Jet Unit 1 replacement parts for 2020 Yamaha FX SVHO

OEM Parts Yamaha 2020 Yamaha FX SVHO Jet Unit 1

JET UNIT 1 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PLATE, TRANSOM Part #: 6ET-G5831-20-00 Required per assembly: 1 ~~$191.75~~ $148.10 - + Add to cart
2	PIN, DOWEL Part #: 99590-14016-00 Required per assembly: 2 ~~$4.59~~ $3.78 - + Add to cart
3	BOLT, WITH, WASHER Part #: 90119-10811-00 Required per assembly: 4 ~~$2.02~~ $1.51 - + Add to cart
4	HOUSING, IMPELLER Part #: 6HL-R1312-00-00 Required per assembly: 1 ~~$360.90~~ $336.09 - + Add to cart
5	BOLT, WITH, WASHER Part #: 90119-06894-00 Required per assembly: 1 ~~$2.02~~ $1.51 - + Add to cart
6	SLEEVE, IMPELLER Part #: 6GN-R1337-00-00 Required per assembly: 1 ~~$279.40~~ $254.00 - + Add to cart
7	O-RING Part #: 93211-70800-00 Required per assembly: 2 ~~$9.16~~ $3.84 - + Add to cart
8	FILTER Part #: 6GN-G6882-00-00 Required per assembly: 1 ~~$16.30~~ $12.84 - + Add to cart
9	O-RING Part #: 66V-42414-00-00 Required per assembly: 1 ~~$6.99~~ $6.35 - + Add to cart
10	BOLT, WITH, WASHER Part #: 90119-06890-00 Required per assembly: 4 ~~$3.04~~ $1.21 - + Add to cart
11	BEARING Part #: 93306-206Y7-00 Required per assembly: 1 ~~$20.98~~ $17.42 - + Add to cart
12	SPACER 1 Part #: 6CS-G5538-00-00 Required per assembly: 1 ~~$47.93~~ $36.26 - + Add to cart
13	BEARING Part #: 93306-355Y0-00 Required per assembly: 1 ~~$25.98~~ $21.41 - + Add to cart
14	OIL SEAL Part #: 93102-31009-00 Required per assembly: 1 ~~$80.48~~ $80.12 - + Add to cart
15	OIL SEAL Part #: 93101-31001-00 Required per assembly: 2 ~~$36.56~~ $33.23 - + Add to cart
16	SHAFT, DRIVE Part #: 6ET-G5511-00-00 Required per assembly: 1 $350.16 - + Add to cart
17	WASHER Part #: 92990-20600-00 Required per assembly: 1 ~~$5.49~~ $4.97 - + Add to cart
18	NUT Part #: 95312-20700-00 Required per assembly: 1 ~~$4.29~~ $3.27 - + Add to cart
19	CAP Part #: 6ET-R1326-00-00 Required per assembly: 1 ~~$24.46~~ $18.13 - + Add to cart
20	O-RING Part #: 93210-54010-00 Required per assembly: 1 ~~$2.99~~ $2.72 - + Add to cart
21	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06823-00 Required per assembly: 4 ~~$7.12~~ $2.42 - + Add to cart
22	IMPELLER Part #: 6ET-R1321-10-00 Required per assembly: 1 ~~$370.25~~ $297.85 - + Add to cart
23	SPACER Part #: 6BH-R1348-00-00 Required per assembly: 1 ~~$34.67~~ $24.92 - + Add to cart
24	O-RING Part #: 93210-30611-00 Required per assembly: 1 ~~$14.49~~ $10.63 - + Add to cart
25	NOZZLE Part #: 6ET-R1318-00-00 Required per assembly: 1 ~~$107.09~~ $96.14 - + Add to cart
26	HOSE 1 Part #: 6CS-U72M2-00-00 Required per assembly: 1 ~~$12.23~~ $7.32 - + Add to cart
27	BAND, HOSE, 18 Part #: 90601-118UF-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$7.12~~ $2.34 - + Add to cart
28	HOSE Part #: 6ET-U215E-00-00 Required per assembly: 1 ~~$9.16~~ $5.22 - + Add to cart
29	CLAMP Part #: 80L-26397-00-00 Required per assembly: 2 ~~$7.99~~ $5.49 - + Add to cart
30	HOSE, WITH, SPRING, (L205) Part #: 90447-15001-00 Required per assembly: 1 ~~$4.04~~ $3.84 - + Add to cart
31	PIN, DOWEL Part #: 93606-12019-00 Required per assembly: 2 Note: (USA) ~~$4.59~~ $3.78 - + Add to cart
32	BOLT, WITH, WASHER Part #: 90119-10811-00 Required per assembly: 4 ~~$2.02~~ $1.51 - + Add to cart
33	NOZZLE, DEFLECTOR Part #: 6S5-R1313-01-00 Required per assembly: 1 ~~$33.64~~ $26.43 - + Add to cart
34	BOLT, WITH, WASHER Part #: 90119-08852-00 Required per assembly: 2 ~~$9.16~~ $4.22 - + Add to cart
35	COLLAR Part #: 90387-08M06-00 Required per assembly: 2 ~~$12.49~~ $8.81 - + Add to cart
36	RING, TRIM Part #: 6AN-R1190-00-00 Required per assembly: 1 ~~$33.64~~ $24.18 - + Add to cart
37	STUD, JOINT, BALL Part #: 6ET-U1461-10-00 Required per assembly: 1 ~~$7.12~~ $2.18 - + Add to cart
38	WASHER, PLATE Part #: 90201-068M4-00 Required per assembly: 2 Note: YMUS ~~$2.12~~ $1.39 - + Add to cart
39	NUT Part #: 95380-06700-00 Required per assembly: 1 ~~$9.49~~ $6.05 - + Add to cart
40	BOLT, WITH, WASHER Part #: 90119-08852-00 Required per assembly: 2 ~~$9.16~~ $4.22 - + Add to cart
41	COLLAR Part #: 90387-08M06-00 Required per assembly: 2 ~~$12.49~~ $8.81 - + Add to cart
42	TUBE Part #: 6CN-U773D-01-00 Required per assembly: 1 ~~$7.12~~ $2.95 - + Add to cart
