Rear Wheel 2 replacement parts for 2019 Yamaha Kodiak 700 4WD

OEM Parts Yamaha 2019 Yamaha Kodiak 700 4WD Rear Wheel 2

REAR WHEEL 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	REAR WHEEL COMP. Part #: B16-F5390-00-00 Required per assembly: 1 ~~$214.99~~ $189.83 - + Add to cart
2	TIRE (AT25X10-12 MU20**TL) Part #: 94110-12814-00 Required per assembly: 1 ~~$249.99~~ $244.49 - + Add to cart
3	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 ~~$9.49~~ $7.36 - + Add to cart
4	NUT Part #: 90179-10020-00 Required per assembly: 4 ~~$6.49~~ $5.44 - + Add to cart
5	HUB ASSY 2 Part #: B16-F510D-03-00 Required per assembly: 1 ~~$59.99~~ $53.78 - + Add to cart
6	BOLT, SERRATION Part #: 90114-10014-00 Required per assembly: 4 ~~$3.54~~ $2.69 - + Add to cart
7	REAR, KNUCKLE, ASSEMBLY, 2 Part #: 2BG-F532F-01-00 Required per assembly: 1 ~~$164.99~~ $134.72 - + Add to cart
8	BEARING Part #: 93305-00602-00 Required per assembly: 1 ~~$110.98~~ $102.45 - + Add to cart
9	CIRCLIP Part #: 99009-55500-00 Required per assembly: 1 ~~$10.49~~ $7.12 - + Add to cart
10	BUSH, SOLID(2NL) Part #: 90381-17067-00 Required per assembly: 4 ~~$13.87~~ $12.61 - + Add to cart
11	NIPPLE, GREASE(6A1) Part #: 93700-06M03-00 Required per assembly: 2 ~~$8.49~~ $8.30 - + Add to cart
12	SPACER Part #: 5KM-23448-00-00 Required per assembly: 2 ~~$18.98~~ $17.89 - + Add to cart
13	COVER, THRUST, 1 Part #: 3JN-23517-00-00 Required per assembly: 4 ~~$17.98~~ $15.88 - + Add to cart
14	BOLT, FLANGE Part #: 90105-10212-00 Required per assembly: 2 ~~$8.49~~ $5.50 - + Add to cart
15	NUT, SELF-LOCKING Part #: 90185-10012-00 Required per assembly: 2 ~~$3.60~~ $2.93 - + Add to cart
16	REAR DRIVE SHAFT ASSEMBLY Part #: B16-2531H-01-00 Required per assembly: 1 ~~$299.99~~ $294.51 - + Add to cart
17	DOUBLE OFF SET JOINT Part #: B16-2530V-01-00 Required per assembly: 1 ~~$195.99~~ $174.59 - + Add to cart
18	BALL JOINT SET Part #: 28P-2510F-10-00 Required per assembly: 1 ~~$452.99~~ $409.21 - + Add to cart
19	BOOT SET (DOUBLE OFFSET JOINT) Part #: B16-2510H-01-00 Required per assembly: 1 ~~$92.98~~ $67.12 - + Add to cart
20	BOOT SET (BALL JOINT) Part #: 28P-2510G-10-00 Required per assembly: 1 ~~$64.98~~ $52.87 - + Add to cart
21	SHAFT Part #: B16-2518E-10-00 Required per assembly: 1 ~~$95.98~~ $86.29 - + Add to cart
22	BOOT BAND (DOUBLE OFFSET JOINT Part #: B16-2511H-00-00 Required per assembly: 1 ~~$13.49~~ $9.83 - + Add to cart
23	BOOT BAND (SMALL) Part #: B16-2512G-00-00 Required per assembly: 1 ~~$9.49~~ $6.88 - + Add to cart
24	BOOT BAND (SMALL) Part #: 28P-2512G-00-00 Required per assembly: 1 ~~$17.98~~ $14.15 - + Add to cart
25	SNAP RING Part #: B16-2512J-00-00 Required per assembly: 1 ~~$4.34~~ $3.18 - + Add to cart
26	CIRCLIP Part #: 3B4-2512H-00-00 Required per assembly: 1 ~~$7.49~~ $5.03 - + Add to cart
27	CIRCLIP Part #: B16-25182-00-00 Required per assembly: 1 ~~$3.60~~ $3.05 - + Add to cart
28	BOOT BAND(DOUBLE OFFSET JOINT) Part #: 28P-2511H-00-00 Required per assembly: 1 ~~$16.48~~ $13.05 - + Add to cart
29	CLIP, SPRING Part #: 3B4-2536E-00-00 Required per assembly: 1 ~~$8.49~~ $6.31 - + Add to cart
30	NUT Part #: 90179-20016-00 Required per assembly: 1 ~~$12.99~~ $12.08 - + Add to cart
31	CAP, WHEEL Part #: 1HP-F512A-00-00 Required per assembly: 1 ~~$2.29~~ $1.69 - + Add to cart
