Gearshift Drum replacement parts for 2020 Honda TRX250X

OEM Parts Honda 2020 Honda TRX250X Gearshift Drum

GEARSHIFT DRUM Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

E 19
001	FORK, FR., GEARSHIFT Part #: 24211-HN6-000 Required per assembly: 1 ~~$59.38~~ $53.96 - + Add to cart
002	FORK Part #: 24212-HN6-000 Required per assembly: 1 ~~$59.38~~ $53.96 - + Add to cart
003	SWINGARM, GEARSHIFT Part #: 24213-HN6-000 Required per assembly: 1 ~~$64.74~~ $52.38 - + Add to cart
004	SHAFT Part #: 24241-HF1-670 Required per assembly: 1 ~~$22.00~~ $20.83 - + Add to cart
005	DRUM, GEARSHIFT Part #: 24301-HN6-A00 Required per assembly: 1 ~~$92.24~~ $74.62 - + Add to cart
006	SHIFTER, DRUM Part #: 24321-HN6-A30 Required per assembly: 1 $12.07 - + Add to cart
007	PLATE, SHIFT, GUIDE Part #: 24328-HB3-000 Required per assembly: 1 $10.02 - + Add to cart
008	STOPPER Part #: 24430-HM8-A40 Required per assembly: 1 $14.26 - + Add to cart
009	SPRING Part #: 24435-HM8-A40 Required per assembly: 1 $3.91 - + Add to cart
010	SPINDLE, GEARSHIFT Part #: 24611-HM8-A40 Required per assembly: 1 ~~$55.59~~ $46.32 - + Add to cart
011	ARM Part #: 24620-HN6-A30 Required per assembly: 1 ~~$41.39~~ $34.49 - + Add to cart
012	PLATE, GEARSHIFT Part #: 24631-HM8-A40 Required per assembly: 1 $16.46 - + Add to cart
013	SPRING, SHIFT, ARM Part #: 24641-HB3-004 Required per assembly: 1 $3.93 - + Add to cart
014	SPRING Part #: 24651-HN6-A30 Required per assembly: 1 $8.19 - + Add to cart
015	PIN, RETURN, SPRING Part #: 24652-KY4-900 Required per assembly: 1 $11.02 - + Add to cart
016	ARM, A, GEARSHIFT Part #: 24661-HN5-670 Required per assembly: 1 ~~$25.97~~ $23.57 - + Add to cart
017	SPINDLE Part #: 24680-HN6-A30 Required per assembly: 1 ~~$73.30~~ $61.09 - + Add to cart
018	PLATE A Part #: 24860-HM8-A40 Required per assembly: 1 $17.52 - + Add to cart
019	LEVER Part #: 24865-HN5-670 Required per assembly: 1 $6.52 - + Add to cart
020	SPRING Part #: 24867-HN6-A30 Required per assembly: 1 $5.02 - + Add to cart
021	BOLT (6X15.2) Part #: 90009-HN5-670 Required per assembly: 1 $3.93 - + Add to cart
022	PIVOT Part #: 90022-HM8-A40 Required per assembly: 1 ~~$3.51~~ $3.39 - + Add to cart
023	NUT, U, (6MM) Part #: 90301-473-003 Required per assembly: 1 $5.94 - + Add to cart
024	WASHER Part #: 90407-HM8-A40 Required per assembly: 1 $4.03 - + Add to cart
025	WASHER Part #: 90408-HM8-A40 Required per assembly: 1 ~~$2.92~~ $2.67 - + Add to cart
026	WASHER (10X21.5) Part #: 90413-GE0-000 Required per assembly: 1 $5.73 - + Add to cart
027	WASHER, DRUM, STOPPER Part #: 90417-360-000 Required per assembly: 1 ~~$2.73~~ $2.39 - + Add to cart
028	WASHER (6MM) Part #: 90442-397-000 Required per assembly: 1 $3.85 - + Add to cart
029	WASHER (12MM) Part #: 90451-GF6-000 Required per assembly: 1 $3.05 - + Add to cart
030	WASHER (12MM) Part #: 90452-166-600 Required per assembly: 2 $3.26 - + Add to cart
031	WASHER, CRANK, ARM Part #: 90545-044-000 Required per assembly: 1 ~~$2.83~~ $2.57 - + Add to cart
032	BEARING (6807) Part #: 91008-HS0-A01 Required per assembly: 1 ~~$46.80~~ $38.25 - + Add to cart
033	CIRCLIP (12MM) Part #: 94510-12000 Required per assembly: 2 ~~$2.86~~ $2.77 - + Add to cart
034	BOLT, FLANGE, (6X20) Part #: 95701-06020-00 Required per assembly: 1 $2.65 - + Add to cart
035	ROLLER (4X13.8) Part #: 96220-40138 Required per assembly: 1 ~~$1.60~~ $0.73 - + Add to cart
