Fuel Tank replacement parts for 2019 Yamaha YFZ450R Special Edition

OEM Parts Yamaha 2019 Yamaha YFZ450R Special Edition Fuel Tank

FUEL TANK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL TANK COMP. Part #: 1TD-F4110-00-00 Required per assembly: 1 ~~$230.99~~ $215.23 - + Add to cart
2	CAP ASSEMBLY Part #: 5KM-24610-00-00 Required per assembly: 1 ~~$66.98~~ $55.49 - + Add to cart
3	GROMMET Part #: 90480-18016-00 Required per assembly: 2 ~~$9.49~~ $6.99 - + Add to cart
4	COLLAR Part #: 90387-066H4-00 Required per assembly: 2 ~~$9.49~~ $6.17 - + Add to cart
5	WASHER, PLATE Part #: 90201-064K6-00 Required per assembly: 2 ~~$10.49~~ $6.17 - + Add to cart
6	BOLT, BUTTON, HEAD Part #: 92012-06040-00 Required per assembly: 2 ~~$4.70~~ $3.27 - + Add to cart
7	GROMMET Part #: 90480-18290-00 Required per assembly: 1 ~~$9.49~~ $6.88 - + Add to cart
8	WASHER, PLATE Part #: 90201-064K6-00 Required per assembly: 1 ~~$10.49~~ $6.17 - + Add to cart
9	COLLAR Part #: 90387-066J1-00 Required per assembly: 1 ~~$9.49~~ $6.73 - + Add to cart
10	BOLT, FLANGE Part #: 95812-06030-00 Required per assembly: 1 ~~$2.14~~ $1.63 - + Add to cart
11	HOSE (L340) Part #: 90445-08684-00 Required per assembly: 1 ~~$5.49~~ $3.30 - + Add to cart
12	DAMPER, PLATE, 1 Part #: 1TD-F414H-00-00 Required per assembly: 1 $23.36 - + Add to cart
13	NUT, SPRING, (4ES) Part #: 90183-06069-00 Required per assembly: 2 ~~$7.49~~ $5.99 - + Add to cart
14	HOSE 1 Part #: 18P-2247A-00-00 Required per assembly: 1 ~~$14.49~~ $12.23 - + Add to cart
15	DAMPER, PLATE Part #: 90520-08001-00 Required per assembly: 2 ~~$9.49~~ $6.86 - + Add to cart
16	DAMPER, RUBBER, 1 Part #: 4RR-21485-00-00 Required per assembly: 2 ~~$7.49~~ $6.27 - + Add to cart
17	FUEL PUMP COMP. Part #: 18P-13907-12-00 Required per assembly: 1 ~~$453.99~~ $451.50 - + Add to cart
18	BRACKET, FUEL, PUMP Part #: 18P-24491-00-00 Required per assembly: 1 ~~$19.98~~ $15.39 - + Add to cart
19	O-RING Part #: 1S3-24486-00-00 Required per assembly: 1 ~~$18.98~~ $16.37 - + Add to cart
20	NUT (CROWN) Part #: 95380-06800-00 Required per assembly: 6 ~~$9.49~~ $6.61 - + Add to cart
21	CASE, CAP Part #: 18P-2464V-01-00 Required per assembly: 1 ~~$5.99~~ $4.63 - + Add to cart
22	CAP Part #: 18P-2467E-00-00 Required per assembly: 1 ~~$7.49~~ $6.27 - + Add to cart
23	PIPE, FUEL, 1 Part #: 18P-13971-00-00 Required per assembly: 1 ~~$88.98~~ $72.85 - + Add to cart
