Speedometer (E03,E33) replacement parts for 2020 Suzuki VZR1800-BZ M109R

OEM Parts Suzuki 2020 Suzuki VZR1800 BZ M109R Speedometer (E03,E33)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SPEEDOMETER Part #: 34120-48GG0 Required per assembly: 1 $490.90 $441.81 - + Add to cart
2	UPPER CASE ASSEMBLY Part #: 34150-48G00 Required per assembly: 1 $133.64 $120.28 - + Add to cart
3	RUBBER, SWITCH Part #: 34124-32F00 Required per assembly: 2 Note: SW RUBBER; $6.50 $5.85 - + Add to cart
4	LOWER CASE ASSEMBLY Part #: 34111-48G40 Required per assembly: 1 $91.51 $78.23 - + Add to cart
5	REFLECTOR ASSEMBLY Part #: 34125-48G00 Required per assembly: 1 $77.24 $69.52 - + Add to cart
6	BRACKET Part #: 34950-48G00 Required per assembly: 1 Not Available
7	CLAMP Part #: 34192-48G00 Required per assembly: 1 Not Available
8	SCREW (3X12) Part #: 34183-09F00 Required per assembly: 9 $3.25 $2.93 - + Add to cart
9	SCREW (3X14) Part #: 34149-03G00 Required per assembly: 3 $4.93 $4.44 - + Add to cart
10	SCREW, SPEEDOMETER Part #: 03541-0516A Required per assembly: 4 Note: SCREW, INNER COVER; $1.70 $1.53 - + Add to cart
11	TACHOMETER ASSEMBLY Part #: 34220-48G40 Required per assembly: 1 $736.99 $630.12 - + Add to cart
12	CASE, ASSEMBLY, UPPER Part #: 34250-48G30 Required per assembly: 1 $130.57 $117.51 - + Add to cart
13	CASE, ASSEMBLY, LOWER Part #: 34211-48G30 Required per assembly: 1 $92.92 $83.63 - + Add to cart
14	CUSHION, METER, NO.2 Part #: 34955-13E01 Required per assembly: 2 Note: CUSHION, SPEEDOMETER; $3.67 $3.30 - + Add to cart
15	SCREW (4X14) Part #: 34149-17E10 Required per assembly: 1 Not Available
16	TAPPING SCREW Part #: 09132-03008 Required per assembly: 11 Note: SCREW (3X16); $1.88 $1.69 - + Add to cart
17	CLAMP Part #: 36385-24A30 Required per assembly: 1 Not Available
18	SCREW, SPEEDOMETER Part #: 03541-0516A Required per assembly: 2 Note: SCREW, INNER COVER; $1.70 $1.53 - + Add to cart
19	SENSOR, SPEED Part #: 34990-48G01 Required per assembly: 1 $171.78 $146.86 - + Add to cart
20	BOLT Part #: 07130-0616B Required per assembly: 1 $2.95 $2.66 - + Add to cart
