Stand Footrest replacement parts for 2019 Yamaha Kodiak 450 4WD

OEM Parts Yamaha 2019 Yamaha Kodiak 450 4WD Stand Footrest

STAND FOOTREST Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BAR, FOOTREST, 1 Part #: BB5-F7471-00-00 Required per assembly: 2 ~~$11.49~~ $8.44 - + Add to cart
2	BAR, FOOTREST, 1 Part #: 5ND-F7471-01-00 Required per assembly: 2 ~~$15.49~~ $11.79 - + Add to cart
3	BOLT, FLANGE Part #: 95817-08012-00 Required per assembly: 4 ~~$5.49~~ $3.90 - + Add to cart
4	PEDAL, BRAKE Part #: 1CT-F7211-01-00 Required per assembly: 1 ~~$37.99~~ $26.51 - + Add to cart
5	NUT (JN5) Part #: 95317-06700-00 Required per assembly: 1 ~~$9.49~~ $6.56 - + Add to cart
6	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 1 ~~$3.50~~ $2.65 - + Add to cart
7	CIRCLIP, E-TYPE Part #: 93430-10015-00 Required per assembly: 1 ~~$9.49~~ $7.35 - + Add to cart
8	WASHER, PLATE Part #: 90201-14023-00 Required per assembly: 1 ~~$6.49~~ $5.16 - + Add to cart
9	SPRING, COMPRESSION Part #: 90501-10782-00 Required per assembly: 1 ~~$9.49~~ $6.05 - + Add to cart
10	PIN, CLEVIS Part #: 90240-06076-00 Required per assembly: 1 ~~$9.49~~ $6.05 - + Add to cart
11	WASHER, PLAIN Part #: 92990-06200-00 Required per assembly: 1 Note: Sold in multiples of 10 only ~~$1.00~~ $0.77 - + Add to cart
12	PIN, COTTER, (648) Part #: 91490-20015-00 Required per assembly: 1 ~~$2.20~~ $1.81 - + Add to cart
13	COVER 1 Part #: BB5-F7453-00-00 Required per assembly: 1 $99.67 - + Add to cart
14	COVER 2 Part #: BB5-F7463-00-00 Required per assembly: 1 $87.43 - + Add to cart
15	PLATE 1 Part #: 5ND-F7445-00-00 Required per assembly: 2 ~~$11.99~~ $8.10 - + Add to cart
16	BOLT Part #: 90109-06840-00 Required per assembly: 8 ~~$1.50~~ $1.15 - + Add to cart
17	RIVET Part #: 90269-06804-00 Required per assembly: 4 ~~$2.25~~ $1.69 - + Add to cart
18	NUT, NYLON Part #: 95707-06300-00 Required per assembly: 4 ~~$3.75~~ $3.14 - + Add to cart
19	WASHER, PLATE Part #: 90201-06078-00 Required per assembly: 4 ~~$6.49~~ $5.38 - + Add to cart
20	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06051-00 Required per assembly: 4 ~~$6.49~~ $4.25 - + Add to cart
21	CABLE, BRAKE Part #: BB5-F6361-00-00 Required per assembly: 1 ~~$36.99~~ $30.88 - + Add to cart
22	CLAMP(N30) Part #: 90464-21234-00 Required per assembly: 1 ~~$2.45~~ $2.04 - + Add to cart
23	SPRING, TENSION Part #: 90506-20010-00 Required per assembly: 1 ~~$8.49~~ $5.70 - + Add to cart
