Engine Hatch 2 replacement parts for 2020 Yamaha VX-C

OEM Parts Yamaha 2020 Yamaha VX C Engine Hatch 2

ENGINE HATCH 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	LID, ENGINE, ROOM, (VLGS6) Part #: F2X-U517B-10-P4 Required per assembly: 1 $332.50 $326.43 - + Add to cart
2	INNER, ENGINE, HATCH Part #: F2X-U519G-10-00 Required per assembly: 1 $311.08 $282.07 - + Add to cart
3	DAMPER, LID Part #: F2C-U515D-00-00 Required per assembly: 1 $7.12 $2.10 - + Add to cart
4	CUSHION, RUBBER Part #: F1W-U3768-01-00 Required per assembly: 2 $6.11 $1.59 - + Add to cart
5	SCREW Part #: F2S-U13C1-00-00 Required per assembly: 15 $7.12 $2.65 - + Add to cart
6	PACKING 1 Part #: F2N-U2663-01-00 Required per assembly: 1 $62.21 $49.88 - + Add to cart
7	LOCK, LID Part #: F2X-U517C-01-00 Required per assembly: 1 $13.25 $8.30 - + Add to cart
8	HINGE ASSEMBLY Part #: F2X-U515A-01-00 Required per assembly: 1 $377.38 $349.26 - + Add to cart
9	PLATE, HINGE, LID Part #: F1K-U518E-04-00 Required per assembly: 1 $49.96 $42.31 - + Add to cart
10	HINGE, LID Part #: F1K-U517D-05-00 Required per assembly: 1 $339.64 $314.48 - + Add to cart
11	ROLLER, DETENT Part #: F2X-U135C-00-00 Required per assembly: 1 $13.25 $10.57 - + Add to cart
12	PIN, HINGE Part #: F1K-U517R-01-00 Required per assembly: 2 $8.15 $3.55 - + Add to cart
13	SPACER 1 Part #: F1K-U471E-03-00 Required per assembly: 1 $19.37 $13.59 - + Add to cart
14	SPRING, TORSION Part #: F1K-U283B-02-00 Required per assembly: 1 $12.23 $6.27 - + Add to cart
15	BOLT, FLANGE Part #: 90105-06826-00 Required per assembly: 2 $7.12 $3.33 - + Add to cart
16	NUT, FLANGE Part #: 9572R-06300-00 Required per assembly: 2 $9.16 $3.08 - + Add to cart
17	WASHER Part #: 9299R-06200-00 Required per assembly: 2 $0.75 $0.45 - + Add to cart
18	BOLT, HEX., SOCKET, BUTTON Part #: 90111-06873-00 Required per assembly: 4 $11.21 $5.50 - + Add to cart
19	LOCKER, BOW Part #: F2X-U475B-00-00 Required per assembly: 1 $203.99 $181.22 - + Add to cart
20	PACKING 4 Part #: F2C-U266C-00-00 Required per assembly: 1 $13.25 $7.32 - + Add to cart
21	PLUG, BLIND Part #: 90605-502U1-00 Required per assembly: 1 $7.12 $2.42 - + Add to cart
22	RIVET Part #: 90269-08801-00 Required per assembly: 4 $6.11 $1.29 - + Add to cart
23	PLATE, LOKER, BOW Part #: F2S-U475F-00-00 Required per assembly: 1 $18.35 $12.08 - + Add to cart
24	RIVET Part #: 90269-08801-00 Required per assembly: 5 $6.11 $1.29 - + Add to cart
25	MIRROR ASSEMBLY 1 Part #: F2X-U590D-70-00 Required per assembly: 1 $167.27 $135.98 - + Add to cart
26	CUSHION, RUBBER Part #: F1W-U3768-01-00 Required per assembly: 1 $6.11 $1.59 - + Add to cart
27	PACKING 3 Part #: F1K-U266B-00-00 Required per assembly: 2 $6.11 $1.29 - + Add to cart
28	MIRROR ASSEMBLY 2 Part #: F2X-U590E-70-00 Required per assembly: 1 $167.27 $135.98 - + Add to cart
29	CUSHION, RUBBER Part #: F1W-U3768-01-00 Required per assembly: 1 $6.11 $1.59 - + Add to cart
30	PACKING 3 Part #: F1K-U266B-00-00 Required per assembly: 2 $6.11 $1.29 - + Add to cart
31	SCREW Part #: F2X-U13C1-00-00 Required per assembly: 8 $6.11 $1.81 - + Add to cart
32	HOOK A Part #: F1K-U5772-04-00 Required per assembly: 2 $12.23 $6.27 - + Add to cart
33	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 2 Note: Sold in multiples of 5 only $5.49 $4.97 - + Add to cart
34	MAT 2 Part #: F1K-U759C-00-00 Required per assembly: 2 $6.11 $1.89 - + Add to cart
35	BOX, FIRE, EXTINGUISHER Part #: F2X-U5983-00-00 Required per assembly: 1 $12.37 - + Add to cart
36	RIVET, BLIND Part #: 90267-48802-00 Required per assembly: 2 $6.99 $2.08 - + Add to cart
37	BAND, 1 Part #: F2P-U828K-00-00 Required per assembly: 1 $13.25 $6.49 - + Add to cart
