Shift Drum - Shift Fork (Dct) replacement parts for 2021 Honda GL1800DA

OEM Parts Honda 2021 Honda GL1800DA Shift Drum - Shift Fork (Dct)

SHIFT DRUM - SHIFT FORK (DCT) Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

E 2010
001	HOLDER, TRANSMISSION Part #: 11130-MKC-A00 Required per assembly: 1 $194.88 $157.75 - + Add to cart
002	GASKET, TRANSMISSION, HOLDER Part #: 11135-MKC-A01 Required per assembly: 1 $19.78 $16.01 - + Add to cart
003	DAMPER, A, BEARING Part #: 11370-MKC-A00 Required per assembly: 1 $68.39 $55.36 - + Add to cart
004	FORK, FR., MAINSHAFT, GEARSHIFT Part #: 24211-MKC-A00 Required per assembly: 1 $68.56 $55.51 - + Add to cart
005	SWINGARM, MAINSHAFT, GEARSHIFT Part #: 24212-MKC-A00 Required per assembly: 1 $68.56 $55.51 - + Add to cart
006	FORK, FR., COUNTERSHAFT, GEARSHIFT Part #: 24213-MKC-A00 Required per assembly: 1 $71.66 $58.00 - + Add to cart
007	SWINGARM, COUNTERSHAFT, GEARSHIFT Part #: 24214-MKC-A00 Required per assembly: 1 $71.66 $58.00 - + Add to cart
008	SHAFT, ASSEMBLY, SHIFT, FORK Part #: 24250-MKC-A00 Required per assembly: 2 $37.92 $30.70 - + Add to cart
009	DRUM, ASSEMBLY, GEARSHIFT Part #: 24300-MKC-A00 Required per assembly: 1 $379.96 $307.56 - + Add to cart
010	SHIFTER, DRUM Part #: 24321-MEB-670 Required per assembly: 1 $39.97 $32.35 - + Add to cart
011	COLLAR, SHIFTER Part #: 24322-MM4-000 Required per assembly: 1 $6.15 $5.47 - + Add to cart
012	PAWL, A, RATCHET Part #: 24324-MKC-A00 Required per assembly: 1 $9.32 $8.05 - + Add to cart
013	PAWL, B, RATCHET Part #: 24325-MKC-A00 Required per assembly: 1 $9.32 $8.05 - + Add to cart
014	PLUNGER, PAWL Part #: 24326-KBH-901 Required per assembly: 2 $6.98 $6.16 - + Add to cart
015	PLATE, CHANGE, GUIDE Part #: 24328-MKC-A00 Required per assembly: 1 $15.67 $12.69 - + Add to cart
016	SPRING, PAWL, PLUNGER Part #: 24329-KA3-740 Required per assembly: 2 $3.60 - + Add to cart
017	STOPPER, GEARSHIFT, DRUM Part #: 24430-MKC-A00 Required per assembly: 1 $16.63 $13.47 - + Add to cart
018	SPRING, SHIFT, DRUM, STOPPER Part #: 24436-MKC-A20 Required per assembly: 1 $5.28 $5.26 - + Add to cart
019	SPINDLE, GEARSHIFT Part #: 24610-MKC-A00 Required per assembly: 1 $97.03 $78.55 - + Add to cart
020	GEAR, SHIFT, REDUCTION, (51T) Part #: 24617-MKC-A01 Required per assembly: 1 $64.48 $52.19 - + Add to cart
021	SPRING, SHIFT, RETURN Part #: 24651-MKC-A00 Required per assembly: 1 $11.13 $9.50 - + Add to cart
022	PIN, RETURN, SPRING Part #: 24652-MKC-A00 Required per assembly: 1 $7.29 $6.40 - + Add to cart
023	PLATE, SHIFT, DRUM, BEARING, SETTING Part #: 24656-MKC-A00 Required per assembly: 1 $5.91 $5.29 - + Add to cart
024	BOLT, OIL, PASSAGE Part #: 90010-MKC-A00 Required per assembly: 1 $11.04 $9.43 - + Add to cart
025	PIVOT, SHIFT, DRUM, STOPPER, ARM Part #: 90022-MKC-A00 Required per assembly: 1 $4.00 - + Add to cart
026	BOLT, FLANGE, (8X30) Part #: 90078-MKC-A00 Required per assembly: 5 $3.55 - + Add to cart
027	BOLT (6X22) Part #: 90088-HP1-670 Required per assembly: 2 $2.44 $2.26 - + Add to cart
028	WASHER, DRUM, STOPPER Part #: 90417-360-000 Required per assembly: 1 $2.73 $2.54 - + Add to cart
029	PIN, DOWEL, (8X8) Part #: 90702-MB0-000 Required per assembly: 2 $4.80 $4.36 - + Add to cart
030	BEARING (12X18X12) Part #: 91024-MGS-D21 Required per assembly: 1 $4.64 - + Add to cart
031	BEARING (607ZZ) Part #: 91026-MGS-D21 Required per assembly: 1 $10.67 $9.14 - + Add to cart
032	BEARING, SHELL, NEEDLE, (10X13), (4X15) Part #: 91105-KZR-601 Required per assembly: 1 $10.70 $9.17 - + Add to cart
033	PIN, DOWEL, (10X16) Part #: 94303-10160 Required per assembly: 2 $3.18 - + Add to cart
034	CIRCLIP (11MM) Part #: 94510-11000 Required per assembly: 1 $1.78 $1.64 - + Add to cart
035	BOLT, FLANGE, (6X16) Part #: 95701-06016-00 Required per assembly: 2 Note: 95701-06016-08* $2.63 $2.44 - + Add to cart
