Windshield replacement parts for 2020 Yamaha YZFR3 ABS

OEM Parts Yamaha 2020 Yamaha YZFR3 ABS Windshield

WINDSHIELD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WINDSHIELD Part #: BS7-F8381-00-00 Required per assembly: 1 $56.12 - + Add to cart
2	NUT, SPEC'L, SHAPE Part #: 90179-05523-00 Required per assembly: 4 Note: Sold in multiples of 5 only $7.73 - + Add to cart
3	BODY, FRONT, UPPER, 1 Part #: BS7-F835G-00-00 Required per assembly: 1 $109.39 - + Add to cart
4	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 4 $2.82 - + Add to cart
5	GROMMET Part #: 90480-13014-00 Required per assembly: 1 ~~$9.49~~ $9.16 - + Add to cart
6	DAMPER, PLATE Part #: 90520-07808-00 Required per assembly: 2 $0.54 - + Add to cart
7	BODY COWLING SUB A Part #: BS7-XF83F-10-P1 Required per assembly: 1 $60.38 - + Add to cart
7	BODY COWLING SUB A Part #: BS7-XF83F-10-P5 Required per assembly: 1 $70.16 - + Add to cart
7	BODY COWLING SUB ASSEMBLY Part #: BS7-XF83F-30-P0 Required per assembly: 1 $80.94 - + Add to cart
8	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 4 ~~$5.59~~ $4.65 - + Add to cart
9	DAMPER, PLATE Part #: 90520-07808-00 Required per assembly: 2 $0.54 - + Add to cart
10	SEAL (31B1) Part #: 31B-F8307-00-00 Required per assembly: 6 $3.16 - + Add to cart
11	TRIM Part #: 1WD-F8376-00-00 Required per assembly: 4 $3.50 - + Add to cart
12	SEAL 2 Part #: 1WD-F414E-00-00 Required per assembly: 4 $3.50 - + Add to cart
13	GRAPHIC 1 Part #: BS7-F8391-70-00 Required per assembly: 1 $1.83 - + Add to cart
14	GRAPHIC 2 Part #: BS7-F8392-70-00 Required per assembly: 1 $2.46 - + Add to cart
15	GRAPHIC 3 Part #: B8P-F8393-00-00 Required per assembly: 1 ~~$0.50~~ $0.31 - + Add to cart
16	SCREW, ROUND, HEAD Part #: 90150-05023-00 Required per assembly: 4 $3.92 - + Add to cart
17	WASHER, PLATE Part #: 90202-05088-00 Required per assembly: 4 $10.18 - + Add to cart
18	PANEL, INNER, 4 Part #: BS7-F836N-00-00 Required per assembly: 1 $27.01 - + Add to cart
19	RIVET Part #: 90269-06816-00 Required per assembly: 3 $2.05 - + Add to cart
20	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05003-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
21	DAMPER, LEG, SHIELD Part #: BS7-F8327-00-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
22	PANEL, INNER, 5 Part #: BS7-F836R-00-00 Required per assembly: 1 $24.43 - + Add to cart
23	RIVET Part #: 90269-06816-00 Required per assembly: 3 $2.05 - + Add to cart
24	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05003-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
25	DAMPER, LEG, SHIELD Part #: BS7-F8327-00-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
26	STAY 1 Part #: BS7-F8356-00-00 Required per assembly: 1 $54.22 - + Add to cart
27	BOLT, FLANGE Part #: 95817-08035-00 Required per assembly: 2 ~~$10.49~~ $8.93 - + Add to cart
28	REAR VIEW MIRROR ASSEMBLY (LEFT) Part #: BS7-F6280-00-00 Required per assembly: 1 $69.29 - + Add to cart
29	REAR VIEW MIRROR ASSEMBLY (RIGHT) Part #: BS7-F6290-00-00 Required per assembly: 1 $107.77 - + Add to cart
30	PLATE, RUBBER, 1, (BK61) Part #: BK6-F8483-00-00 Required per assembly: 2 $1.77 - + Add to cart
31	PLATE, RUBBER, 2 Part #: BS7-F8484-00-00 Required per assembly: 1 $17.02 - + Add to cart
32	PLATE, RUBBER, 3 Part #: BS7-F8485-00-00 Required per assembly: 1 $7.38 - + Add to cart
33	BOLT, HEXAGON, SOCKET, HEAD, (1VJ) Part #: 90110-06138-00 Required per assembly: 4 ~~$6.49~~ $5.30 - + Add to cart
34	COLLAR Part #: 90387-06131-00 Required per assembly: 4 ~~$8.49~~ $8.40 - + Add to cart
35	PLUG Part #: 90338-05010-00 Required per assembly: 4 ~~$9.49~~ $8.44 - + Add to cart
36	LABEL, NOTICE, WINDSHIELD, 1 Part #: 1WD-F815K-10-00 Required per assembly: 1 $1.50 - + Add to cart
