Frame replacement parts for 2019 Yamaha Snoscoot ES

OEM Parts Yamaha 2019 Yamaha Snoscoot ES Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 8ML-F1910-00-00 Required per assembly: 1 $2,121.80 - + Add to cart
2	BULKHEAD Part #: 8ML-F191A-00-00 Required per assembly: 1 Not Available
3	RIVET, 5 Part #: 8JP-RA514-00-00 Required per assembly: 1 $0.45 $0.32 - + Add to cart
4	BRACKET, MAIN, TRACK, 1 Part #: 8ML-F1943-00-00 Required per assembly: 1 $66.98 $53.24 - + Add to cart
5	BRACKET, MAIN, TRACK, 2 Part #: 8ML-F1953-00-00 Required per assembly: 1 $66.98 $53.24 - + Add to cart
6	REINEFORCEMENT, FR Part #: 8ML-F1921-00-00 Required per assembly: 1 $38.99 $33.61 - + Add to cart
7	SCREW, SELF, TAP-HWH, 1 Part #: 8JM-RA202-00-00 Required per assembly: 4 Not Available
8	FRAME, FRONT, END Part #: 8ML-F191D-00-00 Required per assembly: 1 $36.99 $25.95 - + Add to cart
9	REINFORCEMENT, FRAME, 1 Part #: 8ML-F1986-00-00 Required per assembly: 2 $62.99 $54.49 - + Add to cart
10	BRACKET, SUPPORT Part #: 8ML-F5921-00-00 Required per assembly: 2 $9.99 $8.23 - + Add to cart
11	RIVET, 1 Part #: 8ML-RA510-00-00 Required per assembly: 16 Note: Sold in multiples of 12 only $2.04 $1.71 - + Add to cart
12	PLATE 1 Part #: 8ML-F191B-00-00 Required per assembly: 1 $61.99 $54.19 - + Add to cart
13	PLATE 2 Part #: 8ML-F191C-00-00 Required per assembly: 1 $61.99 $54.19 - + Add to cart
14	PLATE 1 Part #: 8MV-F191B-00-00 Required per assembly: 2 $21.98 $18.11 - + Add to cart
15	NUT, HEXAGON, M8 Part #: 8JP-RA331-00-00 Required per assembly: 4 Not Available
16	BUMPER, REAR, 4 Part #: 8ML-K7544-00-00 Required per assembly: 1 $21.98 $18.11 - + Add to cart
17	BUMPER, REAR, 3 Part #: 8ML-K7543-00-00 Required per assembly: 1 $21.98 $18.11 - + Add to cart
18	RIVET, 6 Part #: 8JP-RA515-00-00 Required per assembly: 20 $0.45 $0.32 - + Add to cart
19	RIVET, 3 Part #: 8ML-RA512-00-00 Required per assembly: 51 Note: Sold in multiples of 26 only $2.04 $1.71 - + Add to cart
20	PLATE, COVER Part #: 8ML-F131D-00-00 Required per assembly: 1 $67.11 - + Add to cart
21	RIVET, 4 Part #: 8ML-RA513-00-00 Required per assembly: 34 Note: Sold in multiples of 34 only $1.85 $1.54 - + Add to cart
22	BRACKET Part #: 8ML-E4744-00-00 Required per assembly: 2 $3.75 $3.11 - + Add to cart
23	RIVET, 9 Part #: 8JP-RA518-00-00 Required per assembly: 10 $0.40 $0.30 - + Add to cart
24	PROTECTOR, FUEL, TANK Part #: 8ML-F4141-00-00 Required per assembly: 1 $8.49 $6.88 - + Add to cart
25	BUMPER, FRONT, 1-BLUE Part #: 8MV-K7511-10-00 Required per assembly: 1 $80.98 $61.72 - + Add to cart
25	BUMPER, FRONT, 1 Part #: 8MV-K7511-20-00 Required per assembly: 1 $65.98 $59.50 - + Add to cart
26	TIE, CABLE-8.5/7.5/7.4 Part #: 8JM-RAB01-00-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
27	CABLE, TIE, PUSH, MOUNT Part #: 8JM-RAB02-00-00 Required per assembly: 1 $1.70 $1.21 - + Add to cart
28	RECTIFIER & REGULATOR ASSEMBLY Part #: 8ML-H1960-00-00 Required per assembly: 1 $124.98 $109.18 - + Add to cart
29	VOLTAGE REGULATOR ASSEMBLY Part #: 8ML-H1910-00-00 Required per assembly: 1 $153.99 $117.33 - + Add to cart
30	FOOTREST 2 Part #: 8ML-F7421-00-00 Required per assembly: 1 $44.99 $39.22 - + Add to cart
31	FOOTREST 1 Part #: 8ML-F7411-00-00 Required per assembly: 1 $44.99 $39.22 - + Add to cart
32	BUMPER, REAR, 1 Part #: 8ML-K7541-10-00 Required per assembly: 1 $98.98 $76.63 - + Add to cart
32	BUMPER, REAR, 1 Part #: 8ML-K7541-20-00 Required per assembly: 1 $98.98 $76.63 - + Add to cart
33	BOLT, FLANGE, 1/4-2 Part #: 8MV-RA106-00-00 Required per assembly: 2 Note: Sold in multiples of 4 only $11.49 $9.31 - + Add to cart
34	WASHER, SPRING, 5/1 Part #: 8ML-RA402-00-00 Required per assembly: 1 $1.00 $0.85 - + Add to cart
35	WASHER, LOCK-1/4, EXT Part #: 8JM-RA407-00-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
36	FLAP Part #: 8ML-K7595-00-00 Required per assembly: 1 Not Available
37	SCREW, TAPPING, 1/4 Part #: 8JP-RA202-00-00 Required per assembly: 4 $1.86 $1.24 - + Add to cart
38	NUT, SPRING Part #: 8JP-RA349-00-00 Required per assembly: 4 $1.50 $1.10 - + Add to cart
39	LABEL, WARNING, 2, (FRENCH) Part #: 8JP-K7762-S0-00 Required per assembly: 1 $3.35 $2.62 - + Add to cart
40	LABEL, WARNING, 2, (ENGLISH) Part #: 8JP-K7762-70-00 Required per assembly: 1 $3.75 $2.86 - + Add to cart
41	LABEL 1 Part #: 8JP-F151A-10-00 Required per assembly: 2 Not Available
42	NUT, HEX, FLG-NY, LOCK Part #: 8JM-RA303-00-00 Required per assembly: 4 $1.14 $0.85 - + Add to cart
43	HOLDER, ABSORBER Part #: 8MV-F376J-00-00 Required per assembly: 2 $57.99 $50.15 - + Add to cart
44	SCREW-CAP-HFH 5/16-1 Part #: 8JM-RA117-00-00 Required per assembly: 6 $2.54 $2.10 - + Add to cart
45	DRIVE GUARD ASSEMBLY Part #: 8ML-K7310-00-00 Required per assembly: 1 $58.99 $51.35 - + Add to cart
46	LABEL, CAUTION Part #: 8ML-E417F-00-00 Required per assembly: 1 $14.49 $11.70 - + Add to cart
47	LABEL, WARNING, 3 Part #: 8ML-K7763-00-00 Required per assembly: 1 $2.60 $2.15 - + Add to cart
48	AXLE, IDLER Part #: 8JM-G7465-00-00 Required per assembly: 1 $53.99 $40.36 - + Add to cart
49	WASHER, 9 Part #: 8MV-RA466-00-00 Required per assembly: 2 $3.14 $2.62 - + Add to cart
50	NUT, CLIP, M5 Part #: 8JP-RA353-00-00 Required per assembly: 2 $3.60 $2.71 - + Add to cart
51	SCREW, 11 Part #: 8JP-RA2A0-00-00 Required per assembly: 6 $2.39 $1.78 - + Add to cart
52	PROTECTOR, DISK, BR Part #: 8ML-F5718-00-00 Required per assembly: 1 Not Available
53	RIVET, 8 Part #: 8JP-RA517-00-00 Required per assembly: 3 $0.28 $0.25 - + Add to cart
54	PROTECTOR, FRAME Part #: 8ML-F1978-00-00 Required per assembly: 2 $17.98 $14.77 - + Add to cart
55	WASHER, PLAIN Part #: 8ML-RA400-10-00 Required per assembly: 6 $0.30 $0.25 - + Add to cart
56	RIVET, 5 Part #: 8ML-RA514-00-00 Required per assembly: 6 $0.31 $0.28 - + Add to cart
57	TRIM (3 FEET) Part #: 8JP-F15B3-00-00 Required per assembly: 1 Not Available
58	NUT, FLG., LOCKING Part #: 8JP-RA357-00-00 Required per assembly: 2 $0.45 $0.32 - + Add to cart
59	SCREW, M6X1.0X20 Part #: 8JP-RA261-00-00 Required per assembly: 4 $0.75 $0.59 - + Add to cart
60	NUT, FLANGE, M6-1.0 Part #: 8JM-RA322-00-00 Required per assembly: 4 $0.28 $0.25 - + Add to cart
61	WASHER, FLAT, .194X.50 Part #: 8JM-RA411-00-00 Required per assembly: 2 $0.28 $0.25 - + Add to cart
