2020 Honda CRF450RX - Alternator

ALTERNATOR Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
E 11
001

FLYWHEEL

Part #: 31110-MKE-A01 Required per assembly: 1
$473.03
$382.89
002

STATOR

Part #: 31120-MKE-AB1 Required per assembly: 1
$463.84
$375.46
003

CLAMP, WIRE

Part #: 32112-MKE-A70 Required per assembly: 1
$9.01
$7.78
004

BOLT, FLANGE, (5X14)

Part #: 90003-MEL-000 Required per assembly: 2
$2.37
$2.19
005

WASHER (12.1X24.5)

Part #: 90401-MEN-A30 Required per assembly: 1
$3.41
006

NUT, FLANGE, (12MM)

Part #: 94050-12200 Required per assembly: 1
$2.27
$2.10
007

BOLT, SOCKET, (6X25)

Part #: 96600-06025-00 Required per assembly: 3
$2.87
$2.67
