Rear Wheel replacement parts for 2020 Yamaha YFZ450R Special Edition

OEM Parts Yamaha 2020 Yamaha YFZ450R Special Edition Rear Wheel

REAR WHEEL Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	REAR WHEEL COMP. Part #: 1TD-F5390-11-00 Required per assembly: 1 ~~$287.99~~ $265.87 - + Add to cart
2	AT20X10R9 MS22 TL ( ITD ) Part #: 94110-09802-00 Required per assembly: 1 ~~$309.99~~ $305.71 - + Add to cart
3	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 ~~$9.49~~ $7.36 - + Add to cart
4	GRAPHIC 2 Part #: BW2-F51G2-20-00 Required per assembly: 1 ~~$110.98~~ $100.19 - + Add to cart
5	REAR WHEEL COMP. Part #: 1TD-F5390-11-00 Required per assembly: 1 ~~$287.99~~ $265.87 - + Add to cart
6	AT20X10R9 MS22 TL ( ITD ) Part #: 94110-09802-00 Required per assembly: 1 ~~$309.99~~ $305.71 - + Add to cart
7	VALVE, RIM, (TR413) Part #: 93900-00812-00 Required per assembly: 1 ~~$9.49~~ $7.36 - + Add to cart
8	GRAPHIC 2 Part #: BW2-F51G2-20-00 Required per assembly: 1 ~~$110.98~~ $100.19 - + Add to cart
9	COLLAR, WHEEL Part #: 18P-25383-00-00 Required per assembly: 2 ~~$185.99~~ $159.82 - + Add to cart
10	BOLT, SERRATION Part #: 90114-10013-00 Required per assembly: 4 ~~$5.99~~ $4.48 - + Add to cart
11	NUT, FLANGE, (3BM) Part #: 95704-10500-00 Required per assembly: 8 ~~$4.29~~ $3.26 - + Add to cart
12	WASHER, PLAIN Part #: 92990-10200-00 Required per assembly: 8 ~~$3.79~~ $2.95 - + Add to cart
13	WASHER, PLATE Part #: 90201-16023-00 Required per assembly: 2 ~~$9.49~~ $6.67 - + Add to cart
14	NUT, CASTLE Part #: 90171-16002-00 Required per assembly: 2 ~~$22.98~~ $17.30 - + Add to cart
15	PIN, COTTER Part #: 90252-03001-00 Required per assembly: 2 ~~$2.10~~ $1.77 - + Add to cart
16	COLLAR, SPROCKET, AXLE Part #: 18P-25386-00-00 Required per assembly: 1 ~~$185.99~~ $166.89 - + Add to cart
17	SPROCKET, DRIVEN, (38T) Part #: 5TG-25438-10-00 Required per assembly: 1 ~~$46.99~~ $37.12 - + Add to cart
18	BOLT Part #: 90109-10013-00 Required per assembly: 4 ~~$8.49~~ $6.00 - + Add to cart
19	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 4 ~~$4.95~~ $4.10 - + Add to cart
20	BRACKET, DISC Part #: 1TD-F5712-00-00 Required per assembly: 1 ~~$49.99~~ $40.28 - + Add to cart
21	COLLAR Part #: 90387-40001-00 Required per assembly: 1 ~~$23.98~~ $18.61 - + Add to cart
22	AXLE, WHEEL Part #: BKD-F5381-00-00 Required per assembly: 1 ~~$366.99~~ $344.42 - + Add to cart
23	NUT Part #: 90179-38001-00 Required per assembly: 1 ~~$73.98~~ $60.37 - + Add to cart
24	WASHER, CONICAL, SPRING Part #: 90208-39001-00 Required per assembly: 1 ~~$11.49~~ $9.43 - + Add to cart
25	BOLT, SET Part #: 90113-06039-00 Required per assembly: 4 ~~$10.49~~ $6.85 - + Add to cart
26	CIRCLIP Part #: 18P-25415-00-00 Required per assembly: 1 ~~$8.49~~ $6.27 - + Add to cart
27	O-RING Part #: 93210-37003-00 Required per assembly: 3 ~~$8.49~~ $5.67 - + Add to cart
28	CHAIN (DID520MXV4-98LE) Part #: 94582-38098-00 Required per assembly: 1 ~~$147.63~~ $134.21 - + Add to cart
