Control Cable replacement parts for 2020 Yamaha 242S E Series

OEM Parts Yamaha 2020 Yamaha 242S E Series Control Cable

CONTROL CABLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	REMOCON. LEVER ASSEMBLY Part #: F3F-U134A-10-00 Required per assembly: 1 $994.58 $910.16 - + Add to cart
2	GASKET Part #: F3F-U7564-00-00 Required per assembly: 1 $52.00 $39.28 - + Add to cart
3	LEVER ASSEMBLY Part #: F3F-U151M-10-00 Required per assembly: 2 $298.85 $255.51 - + Add to cart
4	BOLT Part #: F3F-U1355-00-00 Required per assembly: 1 $17.32 $13.59 - + Add to cart
5	COVER Part #: F3F-U1595-B9-00 Required per assembly: 1 Not Available
6	SCREW, FLAT, HEAD, TAPPING Part #: F3F-U7869-00-00 Required per assembly: 2 $0.40 $0.35 - + Add to cart
7	SCREW, PAN, HEAD Part #: 90157-10S16-00 Required per assembly: 4 $5.08 $0.91 - + Add to cart
8	PLATE Part #: F3F-U1348-00-00 Required per assembly: 2 $11.21 $6.43 - + Add to cart
9	SCREW, COUNTERSUNK Part #: 90151-10S20-00 Required per assembly: 4 $0.46 $0.38 - + Add to cart
10	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 4 $4.99 $0.56 - + Add to cart
11	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 $5.08 $1.06 - + Add to cart
12	MOTOR ASSEMBLY Part #: F3F-6140B-01-00 Required per assembly: 1 $1,721.99 $1,708.42 - + Add to cart
13	SCREW, PAN, HEAD Part #: 90157-05815-00 Required per assembly: 8 $6.11 $1.59 - + Add to cart
14	COVER Part #: F3F-U7437-00-00 Required per assembly: 1 $160.13 $132.47 - + Add to cart
15	SCREW Part #: 90149-10SC4-00 Required per assembly: 4 $5.08 $3.02 - + Add to cart
16	WASHER, PLATE Part #: 90201-15S00-00 Required per assembly: 4 $0.15 - + Add to cart
17	WASHER, 5/16X1, 1/2 Part #: 90209-15SA4-00 Required per assembly: 4 $6.11 $1.51 - + Add to cart
18	NUT, WING Part #: 90175-15SA1-00 Required per assembly: 4 $3.04 $1.13 - + Add to cart
19	CONTROL UNIT ASSEMBLY Part #: F3F-H5590-12-00 Required per assembly: 1 Not Available
20	DAMPER, IGNITION, COIL Part #: 6A0-82317-01-00 Required per assembly: 4 $7.49 $7.03 - + Add to cart
21	COLLAR Part #: 90387-06119-00 Required per assembly: 4 $4.90 $4.84 - + Add to cart
22	SCREW, TAPPING Part #: 90167-10S16-00 Required per assembly: 4 $6.11 $1.36 - + Add to cart
23	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 4 $4.99 $0.56 - + Add to cart
24	CONTROL UNIT Part #: F3F-68197-00-00 Required per assembly: 1 $997.99 $981.27 - + Add to cart
25	MAT, WATER, LOCK Part #: GJ3-U755J-00-00 Required per assembly: 1 $115.25 $90.70 - + Add to cart
26	EYE STRAP Part #: F3F-U1543-00-00 Required per assembly: 2 $9.67 $7.41 - + Add to cart
27	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 4 $6.11 $1.13 - + Add to cart
28	CABLE, REVERSE Part #: F5V-U149C-10-00 Required per assembly: 2 Not Available
29	BALL JOINT ASSEMBLY Part #: F2C-U1460-00-00 Required per assembly: 1 $24.46 $18.88 - + Add to cart
30	PACKING C Part #: F1B-U1438-00-00 Required per assembly: 1 $7.12 $2.95 - + Add to cart
31	NUT Part #: F1B-U151S-00-00 Required per assembly: 1 $11.21 $5.44 - + Add to cart
