Side Panel replacement parts for 2020 Yamaha Sidewinder SRX LE

OEM Parts Yamaha 2020 Yamaha Sidewinder SRX LE Side Panel

SIDE PANEL Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SHELL SIDE PANEL ASSEMBLY 2 Part #: 8KC-K8140-40-00 Required per assembly: 1 $321.99 $282.27 - + Add to cart
2	LABEL, WARNING, 1 Part #: 8KC-K7761-70-00 Required per assembly: 1 $15.49 $11.64 - + Add to cart
3	NUT, CLIP, 10 Part #: 8JP-RA352-00-00 Required per assembly: 3 Note: Sold in multiples of 2 only $1.85 $1.35 - + Add to cart
4	SCREW, 10-12X3/4 Part #: 8KC-RA290-00-00 Required per assembly: 2 $2.25 $1.71 - + Add to cart
5	HOOK 2 Part #: 8KC-K715T-00-00 Required per assembly: 1 $4.20 $3.24 - + Add to cart
6	HOOK 1 Part #: 8KC-K715S-00-00 Required per assembly: 1 $4.04 $3.24 - + Add to cart
7	PROTECTOR 2 Part #: 8KC-K7552-00-00 Required per assembly: 1 $45.99 $33.61 - + Add to cart
8	PROTECTOR 1 Part #: 8KC-K7551-01-00 Required per assembly: 1 $16.98 $12.87 - + Add to cart
9	PROTECTOR 3 Part #: 8KC-K7553-01-00 Required per assembly: 1 $18.48 $12.87 - + Add to cart
10	PROTECTOR 4 Part #: 8KC-K7554-00-00 Required per assembly: 1 $5.49 $3.96 - + Add to cart
11	PROTECTOR 5 Part #: 8KC-K7555-00-00 Required per assembly: 1 $45.99 $33.61 - + Add to cart
12	VENT, SIDE, 1 Part #: 8KC-K715U-00-00 Required per assembly: 1 $40.99 $29.86 - + Add to cart
13	SCREW, 4 Part #: 8KC-RA238-00-00 Required per assembly: 1 $1.69 $1.15 - + Add to cart
14	DAMPER, NOISE, 18 Part #: 8KC-K7278-00-00 Required per assembly: 1 $21.98 $15.79 - + Add to cart
15	SHELL SIDE PANEL ASSEMBLY 1 Part #: 8KC-K8130-40-00 Required per assembly: 1 $233.99 $191.09 - + Add to cart
16	LABEL, WARNING, 1 Part #: 8NJ-K7761-S0-00 Required per assembly: 1 Not Available
17	DAMPER, NOISE, 19 Part #: 8KC-K7279-00-00 Required per assembly: 1 $21.98 $16.90 - + Add to cart
18	DAMPER, NOISE, 17 Part #: 8KC-K7277-00-00 Required per assembly: 1 $21.98 $15.79 - + Add to cart
19	DAMPER, NOISE, 17 Part #: 8KC-K7277-10-00 Required per assembly: 1 $21.98 $15.79 - + Add to cart
20	SHROUD Part #: 8MG-K7111-00-00 Required per assembly: 1 $82.98 $75.19 - + Add to cart
21	SHROUD 2 Part #: 8MG-K7112-00-00 Required per assembly: 1 $91.98 $80.18 - + Add to cart
22	SCREW, 4 Part #: 8KC-RA238-00-00 Required per assembly: 1 $1.69 $1.15 - + Add to cart
