Frame replacement parts for 2019 Yamaha WR250FK

OEM Parts Yamaha 2019 Yamaha WR250FK Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FRAME COMP. Part #: 2GC-21101-01-00 Required per assembly: 1 $3,048.36 - + Add to cart
2	BRACKET, FOOTREST Part #: 2GB-21447-00-00 Required per assembly: 1 $152.99 $129.87 - + Add to cart
3	BRACKET, FOOTREST Part #: 17D-21448-00-00 Required per assembly: 1 $41.99 $34.50 - + Add to cart
4	SCREW Part #: 90149-10033-00 Required per assembly: 4 $6.49 $5.35 - + Add to cart
5	REAR FRAME COMP. Part #: 1SL-21190-10-00 Required per assembly: 1 $541.40 - + Add to cart
6	PROTECTOR Part #: 33D-23472-00-00 Required per assembly: 2 $5.99 $4.05 - + Add to cart
7	BOLT, FLANGE Part #: 90105-08230-00 Required per assembly: 4 $4.65 $3.49 - + Add to cart
8	TENSIONER Part #: 30X-22178-00-00 Required per assembly: 1 $38.99 $30.97 - + Add to cart
9	BUSH Part #: 4V4-22184-00-00 Required per assembly: 1 $4.79 $3.49 - + Add to cart
10	WASHER, PLATE Part #: 90201-08045-00 Required per assembly: 2 $6.49 $4.52 - + Add to cart
11	COLLAR Part #: 90387-08041-00 Required per assembly: 1 $9.49 $6.41 - + Add to cart
12	BOLT, FLANGE, (4KG) Part #: 95024-08040-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
13	TENSIONER Part #: 3JD-22178-20-00 Required per assembly: 1 $47.99 $38.12 - + Add to cart
14	BEARING Part #: 93300-60839-00 Required per assembly: 1 Not Available
15	COLLAR Part #: 90387-086N4-00 Required per assembly: 1 $10.49 $9.19 - + Add to cart
16	BOLT, FLANGE Part #: 90105-08133-00 Required per assembly: 1 $5.49 $4.28 - + Add to cart
17	NUT, U Part #: 95617-08100-00 Required per assembly: 1 $10.49 $6.67 - + Add to cart
18	WASHER, PLATE Part #: 90201-08043-00 Required per assembly: 1 $8.49 $5.67 - + Add to cart
19	BRACKET, BATTERY, B Part #: 2GB-21149-00-00 Required per assembly: 1 $8.49 $6.92 - + Add to cart
20	RIVET, BLIND Part #: 90267-32146-00 Required per assembly: 2 $8.49 $5.50 - + Add to cart
21	BOLT, FLANGE Part #: 90105-10176-00 Required per assembly: 1 $13.49 $9.42 - + Add to cart
22	NUT, FLANGE, (3BM) Part #: 95704-10500-00 Required per assembly: 1 $4.29 $3.26 - + Add to cart
23	WASHER, PLATE Part #: 90201-10045-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
24	BRACKET, FRONT, LOWER Part #: 2GB-21417-10-00 Required per assembly: 2 $23.98 $19.54 - + Add to cart
25	BRACKET, FRONT, LOWER, 2 Part #: 2GB-21418-10-00 Required per assembly: 2 $16.48 $13.90 - + Add to cart
26	BOLT, FLANGE Part #: 90105-08143-00 Required per assembly: 4 $8.49 $5.59 - + Add to cart
27	BOLT, FLANGE Part #: 90105-10448-00 Required per assembly: 1 $19.98 $16.54 - + Add to cart
28	NUT, FLANGE, (3BM) Part #: 95704-10500-00 Required per assembly: 1 $4.29 $3.26 - + Add to cart
29	WASHER, PLATE Part #: 90201-10025-00 Required per assembly: 1 $8.49 $6.11 - + Add to cart
30	BOLT, FLANGE Part #: 90105-10189-00 Required per assembly: 2 $10.49 $8.23 - + Add to cart
31	BRACKET, REAR, UPPE Part #: 2GB-21425-00-00 Required per assembly: 1 $34.99 $24.99 - + Add to cart
32	BRACKET, REAR, UPPE Part #: 2GB-21426-00-00 Required per assembly: 1 $33.99 $28.05 - + Add to cart
33	BOLT, FLANGE Part #: 90105-08143-00 Required per assembly: 4 $8.49 $5.59 - + Add to cart
34	GUARD, ENGINE, 1 Part #: 1DX-2147A-01-00 Required per assembly: 1 $156.99 $114.72 - + Add to cart
35	BOLT, WITH, WASHER Part #: 90119-06166-00 Required per assembly: 3 $6.49 $4.72 - + Add to cart
36	DAMPER, PLATE Part #: 90520-04011-00 Required per assembly: 2 $3.14 $2.42 - + Add to cart
37	DAMPER, RUBBER, 1 Part #: 1DX-21485-01-00 Required per assembly: 1 $17.98 $14.36 - + Add to cart
38	HOLDER, CLUTCH, CAB Part #: 1SL-21163-01-00 Required per assembly: 1 $19.98 $16.41 - + Add to cart
39	BOLT, BUTTON, HEAD Part #: 92012-06010-00 Required per assembly: 1 $4.65 $2.40 - + Add to cart
40	CLAMP, WIRE, HARNES Part #: 1SM-21335-01-00 Required per assembly: 1 $24.98 $20.06 - + Add to cart
41	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-05008-00 Required per assembly: 1 $8.49 $5.10 - + Add to cart
42	HOLDER, CLUTCH, CAB Part #: 2GB-21163-00-00 Required per assembly: 1 $14.49 $11.64 - + Add to cart
43	BOLT, BUTTON, HEAD Part #: 92012-06010-00 Required per assembly: 1 $4.65 $2.40 - + Add to cart
44	CLAMP Part #: 90464-31002-00 Required per assembly: 1 $4.82 $3.99 - + Add to cart
45	COVER, SIDE, 5 Part #: 2GB-2171E-01-00 Required per assembly: 1 $25.81 $23.47 - + Add to cart
46	COLLAR (2GH) Part #: 90387-065T2-00 Required per assembly: 2 $9.49 $6.67 - + Add to cart
47	NUT, SPRING, (4ES) Part #: 90183-06069-00 Required per assembly: 1 $7.49 $5.99 - + Add to cart
48	SCREW, TAPPING Part #: 97702-60016-00 Required per assembly: 1 $2.35 $1.21 - + Add to cart
49	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06152-00 Required per assembly: 2 $9.49 $6.15 - + Add to cart
50	COVER, SIDE, 6 Part #: 2GB-2171X-00-00 Required per assembly: 1 $9.49 $8.23 - + Add to cart
51	DAMPER, LOCATING, 1 Part #: 2GB-24181-00-00 Required per assembly: 1 $25.98 $21.26 - + Add to cart
52	DAMPER, LOCATING, 2 Part #: 33D-24182-00-00 Required per assembly: 2 $17.98 $14.47 - + Add to cart
53	DAMPER, LOCATING, 3 Part #: 33D-24183-00-00 Required per assembly: 2 $14.49 $10.18 - + Add to cart
54	WRENCH, HEXAGON Part #: 5ET-28166-10-00 Required per assembly: 1 $35.99 $27.84 - + Add to cart
55	CAP Part #: 18P-2467E-00-00 Required per assembly: 1 $7.49 $6.27 - + Add to cart
56	CASE, CAP Part #: 18P-2464V-01-00 Required per assembly: 1 $5.99 $4.63 - + Add to cart
