Helm replacement parts for 2020 Yamaha SX190 California

OEM Parts Yamaha 2020 Yamaha SX190 California Helm

HELM Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WINDSHIELD FR. Part #: F4C-U1811-00-00 Required per assembly: 1 $1,277.46 - + Add to cart
2	WINDSHIELD FR. (RH) Part #: F4C-U1812-00-00 Required per assembly: 1 $1,375.74 - + Add to cart
3	WIND SHIELD Part #: F4C-U1818-00-00 Required per assembly: 1 ~~$423.29~~ $420.08 - + Add to cart
4	KIT, WINDSHIELD, FITTING Part #: F3R-U1940-10-00 Required per assembly: 1 ~~$136.66~~ $105.81 - + Add to cart
5	EYE STRAP Part #: F3R-U1543-00-00 Required per assembly: 1 ~~$41.81~~ $33.23 - + Add to cart
6	BRACKET Part #: F3R-U5522-00-00 Required per assembly: 2 ~~$30.98~~ $23.07 - + Add to cart
7	SCREW, TAPPING Part #: 90162-08S12-00 Required per assembly: 14 ~~$6.11~~ $1.36 - + Add to cart
8	SCREW Part #: 90149-08SD4-00 Required per assembly: 2 ~~$0.36~~ $0.30 - + Add to cart
9	SCREW, COUNTERSUNK Part #: 90152-08S24-00 Required per assembly: 8 ~~$5.08~~ $0.68 - + Add to cart
10	WASHER, #8, FLAT Part #: 90201-08S00-00 Required per assembly: 10 ~~$4.07~~ $0.60 - + Add to cart
11	NUT, SELF-LOCKING Part #: 90185-08S00-00 Required per assembly: 10 ~~$7.12~~ $1.59 - + Add to cart
12	SCREW, PAN, HEAD Part #: 90157-10S16-00 Required per assembly: 4 ~~$5.08~~ $0.91 - + Add to cart
13	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 4 ~~$4.99~~ $0.56 - + Add to cart
14	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 4 ~~$5.08~~ $1.06 - + Add to cart
15	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 4 ~~$6.11~~ $1.13 - + Add to cart
16	GLOVE BOX HATCH ASSEMBLY Part #: F4C-U1708-00-00 Required per assembly: 1 ~~$362.08~~ $347.14 - + Add to cart
17	WASHER, #8, FLAT Part #: 90201-08S00-00 Required per assembly: 4 ~~$4.07~~ $0.60 - + Add to cart
18	WASHER, LOCK, (#8) Part #: 90204-08S00-00 Required per assembly: 4 ~~$6.11~~ $1.29 - + Add to cart
19	NUT Part #: 90170-08S00-00 Required per assembly: 4 Note: FOR-000821~ SEE NOTE FOR REF. # 9 ~~$6.11~~ $1.29 - + Add to cart
20	DOOR ASSEMBLY Part #: F4C-U5720-00-00 Required per assembly: 1 $317.68 - + Add to cart
21	SCREW, TAPPING Part #: 90162-08SA1-00 Required per assembly: 14 ~~$6.11~~ $1.44 - + Add to cart
22	DOOR ASSEMBLY Part #: F4C-U5720-10-00 Required per assembly: 1 ~~$442.67~~ $438.64 - + Add to cart
23	SCREW, TAPPING Part #: 90162-08SA1-00 Required per assembly: 13 ~~$6.11~~ $1.44 - + Add to cart
24	CAN, TRASH Part #: F4A-U561C-00-00 Required per assembly: 1 ~~$166.99~~ $134.15 - + Add to cart
25	CLIP Part #: F4A-U6969-00-00 Required per assembly: 2 ~~$64.25~~ $51.39 - + Add to cart
26	SCREW, TAPPING Part #: 90161-06S10-00 Required per assembly: 4 ~~$37.72~~ $28.70 - + Add to cart
