Cowling 2 replacement parts for 2020 Yamaha FJR1300ES

OEM Parts Yamaha 2020 Yamaha FJR1300ES Cowling 2

COWLING 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 2 $2.60 $1.95 - + Add to cart
2	BODY, FRONT, UNDER, 1 Part #: 1MC-2835J-00-P5 Required per assembly: 1 $597.99 $575.91 - + Add to cart
3	PANEL 1 (MAT BLACK 2) Part #: 1MC-2835U-00-P4 Required per assembly: 1 $226.99 $195.56 - + Add to cart
4	NUT, SPRING Part #: 90183-05M02-00 Required per assembly: 1 $0.50 $0.41 - + Add to cart
5	GROMMET Part #: 90480-13014-00 Required per assembly: 2 $9.49 $6.73 - + Add to cart
6	NUT, SPRING Part #: 90183-050A6-00 Required per assembly: 2 $2.95 $2.33 - + Add to cart
7	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 1 $5.59 $4.65 - + Add to cart
8	BOLT Part #: 90109-06037-00 Required per assembly: 2 $8.49 $5.79 - + Add to cart
9	HEAD Part #: 1MC-28386-00-00 Required per assembly: 1 $16.48 $13.87 - + Add to cart
10	DAMPER Part #: 1MC-28371-00-00 Required per assembly: 1 $15.49 $11.63 - + Add to cart
11	DAMPER 1 Part #: 1MC-28415-00-00 Required per assembly: 1 $2.70 $1.74 - + Add to cart
12	DAMPER 3 Part #: 1MC-28425-00-00 Required per assembly: 1 $4.25 $2.40 - + Add to cart
13	DAMPER, PLATE Part #: 90520-50004-00 Required per assembly: 1 $5.99 $3.75 - + Add to cart
14	DAMPER, PLATE Part #: 90520-40002-00 Required per assembly: 2 $2.39 $1.63 - + Add to cart
15	DAMPER, PLATE Part #: 90520-40003-00 Required per assembly: 1 $4.79 $3.21 - + Add to cart
16	DAMPER 9 Part #: 1MC-2847P-00-00 Required per assembly: 1 $5.99 $4.60 - + Add to cart
17	PANEL, INNER, 1 Part #: 3P6-2836K-00-00 Required per assembly: 1 $66.98 $58.88 - + Add to cart
18	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 3 $2.60 $1.95 - + Add to cart
19	RIVET Part #: 90269-06001-00 Required per assembly: 2 $6.49 $5.32 - + Add to cart
20	PANEL, INNER, 3 Part #: 1MC-2836M-00-00 Required per assembly: 1 $242.99 $219.00 - + Add to cart
21	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 2 $2.60 $1.95 - + Add to cart
22	VISOR, SIDE, 1, (BLACK, METALLIC, X) Part #: 1MC-2830C-00-P0 Required per assembly: 1 $146.99 $126.22 - + Add to cart
23	PLATE, SPRING Part #: 5PW-2177L-01-00 Required per assembly: 1 $7.49 $6.11 - + Add to cart
24	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 3 $8.49 $5.58 - + Add to cart
25	DAMPER, PLATE Part #: 90520-01003-00 Required per assembly: 1 $5.49 $3.67 - + Add to cart
26	BODY, FRONT, UNDER, 2 Part #: 1MC-2835K-00-P5 Required per assembly: 1 $690.27 - + Add to cart
27	PANEL 2 (MAT BLACK 2) Part #: 1MC-2835V-00-P4 Required per assembly: 1 $226.99 $195.56 - + Add to cart
28	NUT, SPRING Part #: 90183-05M02-00 Required per assembly: 1 $0.50 $0.41 - + Add to cart
29	GROMMET Part #: 90480-13014-00 Required per assembly: 2 $9.49 $6.73 - + Add to cart
30	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 1 $5.59 $4.65 - + Add to cart
31	NUT, SPRING Part #: 90183-050A6-00 Required per assembly: 2 $2.95 $2.33 - + Add to cart
32	BOLT Part #: 90109-06037-00 Required per assembly: 2 $8.49 $5.79 - + Add to cart
33	HEAD Part #: 1MC-28386-00-00 Required per assembly: 1 $16.48 $13.87 - + Add to cart
34	DAMPER Part #: 1MC-28372-00-00 Required per assembly: 1 $11.99 $8.56 - + Add to cart
35	DAMPER 2 Part #: 1MC-28416-00-00 Required per assembly: 1 $2.70 $1.74 - + Add to cart
36	DAMPER 4 Part #: 1MC-28435-00-00 Required per assembly: 1 $5.99 $4.87 - + Add to cart
37	DAMPER, PLATE Part #: 90520-30006-00 Required per assembly: 1 $1.39 $1.15 - + Add to cart
38	DAMPER, PLATE Part #: 90520-50004-00 Required per assembly: 1 $5.99 $3.75 - + Add to cart
39	DAMPER, PLATE Part #: 90520-40002-00 Required per assembly: 1 $2.39 $1.63 - + Add to cart
40	DAMPER 10 Part #: 1MC-2847R-00-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
41	BRACKET 3 Part #: 1MC-2836F-00-00 Required per assembly: 1 $32.99 $24.48 - + Add to cart
42	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $1.95 $1.47 - + Add to cart
43	CLAMP(1GJ) Part #: 90464-54086-00 Required per assembly: 1 $3.60 $2.49 - + Add to cart
44	PANEL, INNER, 2 Part #: 3P6-2836L-00-00 Required per assembly: 1 $66.98 $63.88 - + Add to cart
45	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 3 $2.60 $1.95 - + Add to cart
46	RIVET Part #: 90269-06001-00 Required per assembly: 2 $6.49 $5.32 - + Add to cart
47	COVER, UNDER Part #: 3P6-28385-11-PE Required per assembly: 1 $165.99 $160.93 - + Add to cart
48	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 2 $2.60 $1.95 - + Add to cart
49	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05059-00 Required per assembly: 3 $2.79 $2.10 - + Add to cart
50	WASHER, PLATE Part #: 90202-05180-00 Required per assembly: 2 $10.49 $6.32 - + Add to cart
51	VISOR, SIDE, 2, (BLACK, METALLIC, X) Part #: 1MC-2830D-00-P0 Required per assembly: 1 Note: Black Metallic X $159.99 $138.24 - + Add to cart
52	PLATE, SPRING Part #: 5PW-2177L-01-00 Required per assembly: 1 $7.49 $6.11 - + Add to cart
53	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 3 $8.49 $5.58 - + Add to cart
54	DAMPER, PLATE Part #: 90520-01003-00 Required per assembly: 1 $5.49 $3.67 - + Add to cart
55	NUT, SPRING Part #: 90183-050A6-00 Required per assembly: 1 $2.95 $2.33 - + Add to cart
56	RIVET Part #: 90269-06008-00 Required per assembly: 2 $9.49 $7.26 - + Add to cart
57	PANEL, INNER, 4 Part #: 1MC-2836N-01-00 Required per assembly: 1 $228.99 $205.53 - + Add to cart
58	NUT, SPRING Part #: 90183-050A6-00 Required per assembly: 1 $2.95 $2.33 - + Add to cart
59	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05021-00 Required per assembly: 1 $6.49 $4.88 - + Add to cart
60	RIVET Part #: 90269-06008-00 Required per assembly: 1 $9.49 $7.26 - + Add to cart
61	RIVET Part #: 90269-06008-00 Required per assembly: 2 $9.49 $7.26 - + Add to cart
62	EMBLEM 3D Part #: 1MC-2839B-00-00 Required per assembly: 2 $90.98 $75.33 - + Add to cart
63	FRONT FLASHER LIGHT ASSEMBLY 1 Part #: 1MC-83310-10-00 Required per assembly: 1 $182.99 $157.84 - + Add to cart
64	FRONT FLASHER LIGHT ASSEMBLY 2 Part #: 1MC-83320-10-00 Required per assembly: 1 $168.99 $147.39 - + Add to cart
