Shift Lever - Select Lever replacement parts for 2021 Honda SXS1000M5L

OEM Parts Honda 2021 Honda SXS1000M5L Shift Lever - Select Lever

SHIFT LEVER - SELECT LEVER Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 13
001	CABLE, FINAL, CLUTCH Part #: 41490-HL4-A01 Required per assembly: 1 ~~$9.49~~ $8.42 - + Add to cart
002	SPRING, CLUTCH, CABLE Part #: 41491-HL1-A00 Required per assembly: 1 ~~$2.22~~ $2.06 - + Add to cart
003	NUT, ADJUSTING Part #: 41560-HP5-600 Required per assembly: 1 ~~$8.03~~ $7.01 - + Add to cart
004	SPRING, CLUTCH, CABLE Part #: 41571-HP5-600 Required per assembly: 1 ~~$3.18~~ $2.96 - + Add to cart
005	CLIP, CLUTCH, CABLE Part #: 41573-HP5-600 Required per assembly: 5 ~~$4.68~~ $4.25 - + Add to cart
006	CASE, SELECTOR Part #: 41717-HL4-A00 Required per assembly: 1 ~~$86.90~~ $72.47 - + Add to cart
007	COVER, SELECTOR Part #: 41718-HL4-A00 Required per assembly: 1 ~~$7.78~~ $6.87 - + Add to cart
008	SPRING, SELECTOR Part #: 41722-HL4-A00 Required per assembly: 2 ~~$9.97~~ $9.06 - + Add to cart
009	CABLE, C, RR. Part #: 41723-HL4-A01 Required per assembly: 1 ~~$8.95~~ $7.97 - + Add to cart
010	NUT Part #: 41724-HL4-A00 Required per assembly: 1 $3.15 - + Add to cart
011	ARM, SELECTOR Part #: 41813-HL4-A00 Required per assembly: 1 ~~$34.65~~ $30.96 - + Add to cart
012	TUBE, SELECTOR, CASE Part #: 41817-HL4-A00 Required per assembly: 1 ~~$2.75~~ $2.55 - + Add to cart
013	LEVER, DRIVE, SELECT Part #: 54010-HL4-A00 Required per assembly: 1 ~~$21.53~~ $18.11 - + Add to cart
014	ARM, MODE, SELECT Part #: 54021-HL4-A00 Required per assembly: 1 ~~$32.65~~ $27.22 - + Add to cart
015	GRIP NH1 (BLACK) Part #: 54050-HL1-A00ZA Required per assembly: 1 ~~$15.23~~ $12.70 - + Add to cart
016	GRIP NH1 (BLACK) Part #: 54050-HL3-A00ZA Required per assembly: 1 ~~$6.33~~ $5.84 - + Add to cart
018	LINK, RR. Part #: 54065-HL4-A00 Required per assembly: 1 ~~$12.00~~ $10.01 - + Add to cart
019	CABLE, ASSEMBLY, SHIFT Part #: 54310-HL4-A01 Required per assembly: 1 $45.58 - + Add to cart
020	ARM, SHIFT, CHANGE Part #: 54312-HL4-A00 Required per assembly: 1 ~~$15.85~~ $12.64 - + Add to cart
022	CABLE, A, RR. Part #: 54317-HL4-A01 Required per assembly: 1 ~~$13.24~~ $11.03 - + Add to cart
023	CABLE, B, RR. Part #: 54318-HL4-A01 Required per assembly: 1 ~~$25.02~~ $20.85 - + Add to cart
024	PLATE, SHIFT, CHANGE Part #: 54320-HL4-A00 Required per assembly: 1 ~~$27.04~~ $23.06 - + Add to cart
025	SPRING, SELECT, LEVER Part #: 54324-HN7-000 Required per assembly: 2 ~~$5.57~~ $5.06 - + Add to cart
026	LEVER, SHIFT, CHANGE Part #: 54325-HL4-A00 Required per assembly: 1 ~~$87.20~~ $79.27 - + Add to cart
027	BUSH (8.1X6.2) Part #: 54326-HL1-A00 Required per assembly: 2 ~~$2.07~~ $1.91 - + Add to cart
028	GATE, SHIFT Part #: 54335-HL4-F40 Required per assembly: 1 ~~$13.87~~ $11.54 - + Add to cart
029	BOLT, SPECIAL, (6MM) Part #: 90107-HL4-A00 Required per assembly: 4 ~~$1.40~~ $1.28 - + Add to cart
030	BOLT, CHANGE, PIVOT Part #: 90115-MAL-600 Required per assembly: 2 ~~$17.18~~ $14.33 - + Add to cart
031	BOLT, FLANGE, (6X20) Part #: 90118-968-000 Required per assembly: 1 ~~$5.63~~ $5.12 - + Add to cart
032	SCREW, PAN, (6X14) Part #: 90118-MBV-000 Required per assembly: 3 ~~$2.88~~ $2.68 - + Add to cart
033	BOLT, WASHER, (8X12) Part #: 90150-HL4-F00 Required per assembly: 1 ~~$1.90~~ $1.75 - + Add to cart
034	NUT, FLG, (M8X1.25) Part #: 90309-428-731 Required per assembly: 1 ~~$4.68~~ $4.25 - + Add to cart
035	CLAMP, HARNESS Part #: 90652-HC4-003 Required per assembly: 3 ~~$7.16~~ $6.81 - + Add to cart
036	STRAP, CABLE, (105MM) Part #: 90672-SB2-003 Required per assembly: 1 ~~$5.75~~ $5.58 - + Add to cart
037	O-RING (10X2) Part #: 91304-HA5-003 Required per assembly: 3 ~~$5.29~~ $4.81 - + Add to cart
038	GASKET, SELECTOR Part #: 91352-HL4-A00 Required per assembly: 1 ~~$1.90~~ $1.75 - + Add to cart
039	CAP, FR., WIPER, ARM, (12MM) Part #: 91611-SDA-A00 Required per assembly: 1 ~~$2.99~~ $2.78 - + Add to cart
040	BOLT-WASHER (8X12) Part #: 93406-08012-08 Required per assembly: 2 ~~$2.86~~ $2.65 - + Add to cart
041	NUT, FLANGE, (6MM) Part #: 94050-06000 Required per assembly: 1 ~~$1.73~~ $1.59 - + Add to cart
042	WASHER, PLAIN, (6MM) Part #: 94101-06800 Required per assembly: 2 Not Available
043	PIN, SPLIT, (2.0) Part #: 94201-20151 Required per assembly: 2 ~~$1.60~~ $1.46 - + Add to cart
044	CLIP, TUBE, (C6.5) Part #: 95002-35000 Required per assembly: 1 ~~$1.80~~ $1.67 - + Add to cart
045	JOINT, B, BRAKE, ARM Part #: 95015-32001 Required per assembly: 4 ~~$1.98~~ $1.83 - + Add to cart
046	NUT B Part #: 95015-42000 Required per assembly: 2 ~~$2.90~~ $2.70 - + Add to cart
047	BOLT, FLANGE, (6X16) Part #: 95701-06016-00 Required per assembly: 2 Note: 95701-06016-08* ~~$2.63~~ $2.44 - + Add to cart
048	BOLT, FLANGE, (6X35) Part #: 95701-06035-00 Required per assembly: 2 ~~$2.87~~ $2.67 - + Add to cart
