Clutch replacement parts for 2019 Yamaha Kodiak 450 4WD

OEM Parts Yamaha 2019 Yamaha Kodiak 450 4WD Clutch

CLUTCH Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CLUTCH HOUSING COMP. Part #: 5GH-16611-10-00 Required per assembly: 1 ~~$442.99~~ $397.18 - + Add to cart
2	CLUTCH CARRIER ASSY Part #: 5GH-16620-01-00 Required per assembly: 1 ~~$334.99~~ $328.35 - + Add to cart
3	SPRING, CLUTCH, WEIGHT, 1 Part #: 5GH-16626-00-00 Required per assembly: 5 ~~$15.49~~ $11.51 - + Add to cart
4	BEARING, ONE, WAY Part #: 5GH-16664-00-00 Required per assembly: 1 ~~$161.99~~ $138.32 - + Add to cart
5	CIRCLIP Part #: 93410-46079-00 Required per assembly: 1 ~~$9.49~~ $5.32 - + Add to cart
6	BEARING, CYL.#15 Part #: 93315-21813-00 Required per assembly: 1 ~~$39.99~~ $31.80 - + Add to cart
7	CIRCLIP Part #: 93450-24062-00 Required per assembly: 1 ~~$4.09~~ $3.43 - + Add to cart
8	NUT Part #: 90179-22005-00 Required per assembly: 1 ~~$31.98~~ $22.68 - + Add to cart
9	PRIMARY SLIDING SHEAVE COMP. Part #: 5GH-17606-01-00 Required per assembly: 1 ~~$254.99~~ $225.76 - + Add to cart
10	PRIMARY SLIDING SHEAVE COMP. Part #: 5GH-17620-01-00 Required per assembly: 1 ~~$328.99~~ $296.55 - + Add to cart
11	OIL SEAL Part #: 93101-31167-00 Required per assembly: 2 ~~$19.48~~ $15.50 - + Add to cart
12	WEIGHT Part #: 5KM-17632-00-00 Required per assembly: 8 Note: (USA) ~~$16.48~~ $14.02 - + Add to cart
13	CAM Part #: 5GH-17623-00-00 Required per assembly: 1 ~~$82.98~~ $76.17 - + Add to cart
14	SLIDER Part #: 4WV-17653-00-00 Required per assembly: 4 ~~$8.49~~ $6.80 - + Add to cart
15	SPACER 1 Part #: 4WV-17654-01-00 Required per assembly: 4 ~~$7.49~~ $5.88 - + Add to cart
16	O-RING Part #: 93211-52001-00 Required per assembly: 1 ~~$34.99~~ $24.51 - + Add to cart
17	STOPPER Part #: 5GH-17639-00-00 Required per assembly: 1 ~~$30.98~~ $20.96 - + Add to cart
18	SCREW, PAN, HEAD Part #: 90157-04006-00 Required per assembly: 4 ~~$5.49~~ $4.08 - + Add to cart
19	WASHER, PLATE Part #: 90201-047R9-00 Required per assembly: 4 ~~$2.79~~ $2.34 - + Add to cart
20	COLLAR Part #: 90387-1914K-00 Required per assembly: 1 ~~$135.99~~ $114.22 - + Add to cart
21	V-BELT Part #: 5GH-17641-11-00 Required per assembly: 1 ~~$165.99~~ $144.20 - + Add to cart
22	SHEAVE, PRIMARY, FIXED Part #: 5UH-17611-00-00 Required per assembly: 1 ~~$171.99~~ $148.12 - + Add to cart
23	WASHER, PLATE Part #: 90201-190T7-00 Required per assembly: 1 ~~$9.49~~ $7.98 - + Add to cart
24	NUT Part #: 90179-16005-00 Required per assembly: 1 ~~$12.49~~ $10.87 - + Add to cart
25	SECONDARY FIXED SHEAVE COMP. Part #: 5GH-17660-10-00 Required per assembly: 1 ~~$373.99~~ $365.51 - + Add to cart
26	SECONDARY SLIDING SHEAVE Part #: BB5-17670-00-00 Required per assembly: 1 ~~$225.99~~ $202.74 - + Add to cart
27	OIL SEAL Part #: 93104-41119-00 Required per assembly: 2 ~~$18.48~~ $13.94 - + Add to cart
28	O-RING Part #: 93210-44545-00 Required per assembly: 2 ~~$14.49~~ $11.40 - + Add to cart
29	PIN, GUIDE Part #: 4CW-17664-00-00 Required per assembly: 4 ~~$8.49~~ $7.18 - + Add to cart
30	SPRING, COMPRESSION Part #: 90501-626L9-00 Required per assembly: 1 ~~$66.98~~ $53.60 - + Add to cart
31	SEAT, SECONDARY, SPRING Part #: 4WV-17684-00-00 Required per assembly: 1 ~~$62.99~~ $48.25 - + Add to cart
32	SEAT, SPRING Part #: 4WV-17644-00-00 Required per assembly: 1 ~~$32.99~~ $25.51 - + Add to cart
33	NUT, HEXAGON Part #: 90170-36279-00 Required per assembly: 1 ~~$18.48~~ $13.26 - + Add to cart
34	NUT Part #: 90179-16005-00 Required per assembly: 1 ~~$12.49~~ $10.87 - + Add to cart
