Intake replacement parts for 2019 Yamaha YZFR3

OEM Parts Yamaha 2019 Yamaha YZFR3 Intake

INTAKE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	JOINT, CARBURETOR, 1 Part #: 2MS-E3586-00-00 Required per assembly: 1 $58.99 $56.26 - + Add to cart
2	O-RING (1FN) Part #: 93210-39700-00 Required per assembly: 2 $12.49 $9.51 - + Add to cart
3	BOLT Part #: 91332-06016-00 Required per assembly: 3 $0.28 $0.25 - + Add to cart
4	HOSE CLAMP ASSEMBLY Part #: 90450-55804-00 Required per assembly: 2 $4.15 $2.60 - + Add to cart
5	THROTTLE BODY ASSEMBLY Part #: 2MS-E3750-01-00 Required per assembly: 1 $380.99 $372.04 - + Add to cart
6	GASKET, MANIFOLD Part #: 1WD-E3556-00-00 Required per assembly: 2 $4.15 $2.60 - + Add to cart
7	INJECTOR Part #: 1WD-E3761-00-00 Required per assembly: 2 $79.98 $68.04 - + Add to cart
8	O-RING Part #: 5PS-14147-00-00 Required per assembly: 1 $13.49 $9.14 - + Add to cart
9	STEPPING MOTOR Part #: 1WS-85801-00-00 Required per assembly: 1 $173.99 $162.68 - + Add to cart
10	SPRING, PLUNGER Part #: 1WS-14335-00-00 Required per assembly: 1 $11.49 $9.36 - + Add to cart
11	SCREW, WITH, WASHER Part #: 98517-06012-00 Required per assembly: 1 $4.09 $3.08 - + Add to cart
12	BOLT 1 Part #: 1WD-E3573-00-00 Required per assembly: 2 $1.60 $1.19 - + Add to cart
13	WASHER Part #: 8GL-13571-00-00 Required per assembly: 2 $4.40 $3.30 - + Add to cart
14	COLLAR Part #: 8HG-14534-00-00 Required per assembly: 2 $34.99 $26.54 - + Add to cart
15	AIR SCREW SET Part #: 5JW-14104-00-00 Required per assembly: 2 $17.98 $14.24 - + Add to cart
16	CAP Part #: 895-14169-00-00 Required per assembly: 2 $5.99 $3.93 - + Add to cart
17	CLIP, PIPE Part #: 8A7-14139-00-00 Required per assembly: 2 $9.49 $6.67 - + Add to cart
18	O-RING Part #: 54P-E416A-00-00 Required per assembly: 1 $7.49 $6.31 - + Add to cart
19	PLATE Part #: 1WD-E4243-00-00 Required per assembly: 1 Not Available
20	PIPE Part #: 1WD-E3938-00-00 Required per assembly: 1 $71.98 $71.00 - + Add to cart
21	PIPE (2MS1) Part #: 2MS-E4465-00-00 Required per assembly: 1 Not Available
22	PIPE (2MS1) Part #: 2MS-E4466-00-00 Required per assembly: 1 $12.49 $10.46 - + Add to cart
23	WAY 3 Part #: 90413-06031-00 Required per assembly: 1 $9.49 $8.06 - + Add to cart
24	CLIP Part #: 90467-090A2-00 Required per assembly: 4 $4.75 $2.45 - + Add to cart
25	CASE, AIR, CLEANER, 1 Part #: 1WD-E4411-00-00 Required per assembly: 1 $83.63 - + Add to cart
26	FUNNEL, AIR Part #: 2MS-E4469-00-00 Required per assembly: 1 Not Available
27	FUNNEL 2 Part #: 2MS-E446C-00-00 Required per assembly: 1 Not Available
28	DUCT Part #: 1WD-E4437-00-00 Required per assembly: 1 Not Available
29	CAP, CLEANER, CASE, 1 Part #: 2MS-E4412-00-00 Required per assembly: 1 Not Available
30	SEAL Part #: 1WD-E4452-00-00 Required per assembly: 1 $3.00 $2.49 - + Add to cart
31	SEAL Part #: 1WD-E4457-00-00 Required per assembly: 1 Not Available
32	SCREW, TRUSS, TAP. Part #: 97707-50025-00 Required per assembly: 8 $9.49 $6.06 - + Add to cart
33	CAP, CLEANER, CASE, 2 Part #: 1WD-E4422-00-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
34	SEAL Part #: 1WD-E4462-00-00 Required per assembly: 1 $10.49 $9.75 - + Add to cart
35	SCREW, BIND Part #: 98902-05020-00 Required per assembly: 3 $1.85 $1.41 - + Add to cart
36	ELEMENT, AIR, CLEANER Part #: 1WD-E4451-00-00 Required per assembly: 1 $30.98 $27.22 - + Add to cart
37	PIPE, DRAIN, (MIO, AL115S) Part #: 5TL-E443E-00-00 Required per assembly: 1 $1.10 $0.67 - + Add to cart
38	CLIP Part #: 90467-110A3-00 Required per assembly: 1 $8.49 $4.16 - + Add to cart
39	BAND Part #: 54P-E3474-00-00 Required per assembly: 2 $11.49 $9.75 - + Add to cart
40	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 $5.49 $3.84 - + Add to cart
41	HOSE, AIR Part #: 1WD-E3543-01-00 Required per assembly: 1 $3.25 $2.72 - + Add to cart
42	CLIP Part #: 90467-13802-00 Required per assembly: 1 $3.10 $2.57 - + Add to cart
43	CLIP, SCISSOR Part #: 90467-12052-00 Required per assembly: 1 $10.49 $6.44 - + Add to cart
44	PIPE, BREATHER Part #: 2MS-E5373-01-00 Required per assembly: 1 $4.45 $3.67 - + Add to cart
45	CLIP Part #: 90467-13802-00 Required per assembly: 2 $3.10 $2.57 - + Add to cart
