Side Cover 3 replacement parts for 2020 Yamaha YXZ1000R SS XTR

OEM Parts Yamaha 2020 Yamaha YXZ1000R SS XTR Side Cover 3

SIDE COVER 3 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PNL., DOOR, FR., LH Part #: 2HC-K8557-01-00 Required per assembly: 1 ~~$359.99~~ $320.60 - + Add to cart
2	NUT, PLATE Part #: 2HC-F1736-00-00 Required per assembly: 2 ~~$10.49~~ $7.30 - + Add to cart
3	BODY, LATCH, 1 Part #: 2HC-K7171-00-00 Required per assembly: 1 ~~$56.99~~ $46.57 - + Add to cart
4	LOCK ASSEMBLY Part #: 2HC-F16A0-00-00 Required per assembly: 1 ~~$32.99~~ $23.80 - + Add to cart
5	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 2 ~~$3.50~~ $2.65 - + Add to cart
6	LEVER, LATCH, 1 Part #: 2HC-F17N1-00-00 Required per assembly: 1 ~~$8.49~~ $5.76 - + Add to cart
7	SPRING Part #: 2HC-F1742-00-00 Required per assembly: 1 ~~$3.20~~ $2.25 - + Add to cart
8	PIN Part #: 90249-05801-00 Required per assembly: 1 ~~$2.54~~ $2.16 - + Add to cart
9	CIRCLIP (EU0) Part #: 99080-04600-00 Required per assembly: 1 ~~$1.99~~ $1.81 - + Add to cart
10	ROD 1 Part #: 2HC-F7247-00-00 Required per assembly: 1 Not Available
11	CLIP, CABLE Part #: 2HC-F2805-00-00 Required per assembly: 1 Not Available
12	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06086-00 Required per assembly: 4 ~~$6.49~~ $4.88 - + Add to cart
13	STAY, FR., DOOR, 1 Part #: 2HC-K8554-00-00 Required per assembly: 2 ~~$7.49~~ $5.76 - + Add to cart
14	COLLAR Part #: 2HC-F1748-00-00 Required per assembly: 4 ~~$2.70~~ $2.10 - + Add to cart
15	BOLT Part #: 90109-068A8-00 Required per assembly: 2 ~~$2.95~~ $2.24 - + Add to cart
16	BOLT Part #: 90109-08856-00 Required per assembly: 4 ~~$3.00~~ $2.25 - + Add to cart
17	LOCK Part #: 2HC-F178J-00-00 Required per assembly: 1 ~~$9.49~~ $8.30 - + Add to cart
18	BOLT, BUTTON, HEAD Part #: 92012-08012-00 Required per assembly: 2 ~~$9.49~~ $6.24 - + Add to cart
19	PAD Part #: 2MB-F8378-00-00 Required per assembly: 1 ~~$2.70~~ $2.45 - + Add to cart
20	PNL., DOOR, FR., RH Part #: 2HC-K8558-01-00 Required per assembly: 1 ~~$359.99~~ $322.60 - + Add to cart
21	NUT, PLATE Part #: 2HC-F1736-00-00 Required per assembly: 2 ~~$10.49~~ $7.30 - + Add to cart
22	BODY, LATCH, 2 Part #: 2HC-K7172-00-00 Required per assembly: 1 ~~$56.99~~ $46.57 - + Add to cart
23	LOCK ASSEMBLY 2 Part #: 2HC-F16B0-00-00 Required per assembly: 1 ~~$33.99~~ $24.27 - + Add to cart
24	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 2 ~~$3.50~~ $2.65 - + Add to cart
25	LEVER, LATCH, 1 Part #: 2HC-F17N1-00-00 Required per assembly: 1 ~~$8.49~~ $5.76 - + Add to cart
26	SPRING Part #: 2HC-F1742-00-00 Required per assembly: 1 ~~$3.20~~ $2.25 - + Add to cart
27	PIN Part #: 90249-05801-00 Required per assembly: 1 ~~$2.54~~ $2.16 - + Add to cart
28	CIRCLIP (EU0) Part #: 99080-04600-00 Required per assembly: 1 ~~$1.99~~ $1.81 - + Add to cart
29	ROD 2 Part #: 2HC-F7248-00-00 Required per assembly: 1 ~~$2.39~~ $2.00 - + Add to cart
30	CLIP, CABLE Part #: 2HC-F2805-00-00 Required per assembly: 1 Not Available
31	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06086-00 Required per assembly: 4 ~~$6.49~~ $4.88 - + Add to cart
32	STAY, FR., DOOR, 1 Part #: 2HC-K8554-00-00 Required per assembly: 2 ~~$7.49~~ $5.76 - + Add to cart
33	COLLAR Part #: 2HC-F1748-00-00 Required per assembly: 4 ~~$2.70~~ $2.10 - + Add to cart
34	BOLT Part #: 90109-068A8-00 Required per assembly: 2 ~~$2.95~~ $2.24 - + Add to cart
35	BOLT Part #: 90109-08856-00 Required per assembly: 4 ~~$3.00~~ $2.25 - + Add to cart
36	LOCK Part #: 2HC-F178J-00-00 Required per assembly: 1 ~~$9.49~~ $8.30 - + Add to cart
37	BOLT, BUTTON, HEAD Part #: 92012-08012-00 Required per assembly: 2 ~~$9.49~~ $6.24 - + Add to cart
38	PAD Part #: 2MB-F8378-00-00 Required per assembly: 1 ~~$2.70~~ $2.45 - + Add to cart
39	SIDE COVER COMP. 1 Part #: 2HC-F17E0-20-00 Required per assembly: 1 ~~$128.99~~ $116.50 - + Add to cart
40	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06181-00 Required per assembly: 6 ~~$1.50~~ $1.22 - + Add to cart
41	SIDE COVER COMP. 2 Part #: 2HC-F17F0-20-00 Required per assembly: 1 ~~$128.99~~ $115.91 - + Add to cart
42	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06181-00 Required per assembly: 6 ~~$1.50~~ $1.22 - + Add to cart
