OEM Parts Polaris 2020 Polaris P2000i (R01) Engine Asm.

2020 Polaris P2000i (R01) P20GDGDNA - Engine Asm.

ENGINE ASM. Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

ASM-SPARK, ARRESTOR, 2K

Part #: 2208686 Required per assembly: 1
Currently Not Available
2

EXHAUST-2K

Part #: 3410508 Required per assembly: 1
Currently Not Available
3

ASM-STATOR, 2K

Part #: 2208678 Required per assembly: 1
Currently Not Available
4

FLYWHEEL-2K

Part #: 3410511 Required per assembly: 1
Currently Not Available
5

FAN-GENERATOR, COOLING, 2K

Part #: 3410509 Required per assembly: 1
Currently Not Available
6

ASM-DIPSTICK, W/ORING, 2K

Part #: 2208706 Required per assembly: 1
Currently Not Available
7

ASM-AIRBOX, 2K

Part #: 2208680 Required per assembly: 1
Currently Not Available
8

FILTER-AIR, 2K

Part #: 3410513 Required per assembly: 1
Currently Not Available
9

ASM-RECOIL, 2K

Part #: 2208677 Required per assembly: 1
Currently Not Available
9

HANDLE-RECOIL, 2K, 3K

Part #: 3410486 Required per assembly: 1
Currently Not Available
10

FAN-EXHAUST, COOLING, 2K

Part #: 3410510 Required per assembly: 1
Currently Not Available
11

PLUG-SPARK, 2K

Part #: 3410512 Required per assembly: 1
Currently Not Available
12

ASM-CARB, AIR, GASKET, 2K

Part #: 2208679 Required per assembly: 1
Currently Not Available
13

ASM-CARB, COMPLETE, 2K

Part #: 2208685 Required per assembly: 1 Note: WHEN ORDERING CARBURETOR, ALSO ORDER REF. 12, GASKET KIT
Currently Not Available
14

ASM-MAGNETO, 2K

Part #: 3410529 Required per assembly: 1
Currently Not Available
