 - + Add to cart
4	NUT, 1/4-20 Part #: 90170-14S00-00 Required per assembly: 1 ~~$5.08~~ $0.60 - + Add to cart
5	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 1 ~~$8.15~~ $3.84 - + Add to cart
6	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 1 ~~$6.11~~ $1.13 - + Add to cart
7	BACKREST, FRONT, STBD Part #: F3F-U35B2-90-00 Required per assembly: 1 $814.27 - + Add to cart
8	BACK REST 3 Part #: F3F-U3796-90-00 Required per assembly: 1 $932.21 - + Add to cart
9	BACK, REST, 4 Part #: F3F-U3798-90-00 Required per assembly: 1 Not Available
10	CUSHION, FORE, 1 Part #: F3F-U35A1-90-00 Required per assembly: 1 $921.62 - + Add to cart
11	BRACKET, SEAT Part #: F3F-U3714-21-00 Required per assembly: 4 ~~$32.63~~ $25.67 - + Add to cart
12	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 16 ~~$4.99~~ $0.56 - + Add to cart
13	WASHER, LOCK, (#10) Part #: 90204-10S00-00 Required per assembly: 16 ~~$7.12~~ $2.57 - + Add to cart
14	NUT Part #: 90170-10S00-00 Required per assembly: 16 ~~$6.11~~ $1.51 - + Add to cart
15	SCREW, COUNTERSUNK Part #: 90151-10S16-00 Required per assembly: 16 ~~$6.11~~ $1.36 - + Add to cart
16	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 16 ~~$4.99~~ $0.56 - + Add to cart
17	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 16 ~~$5.08~~ $1.06 - + Add to cart
18	BRACKET, SEAT Part #: F3F-U3714-31-00 Required per assembly: 4 ~~$26.51~~ $20.40 - + Add to cart
19	CUSHION, SEAT, FRONT, RIGHT Part #: F3F-U35A2-90-00 Required per assembly: 1 $1,473.50 - + Add to cart
20	CUSHION, FORE, 5 Part #: F3F-U35A5-90-00 Required per assembly: 1 $485.51 - + Add to cart
21	CUSHION, FORE, 6 Part #: F3F-U35A6-90-00 Required per assembly: 1 $455.27 - + Add to cart
22	BACK REST 1 Part #: F3F-U3791-90-00 Required per assembly: 1 $1,133.30 - + Add to cart
23	CUSHION 1 Part #: F3F-U371D-M0-00 Required per assembly: 1 ~~$678.28~~ $674.44 - + Add to cart
24	BACKREST 2 Part #: F3F-U3795-90-00 Required per assembly: 1 $1,057.70 - + Add to cart
25	CUSHION 2 Part #: F3F-U371E-M0-00 Required per assembly: 1 $1,527.94 - + Add to cart
26	BACKREST 1 Part #: F3F-U3766-90-00 Required per assembly: 1 $877.78 - + Add to cart
27	CUSHION, SEAT, REAR Part #: F3F-U3724-90-00 Required per assembly: 1 $321.80 - + Add to cart
28	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 3 ~~$0.71~~ $0.60 - + Add to cart
29	PAD 1 Part #: F3F-U36A1-90-00 Required per assembly: 1 $859.63 - + Add to cart
30	PAD 2 Part #: F3F-U36A2-90-00 Required per assembly: 1 $293.42 - + Add to cart
31	PAD 1 Part #: F3F-U521C-90-00 Required per assembly: 1 ~~$1,012.87~~ $956.79 - + Add to cart
32	PAD 2 Part #: F3F-U521D-90-00 Required per assembly: 1 ~~$1,202.48~~ $1,134.16 - + Add to cart
33	HINGE 3 Part #: F3F-U2829-00-00 Required per assembly: 2 ~~$21.41~~ $16.62 - + Add to cart
34	LATCH Part #: F3F-U5532-00-00 Required per assembly: 2 ~~$18.35~~ $14.35 - + Add to cart
35	SCREW, #10, X, 3/4&QUO Part #: 90169-10SA1-00 Required per assembly: 16 ~~$6.11~~ $1.44 - + Add to cart
36	TAPPING SCREW Part #: 90169-08SA5-00 Required per assembly: 4 ~~$6.11~~ $2.42 - + Add to cart
37	CUSHION, 3 Part #: F3F-U372D-90-00 Required per assembly: 1 $490.05 - + Add to cart
38	CUSHION 4 Part #: F3F-U372E-90-00 Required per assembly: 1 $490.05 - + Add to cart
39	CUSHION 5 Part #: F3F-U372F-40-00 Required per assembly: 2 ~~$1,102.92~~ $1,043.65 - + Add to cart
40	PAD 1 Part #: F3F-U592C-G0-00 Required per assembly: 1 ~~$311.08~~ $299.54 - + Add to cart
41	PAD 1 Part #: F3F-U592C-H0-00 Required per assembly: 1 ~~$311.08~~ $299.54 - + Add to cart
