OEM Parts Honda 2021 Honda CT125A Switch - Cable - Mirror

2021 Honda CT125A Trail 125 - Switch - Cable - Mirror

SWITCH - CABLE - MIRROR Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 04
001

CABLE, A, THROTTLE

Part #: 17910-K2E-T01 Required per assembly: 1
$15.25
$13.15
-
+
Add to cart
002

CABLE, B, THROTTLE

Part #: 17920-K2E-T01 Required per assembly: 1
$12.75
$10.98
-
+
Add to cart
003

SWITCH, ASSEMBLY, ENGINE, STOP

Part #: 35130-K2E-T01 Required per assembly: 1
$59.13
$51.68
-
+
Add to cart
004

SWITCH, ASSEMBLY, DIMMER, &, HORN, &, TURN, SIGNAL

Part #: 35200-K2E-T01 Required per assembly: 1
$59.78
$52.39
-
+
Add to cart
005

GRIP, THROTTLE

Part #: 53140-K2E-T00 Required per assembly: 1
$11.91
$10.00
-
+
Add to cart
006

GRIP, L., HANDLE

Part #: 53166-K2E-T00 Required per assembly: 1
$8.05
$6.92
-
+
Add to cart
007

HOLDER, BACK, MIRROR

Part #: 53173-K2E-T00 Required per assembly: 1
$12.69
$11.40
-
+
Add to cart
008

CAP, LOCK, NUT

Part #: 88119-KWW-640 Required per assembly: 2
$2.65
$2.46
-
+
Add to cart
009

MIRROR *NH303M*(MAT AXIS GRAY METALLIC)

Part #: 88210-K2E-T01ZA Required per assembly: 2
$18.55
$14.79
-
+
Add to cart
010

BOLT, FLANGE, (6X28)

Part #: 90013-GHB-680 Required per assembly: 1
$2.06
$1.90
-
+
Add to cart
011

BOLT, ADAPTER, (10MM)

Part #: 90101-KWW-640 Required per assembly: 2
$3.27
$3.04
-
+
Add to cart
012

NUT, HEX., (10MM)

Part #: 90301-KWW-640 Required per assembly: 2
$2.07
$1.99
-
+
Add to cart
013

BAND, WIRE

Part #: 90650-KW3-000 Required per assembly: 4
$5.39
$4.85
-
+
Add to cart
014

SCREW-WASHER (5X20)

Part #: 93892-05020-07 Required per assembly: 4
$1.90
$1.75
-
+
Add to cart
