Control Cable replacement parts for 2020 Yamaha AR190

OEM Parts Yamaha 2020 Yamaha AR190 Control Cable

CONTROL CABLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	REMOCON. LEVER ASSEMBLY Part #: F4C-U134A-00-00 Required per assembly: 1 $505.91 $476.22 - + Add to cart
2	BACK PLATE 1 Part #: EL8-48212-00-00 Required per assembly: 1 $10.99 $8.68 - + Add to cart
3	PLATE, CAM Part #: EL8-48251-00-00 Required per assembly: 1 $38.99 $37.77 - + Add to cart
4	CAP, LOCK, ARM Part #: 6X0-48138-00-00 Required per assembly: 1 $15.49 $15.10 - + Add to cart
5	CIRCLIP, E-TYPE Part #: 93430-06024-00 Required per assembly: 3 $4.04 $3.84 - + Add to cart
6	WASHER, PLATE Part #: 92990-10600-00 Required per assembly: 1 Note: Sold in multiples of 5 only $3.10 $3.02 - + Add to cart
7	CIRCLIP 1 Part #: EL8-48259-00-00 Required per assembly: 2 $7.49 $7.03 - + Add to cart
8	SHAFT, FRICTION Part #: 6X0-48265-00-00 Required per assembly: 1 $18.48 $17.37 - + Add to cart
9	SHAFT, THROTTLE Part #: 6X0-48262-00-00 Required per assembly: 1 Not Available
10	THROTTLE, FRICTION Part #: 6X0-48264-00-00 Required per assembly: 1 $58.99 $55.93 - + Add to cart
11	PLATE, ADJUST Part #: 6X0-48187-00-00 Required per assembly: 1 $18.48 $17.37 - + Add to cart
12	NUT, HEXAGON Part #: 95380-06600-00 Required per assembly: 2 $4.79 $4.60 - + Add to cart
13	SPACER Part #: 704-48266-00-00 Required per assembly: 1 Not Available
14	NEUTRAL SWITCH ASSEMBLY Part #: F1C-U137A-10-00 Required per assembly: 1 $89.75 $72.56 - + Add to cart
15	SCREW 3 Part #: 703-48129-00-00 Required per assembly: 4 $2.04 $1.97 - + Add to cart
16	SCREW 1 Part #: 6XE-48281-00-00 Required per assembly: 2 $11.99 $10.57 - + Add to cart
17	SCREW, PANHEAD, (A93) Part #: 98580-05525-00 Required per assembly: 2 $2.00 $1.51 - + Add to cart
18	ARM, THROTTLE Part #: 6X0-48261-00-00 Required per assembly: 1 $50.99 $48.35 - + Add to cart
19	BOLT (FJ0) Part #: 97080-06018-00 Required per assembly: 3 $8.99 $6.97 - + Add to cart
20	CABLE, END, REMOTE, CONTROL, 2 Part #: 703-48345-01-00 Required per assembly: 2 $16.00 $13.80 - + Add to cart
21	SCREW 1 Part #: EL8-48127-00-00 Required per assembly: 11 $6.49 $6.18 - + Add to cart
22	BACK PLATE 2 Part #: EL8-48213-00-00 Required per assembly: 1 $17.98 $17.37 - + Add to cart
23	ANCHOR, CABLE Part #: 703-48358-01-00 Required per assembly: 1 $10.99 $10.57 - + Add to cart
24	HOUSING, GEAR Part #: EL8-48231-00-00 Required per assembly: 1 $41.99 $39.28 - + Add to cart
25	ARM, DRIVE Part #: EL8-48241-00-00 Required per assembly: 1 $37.99 $36.26 - + Add to cart
26	STOPPER, THROTTLE, ADJUST Part #: F1C-48254-00-00 Required per assembly: 1 $9.99 $9.06 - + Add to cart
27	SCREW, FLAT, HEAD Part #: 98780-06020-00 Required per assembly: 2 $9.49 $6.55 - + Add to cart
28	ROLLER, FREE, ACCEL. Part #: 701-48248-00-00 Required per assembly: 1 Note: ((LX)) [ROLLER,FREE ACCEL.] $6.99 $6.56 - + Add to cart
29	SPRING, DETENT Part #: 704-48238-00-00 Required per assembly: 5 Not Available
30	CIRCLIP 2 Part #: EL8-48279-00-00 Required per assembly: 1 $17.48 $17.37 - + Add to cart
31	WASHER 3 Part #: 704-48193-00-00 Required per assembly: 1 $14.99 $14.35 - + Add to cart
32	BUSHING 1 Part #: EL8-48234-00-00 Required per assembly: 1 $7.49 $7.03 - + Add to cart
33	WASHER 2 Part #: 703-48192-00-00 Required per assembly: 1 $4.90 $4.84 - + Add to cart
34	BUSHING Part #: 703-48235-00-00 Required per assembly: 1 $11.99 $11.32 - + Add to cart
35	GRIP, CONTROL, LEVER Part #: 6X3-48222-10-00 Required per assembly: 1 $23.98 $23.42 - + Add to cart
36	SPRING, NEUTRAL, LOCK Part #: 703-48227-00-00 Required per assembly: 1 Note: ((150)) [SPRING,NEUTRAL] $7.49 $7.03 - + Add to cart
37	SCREW, PAN, HEAD Part #: 98580-05008-00 Required per assembly: 1 $8.49 $5.64 - + Add to cart
38	WASHER, PLAIN Part #: 6X0-48288-00-00 Required per assembly: 1 $6.99 $6.56 - + Add to cart
39	SCREW 1 Part #: 6X0-48127-00-00 Required per assembly: 1 $3.29 $3.24 - + Add to cart
40	LOCK, NEUTRAL Part #: 6X0-48223-00-00 Required per assembly: 1 $29.98 $28.70 - + Add to cart
41	LEVER, CONTROL Part #: 6X3-48221-10-00 Required per assembly: 1 $197.89 $179.90 - + Add to cart
42	COVER Part #: 6X0-48225-00-00 Required per assembly: 1 $15.99 $15.86 - + Add to cart
43	BODY, REMOTE, CONTROL, 1 Part #: 6X3-48111-10-00 Required per assembly: 1 $23.98 $22.66 - + Add to cart
44	COVER Part #: 6X3-48225-30-00 Required per assembly: 1 $8.99 $8.30 - + Add to cart
45	PLUNGER Part #: 6X0-48155-00-00 Required per assembly: 1 $21.98 $20.40 - + Add to cart
46	WASHER, INTERNAL, TOOTH Part #: 92990-05300-00 Required per assembly: 6 Note: Sold in multiples of 5 only $9.49 $6.55 - + Add to cart
47	SCREW Part #: 6X0-48281-00-00 Required per assembly: 2 $3.29 $3.24 - + Add to cart
48	WASHER 3 Part #: 6X0-48193-00-00 Required per assembly: 1 $15.49 $15.10 - + Add to cart
49	SCREW (M6X30) Part #: 6X0-48128-00-00 Required per assembly: 3 Note: (M6X30) $11.63 $10.57 - + Add to cart
49	SCREW, PAN, HEAD, (6H4) Part #: 97885-06035-00 Required per assembly: 3 $6.49 $6.27 - + Add to cart
50	NUT 1 Part #: 6X0-48156-00-00 Required per assembly: 3 $11.99 $11.32 - + Add to cart
51	WASHER Part #: 701-48287-00-00 Required per assembly: 3 Note: ((150)) $11.49 $11.32 - + Add to cart
52	SCREW 3 Part #: 6X3-48129-00-00 Required per assembly: 4 $6.99 $6.49 - + Add to cart
53	INDICATOR, SHIFT Part #: 6X3-44191-00-00 Required per assembly: 1 $10.99 $10.57 - + Add to cart
54	BUSHING Part #: 6X0-48116-00-00 Required per assembly: 1 $6.99 $6.65 - + Add to cart
55	SCREW, PAN, HEAD, (6B0) Part #: 97885-05016-00 Required per assembly: 2 $4.70 $4.54 - + Add to cart
56	SCREW, 1/4-20, X, 3 Part #: 90149-14SA7-00 Required per assembly: 2 $6.11 $1.97 - + Add to cart
57	SCREW, #8, X, 5/8" Part #: 90167-08S10-00 Required per assembly: 1 $6.11 $0.91 - + Add to cart
58	PLATE Part #: F4C-U1348-00-00 Required per assembly: 1 $69.34 $55.93 - + Add to cart
59	WASHER, FENDER, (1/4", X, 1") Part #: 90209-14SA2-00 Required per assembly: 2 $2.02 $0.60 - + Add to cart
60	SCREW, COUNTERSUNK Part #: 90152-14S16-00 Required per assembly: 3 $0.51 $0.38 - + Add to cart
61	BAND, HOSE Part #: 90601-200U8-00 Required per assembly: 1 $7.12 $2.10 - + Add to cart
62	NUT, SELF-LOCKING Part #: 90185-14S00-00 Required per assembly: 2 $5.08 $0.68 - + Add to cart
63	CABLE, REVERSE Part #: F5V-6149C-01-00 Required per assembly: 1 $322.97 - + Add to cart
64	BALL JOINT ASSEMBLY Part #: F2C-U1460-00-00 Required per assembly: 1 $24.46 $18.88 - + Add to cart
65	PACKING C Part #: F1B-U1438-00-00 Required per assembly: 1 $7.12 $2.95 - + Add to cart
66	NUT Part #: F1B-U151S-00-00 Required per assembly: 1 $11.21 $5.44 - + Add to cart
67	CABLE, THROTTLE Part #: F4A-U7252-00-00 Required per assembly: 1 $132.59 $98.25 - + Add to cart
