Electrical (E03,E33) replacement parts for 2020 Suzuki DL1050, XT, XTA V-Strom

OEM Parts Suzuki 2020 Suzuki DL1050, XT, XTA V Strom Electrical (E03,E33)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	RELAY, ASSEMBLY, STARTING, MOTOR Part #: 31800-06G02 Required per assembly: 1 $86.90 $74.30 - + Add to cart
2	COVER Part #: 31861-47E00 Required per assembly: 1 Note: COVER, RELAY ASSY; $17.46 $14.92 - + Add to cart
3	FUSE, 30A Part #: 09481-30101 Required per assembly: 2 $2.75 $2.48 - + Add to cart
4	PROTECTOR, CONTROL, CABLE Part #: 44552-24B00 Required per assembly: 1 Note: MOLDING, REAR; $17.90 $15.29 - + Add to cart
5	SCREW Part #: 09128-06013 Required per assembly: 2 Note: BOLT, STG MOT TERM; $1.56 $1.40 - + Add to cart
6	RECTIFIER ASSEMBLY Part #: 32800-31J10 Required per assembly: 1 $159.58 $143.62 - + Add to cart
7	NUT Part #: 08319-3106A Required per assembly: 2 $2.53 $2.28 - + Add to cart
8	TAPE, FUEL, TANK Part #: 45517-16G20 Required per assembly: 1 $12.06 $10.85 - + Add to cart
9	BOLT (6X35) Part #: 09106-06088 Required per assembly: 6 $4.52 $4.07 - + Add to cart
10	BOLT, MAGNETO, STATOR Part #: 09106-06120 Required per assembly: 2 Note: 6X40 Not Available
11	NUT, LICENSE, LAMP Part #: 09159-06096 Required per assembly: 8 $3.31 $2.98 - + Add to cart
12	COIL, ASSEMBLY, IGNITION Part #: 33410-06G01 Required per assembly: 1 $126.10 $107.82 - + Add to cart
13	COIL, ASSEMBLY, IGNITION, REAR Part #: 33410-06L00 Required per assembly: 1 $103.42 $93.08 - + Add to cart
14	COIL, ASSEMBLY, IGNITION Part #: 33410-20H01 Required per assembly: 1 $99.35 $84.94 - + Add to cart
15	COIL, ASSEMBLY, IGNITION Part #: 33410-26G01 Required per assembly: 1 $129.31 $110.55 - + Add to cart
16	SHIELD, IGNITION, COIL Part #: 13412-06L00 Required per assembly: 1 $38.72 $34.85 - + Add to cart
17	SPACER (6.4X10X18) Part #: 09180-06195 Required per assembly: 4 $4.70 $4.23 - + Add to cart
18	SPACER Part #: 09180-06198 Required per assembly: 4 Note: SPACER (6.2X12X16); $4.54 $4.09 - + Add to cart
19	SPACER (6.5X9X3.8) Part #: 09180-06255 Required per assembly: 2 $2.68 $2.41 - + Add to cart
20	CLAMP, BREATHER, HOSE Part #: 09408-00235 Required per assembly: 1 $2.95 $2.66 - + Add to cart
21	CAP, ASSEMBLY, SPARK, PLUG Part #: 33510-31G00 Required per assembly: 2 $49.67 $42.47 - + Add to cart
22	CAP, ASSEMBLY, SPARK, PLUG Part #: 33510-31G10 Required per assembly: 2 $40.70 $36.63 - + Add to cart
23	SEAL, HIGH, TENSION, CORD, RR Part #: 33542-06G00 Required per assembly: 1 $8.78 $7.90 - + Add to cart
24	SEAL, HIGH, TENSION, CORD, FR Part #: 33542-06G10 Required per assembly: 1 $8.95 $8.06 - + Add to cart
25	SEAL, HIGHTENSION, CORD Part #: 33542-38B00 Required per assembly: 2 Note: SEAL, HIGH TENSION CORD; $30.87 $26.39 - + Add to cart
26	HARDWARE, FI, CONTROL, UNIT Part #: 32910-06L00 Required per assembly: 1 Note: SEE NOTE 1 $1,236.24 $1,112.62 - + Add to cart
27	SENSOR, ASSEMBLY, FUEL, CUT Part #: 33960-25H00 Required per assembly: 1 $84.77 $76.29 - + Add to cart
28	PROTECTOR Part #: 33651-37000 Required per assembly: 2 Note: CUSHION (170x95x3.0); CUT AS REQUIRED ((115x50),(20x90)) $16.19 $14.57 - + Add to cart
29	PROTECTOR (30X50X3.0) Part #: 33652-36000 Required per assembly: 1 $393.31 $336.27 - + Add to cart
