Steering Gear Box - Tie Rod replacement parts for 2020 Honda SXS1000S4

OEM Parts Honda 2020 Honda SXS1000S4 Steering Gear Box - Tie Rod

STEERING GEAR BOX - TIE ROD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 10
001	END, SET, TIE, ROD Part #: 53010-HL6-A01 Required per assembly: 2 ~~$50.34~~ $41.99 - + Add to cart
002	RACK, STEERING Part #: 53402-HL6-A41 Required per assembly: 1 ~~$110.75~~ $92.34 - + Add to cart
003	SPRING Part #: 53413-SH3-003 Required per assembly: 1 ~~$6.53~~ $6.27 - + Add to cart
004	SCREW, RACK, GUIDE Part #: 53414-679-013 Required per assembly: 1 ~~$31.33~~ $28.51 - + Add to cart
005	GUIDE, STEERING, RACK Part #: 53416-HL3-A00 Required per assembly: 1 ~~$13.75~~ $11.12 - + Add to cart
006	WASHER, DISK Part #: 53418-SC2-003 Required per assembly: 1 ~~$8.54~~ $8.05 - + Add to cart
007	PINION, STEERING Part #: 53421-HL6-A01 Required per assembly: 1 ~~$61.40~~ $51.20 - + Add to cart
009	DUST SEAL Part #: 53426-671-003 Required per assembly: 1 ~~$15.36~~ $14.69 - + Add to cart
011	BUSH, RACK, END Part #: 53430-HL6-A01 Required per assembly: 2 ~~$5.46~~ $4.96 - + Add to cart
012	BAND, A, BELLOWS Part #: 53449-HL6-A01 Required per assembly: 2 ~~$5.58~~ $5.07 - + Add to cart
013	BAND, BELLOWS Part #: 53449-S3A-J01 Required per assembly: 2 ~~$6.22~~ $5.53 - + Add to cart
015	COVER, PINION, DUST Part #: 53502-S3A-J01 Required per assembly: 1 ~~$7.55~~ $6.60 - + Add to cart
016	PIPE, TIE, ROD Part #: 53521-HL6-A01 Required per assembly: 2 ~~$42.07~~ $35.92 - + Add to cart
017	WASHER, TIE, ROD, LOCK Part #: 53536-SR3-000 Required per assembly: 2 ~~$7.31~~ $6.95 - + Add to cart
018	DUST, SEAL, TIE, ROD Part #: 53537-HL6-A01 Required per assembly: 2 ~~$16.22~~ $13.51 - + Add to cart
019	END, TIE, ROD Part #: 53540-HL6-A01 Required per assembly: 2 ~~$58.16~~ $53.94 - + Add to cart
021	BOX, STEERING, GEAR Part #: 53840-HL6-A41 Required per assembly: 1 ~~$459.54~~ $383.15 - + Add to cart
023	NUT, FLANGE, (10MM) Part #: 90002-T2A-A00 Required per assembly: 2 ~~$2.07~~ $1.91 - + Add to cart
024	BOLT, STUD, (10X21) Part #: 90107-HL6-A00 Required per assembly: 4 ~~$5.18~~ $4.71 - + Add to cart
026	NUT, HEX., (16MM), (LEFT, HAND, THREAD) Part #: 90301-HL6-A00 Required per assembly: 2 ~~$2.72~~ $2.61 - + Add to cart
027	NUT (10MM) Part #: 90305-HC0-770 Required per assembly: 4 ~~$4.30~~ $3.91 - + Add to cart
030	NUT, HEX., (16MM) Part #: 94002-16280-0S Required per assembly: 2 ~~$2.40~~ $2.22 - + Add to cart
031	PIN, SPLIT, (2.0X35) Part #: 94201-20350 Required per assembly: 2 ~~$2.07~~ $1.91 - + Add to cart
031	PIN, SPLIT, (2.0X35) Part #: 94201-20350 Required per assembly: 2 ~~$2.07~~ $1.91 - + Add to cart
031	PIN, SPLIT, (2.0X35) Part #: 94201-20350 Required per assembly: 2 ~~$2.07~~ $1.91 - + Add to cart
032	CIRCLIP (35MM) Part #: 94520-35000 Required per assembly: 1 ~~$2.92~~ $2.71 - + Add to cart
