Front Fork replacement parts for 2020 Yamaha YZFR1

OEM Parts Yamaha 2020 Yamaha YZFR1 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: B3L-23102-00-00 Required per assembly: 1 ~~$1,046.99~~ $1,022.97 - + Add to cart
2	INNER TUBE COMP.1 Part #: B3L-23110-00-00 Required per assembly: 1 $268.86 - + Add to cart
3	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 ~~$26.98~~ $22.35 - + Add to cart
4	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $11.30 - + Add to cart
5	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 ~~$28.98~~ $22.96 - + Add to cart
6	WASHER, OIL, SEAL Part #: 5PW-23146-00-00 Required per assembly: 1 ~~$19.98~~ $19.23 - + Add to cart
7	METAL, SLIDE, 1 Part #: 2CR-23125-00-00 Required per assembly: 1 ~~$12.99~~ $12.34 - + Add to cart
8	PISTON, FRONT, FORK Part #: 2CR-23171-00-00 Required per assembly: 1 ~~$30.98~~ $24.54 - + Add to cart
9	TUBE, OUTER, 2 Part #: 2CR-23136-10-00 Required per assembly: 1 ~~$373.99~~ $336.65 - + Add to cart
10	CYLINDER, COMP, FRONT, FORK Part #: B3L-23170-00-00 Required per assembly: 1 ~~$337.99~~ $332.08 - + Add to cart
11	VALVE COMP. Part #: B3L-2316A-00-00 Required per assembly: 1 ~~$185.99~~ $173.91 - + Add to cart
12	O-RING Part #: B3L-23147-00-00 Required per assembly: 1 $3.42 - + Add to cart
13	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $8.63 - + Add to cart
14	SPRING, FRONT, FORK Part #: BN6-23141-00-00 Required per assembly: 1 ~~$31.98~~ $27.25 - + Add to cart
15	SPACER Part #: 2CR-23118-00-00 Required per assembly: 1 $13.19 - + Add to cart
16	GUIDE, SPRING Part #: 2CR-23117-00-00 Required per assembly: 1 $13.55 - + Add to cart
17	BOLT, CAP Part #: 2CR-23111-10-00 Required per assembly: 1 ~~$322.99~~ $291.98 - + Add to cart
18	O-RING Part #: 39P-23147-00-00 Required per assembly: 1 ~~$9.49~~ $9.22 - + Add to cart
19	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
20	FRONT FORK ASSEMBLY (R.H) Part #: B3L-23103-00-00 Required per assembly: 1 ~~$1,046.99~~ $1,022.97 - + Add to cart
21	INNER TUBE COMP.2 Part #: B3L-23120-00-00 Required per assembly: 1 $266.82 - + Add to cart
22	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 ~~$26.98~~ $22.35 - + Add to cart
23	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $11.30 - + Add to cart
24	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 ~~$28.98~~ $22.96 - + Add to cart
25	WASHER, OIL, SEAL Part #: 5PW-23146-00-00 Required per assembly: 1 ~~$19.98~~ $19.23 - + Add to cart
26	METAL, SLIDE, 1 Part #: 2CR-23125-00-00 Required per assembly: 1 ~~$12.99~~ $12.34 - + Add to cart
27	PISTON, FRONT, FORK Part #: 2CR-23171-00-00 Required per assembly: 1 ~~$30.98~~ $24.54 - + Add to cart
28	TUBE, OUTER, 2 Part #: 2CR-23136-10-00 Required per assembly: 1 ~~$373.99~~ $336.65 - + Add to cart
29	CYLINDER, COMP, FRONT, FORK Part #: B3L-23170-00-00 Required per assembly: 1 ~~$337.99~~ $332.08 - + Add to cart
30	VALVE COMP. Part #: B3L-2316A-00-00 Required per assembly: 1 ~~$185.99~~ $173.91 - + Add to cart
31	O-RING Part #: B3L-23147-00-00 Required per assembly: 1 $3.42 - + Add to cart
32	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $8.63 - + Add to cart
33	SPRING, FRONT, FORK Part #: BN6-23141-00-00 Required per assembly: 1 ~~$31.98~~ $27.25 - + Add to cart
34	SPACER Part #: 2CR-23118-00-00 Required per assembly: 1 $13.19 - + Add to cart
35	GUIDE, SPRING Part #: 2CR-23117-00-00 Required per assembly: 1 $13.55 - + Add to cart
36	BOLT, CAP Part #: 2CR-23111-10-00 Required per assembly: 1 ~~$322.99~~ $291.98 - + Add to cart
37	O-RING Part #: 39P-23147-00-00 Required per assembly: 1 ~~$9.49~~ $9.22 - + Add to cart
38	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
39	PROTECTOR Part #: 5PW-23472-00-00 Required per assembly: 1 ~~$16.48~~ $14.83 - + Add to cart
40	UNDER BRACKET COMP. Part #: B3L-23340-00-00 Required per assembly: 1 ~~$566.99~~ $545.95 - + Add to cart
41	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 ~~$26.98~~ $23.44 - + Add to cart
42	BEARING Part #: 93399-99957-00 Required per assembly: 1 ~~$76.98~~ $63.61 - + Add to cart
43	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08030-00 Required per assembly: 4 $3.25 - + Add to cart
44	FORK SEALS KIT Part #: 4PU-W003B-00-00 Required per assembly: 1 ~~$47.99~~ $43.27 - + Add to cart
