Throttle Body Assembly 1 replacement parts for 2020 Yamaha YXZ1000R EPS

OEM Parts Yamaha 2020 Yamaha YXZ1000R EPS Throttle Body Assembly 1

THROTTLE BODY ASSEMBLY 1 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	THROTTLE BODY ASSEMBLY Part #: B5H-13750-02-00 Required per assembly: 1 $1,625.00 $1,477.27 - + Add to cart
2	GASKET, MANIFOLD Part #: 8FP-13556-10-00 Required per assembly: 3 $7.49 $6.80 - + Add to cart
3	INJECTOR Part #: 2HC-13761-00-00 Required per assembly: 3 $127.98 $114.13 - + Add to cart
4	O-RING Part #: 68V-1416A-00-00 Required per assembly: 1 $14.49 $13.59 - + Add to cart
5	O-RING Part #: 5YP-14562-00-00 Required per assembly: 1 $8.49 $6.49 - + Add to cart
6	COVER 1 Part #: 5UG-14293-00-00 Required per assembly: 1 $14.49 $9.81 - + Add to cart
7	O-RING Part #: 5LP-14147-00-00 Required per assembly: 1 $12.99 $9.99 - + Add to cart
8	CLAMP 1 Part #: 69J-2417H-00-00 Required per assembly: 2 $13.99 $13.59 - + Add to cart
9	HOSE, AIR, 4 Part #: 2HC-13894-00-00 Required per assembly: 1 $16.48 $13.14 - + Add to cart
10	CONNECTOR Part #: 5PW-1410F-00-00 Required per assembly: 1 $21.98 $17.15 - + Add to cart
11	PIPE Part #: 8FP-14349-30-00 Required per assembly: 1 $6.49 $4.08 - + Add to cart
12	HOSE, AIR, 2 Part #: 8HF-13892-00-00 Required per assembly: 1 $47.99 $36.77 - + Add to cart
13	HOSE, AIR, 3 Part #: 8GL-13893-00-00 Required per assembly: 1 $8.49 $6.18 - + Add to cart
14	HOSE, AIR Part #: 8GL-13895-00-00 Required per assembly: 1 $32.99 $22.82 - + Add to cart
15	SENSOR, PRESSURE Part #: 1WS-82380-00-00 Required per assembly: 2 $209.99 $180.71 - + Add to cart
16	SCREW Part #: 2C0-14216-00-00 Required per assembly: 2 $4.20 $2.98 - + Add to cart
17	HOSE, AIR Part #: 18P-13543-00-00 Required per assembly: 1 $34.99 $26.73 - + Add to cart
18	SCREW Part #: 8CC-14216-10-00 Required per assembly: 2 $8.99 $7.03 - + Add to cart
19	THROTTLE SENSOR AS Part #: 3B4-85885-01-00 Required per assembly: 1 $78.98 $65.97 - + Add to cart
20	BOLT 1 Part #: 8GL-13573-00-00 Required per assembly: 2 $16.48 $11.46 - + Add to cart
21	WASHER Part #: 8GL-13571-00-00 Required per assembly: 2 $4.40 $3.30 - + Add to cart
22	COLLAR Part #: 8GL-14534-00-00 Required per assembly: 2 $10.49 $8.39 - + Add to cart
23	PIPE INLET ASSEMBLY Part #: 2HC-13930-00-00 Required per assembly: 1 $241.99 $210.29 - + Add to cart
24	PIPE Part #: 5PW-14349-00-00 Required per assembly: 1 $12.99 $8.44 - + Add to cart
25	NUT, CABLE, ADJUSTING Part #: 1S3-14161-00-00 Required per assembly: 1 $8.49 $6.27 - + Add to cart
26	GUIDE, CABLE Part #: 1UY-14155-00-00 Required per assembly: 1 $19.98 $16.16 - + Add to cart
27	CLIP Part #: 90467-150A2-00 Required per assembly: 1 $8.49 $6.12 - + Add to cart
28	HOSE 1 Part #: 2HC-13545-00-00 Required per assembly: 1 $18.98 $17.15 - + Add to cart
29	CAP Part #: 895-14169-00-00 Required per assembly: 2 $5.99 $3.93 - + Add to cart
30	CLIP, PIPE Part #: 8A7-14139-00-00 Required per assembly: 2 $9.49 $6.67 - + Add to cart
31	ADJUST SCREW SET Part #: 8GL-14503-00-00 Required per assembly: 3 $16.48 $13.43 - + Add to cart
32	CLIP Part #: 90467-11106-00 Required per assembly: 3 $4.04 $2.68 - + Add to cart
33	PIPE Part #: B5H-14419-00-00 Required per assembly: 1 $16.98 $13.93 - + Add to cart
34	PIPE Part #: B5H-14465-00-00 Required per assembly: 1 $16.48 $13.68 - + Add to cart
35	PIPE Part #: B5H-14466-00-00 Required per assembly: 1 $19.48 $14.74 - + Add to cart
36	PIPE Part #: B5H-1443J-00-00 Required per assembly: 1 $17.48 $12.49 - + Add to cart
37	PIPE Part #: B5H-1444J-00-00 Required per assembly: 1 $17.48 $13.85 - + Add to cart
38	WAY 3 Part #: 90413-06031-00 Required per assembly: 2 $9.49 $8.06 - + Add to cart
39	CLIP Part #: 90467-100A1-00 Required per assembly: 6 $8.49 $6.27 - + Add to cart
40	CLAMP Part #: 90464-20025-00 Required per assembly: 1 $2.39 $2.00 - + Add to cart
41	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-04006-00 Required per assembly: 3 $3.20 $2.66 - + Add to cart
42	CLIP Part #: 90467-100A1-00 Required per assembly: 1 $8.49 $6.27 - + Add to cart
43	SOLENOID VALVE ASSEMBLY Part #: BG4-86120-00-00 Required per assembly: 1 $52.99 $44.33 - + Add to cart
44	NUT, FLANGE, (7NB) Part #: 95780-06500-00 Required per assembly: 1 $2.95 $1.87 - + Add to cart
