Frame replacement parts for 2020 Yamaha Wolverine X2 EPS

OEM Parts Yamaha 2020 Yamaha Wolverine X2 EPS Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: BAN-F1110-31-00 Required per assembly: 1 $3,520.48 $3,200.44 - + Add to cart
2	ENGINE BRACKET COMP. Part #: BG4-21410-00-00 Required per assembly: 1 $80.98 $72.91 - + Add to cart
3	ENGINE BRACKET COMP. 2 Part #: BG4-21420-00-00 Required per assembly: 1 $80.98 $72.91 - + Add to cart
4	BOLT, FLANGE, (3GD) Part #: 95817-10025-00 Required per assembly: 4 $9.49 $6.05 - + Add to cart
5	BRACKET 5 Part #: BG4-F161F-00-00 Required per assembly: 1 $13.49 $9.65 - + Add to cart
6	BRACKET 3 Part #: BG4-F161A-00-00 Required per assembly: 1 $8.99 $7.30 - + Add to cart
7	BOLT, FLANGE, (JN5) Part #: 95817-12065-00 Required per assembly: 2 $5.49 $4.72 - + Add to cart
8	BOLT, FLANGE Part #: 95812-10016-00 Required per assembly: 4 $10.49 $8.10 - + Add to cart
9	BRACKET, ENGINE, 1 Part #: BG4-21490-00-00 Required per assembly: 2 $81.98 $74.36 - + Add to cart
10	BOLT, FLANGE, (JN5) Part #: 95817-12065-00 Required per assembly: 2 $5.49 $4.72 - + Add to cart
11	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 2 $4.95 $4.10 - + Add to cart
12	SUPPORT, ENGINE Part #: BG4-F1283-00-00 Required per assembly: 1 $15.99 $12.41 - + Add to cart
13	SUPT., ENGINE, 2 Part #: BG4-F1284-00-00 Required per assembly: 1 $15.99 $12.34 - + Add to cart
14	BOLT, FLANGE, (3GD) Part #: 95817-10025-00 Required per assembly: 4 $9.49 $6.05 - + Add to cart
15	BRACKET 1 Part #: BG4-F172K-00-00 Required per assembly: 1 $4.95 $3.78 - + Add to cart
16	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 $5.49 $3.84 - + Add to cart
17	BRACKET 1 Part #: BG4-F172K-00-00 Required per assembly: 1 $4.95 $3.78 - + Add to cart
18	BOLT, FLANGE Part #: 95817-06010-00 Required per assembly: 2 $5.49 $3.84 - + Add to cart
19	STAY, SUPPORT, 1 Part #: BG4-F831T-00-00 Required per assembly: 1 $50.12 - + Add to cart
20	WASHER, PLATE Part #: 90201-12039-00 Required per assembly: 4 $4.49 $4.08 - + Add to cart
21	BOLT, FLANGE Part #: 90105-12121-00 Required per assembly: 4 $3.79 $2.57 - + Add to cart
22	BRKT., RR., AXLE Part #: BG4-F1981-00-00 Required per assembly: 1 $4.50 $3.46 - + Add to cart
23	BOLT, FLANGE, (JN5) Part #: 95817-08016-00 Required per assembly: 2 $5.49 $4.05 - + Add to cart
24	LUG, SEAT, RAIL, LH. Part #: BG4-F1143-10-00 Required per assembly: 1 $43.77 - + Add to cart
25	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
26	MEMBER, SEAT, SUPPORT Part #: BG4-F255G-01-00 Required per assembly: 1 $36.99 $32.99 - + Add to cart
27	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
28	BRACKET, LOCK, 2 Part #: BG4-F287M-00-00 Required per assembly: 1 $20.98 $15.98 - + Add to cart
29	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
30	STAY, MUFFLER, 2 Part #: B8K-F1446-00-00 Required per assembly: 1 $3.04 $2.53 - + Add to cart
31	COVER 3 Part #: 2MB-F198J-00-00 Required per assembly: 2 $4.90 $4.84 - + Add to cart
32	BOLT, SPECIAL, 1 Part #: JW1-K6179-01-00 Required per assembly: 2 $1.75 $1.21 - + Add to cart
33	HOOK, SIDE, COVER, 1 Part #: BG4-F1331-00-00 Required per assembly: 2 $9.49 $6.59 - + Add to cart
34	BOLT, FLANGE Part #: 95812-06014-00 Required per assembly: 4 $6.49 $5.35 - + Add to cart
35	REINFORCEMENT, FRAME, 1 Part #: BG4-F1986-01-00 Required per assembly: 1 $1,114.00 - + Add to cart
36	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 3 $1.95 $1.47 - + Add to cart
37	PLUG Part #: B8K-F2417-00-00 Required per assembly: 2 $2.70 $2.00 - + Add to cart
38	MOLD, FUEL, TANK Part #: 31A-24188-01-00 Required per assembly: 1 $13.99 $11.60 - + Add to cart
39	TOOL KIT Part #: BG4-F8100-00-00 Required per assembly: 1 $24.98 $17.61 - + Add to cart
40	GAUGE, AIR Part #: 1XD-F811A-00-00 Required per assembly: 1 $7.49 $6.86 - + Add to cart
41	POUCH Part #: 1P0-F8186-01-00 Required per assembly: 1 $2.89 $2.62 - + Add to cart
42	MOLD, FUEL, TANK Part #: 3VD-24188-00-00 Required per assembly: 1 $41.99 $32.93 - + Add to cart
