Rear Final Gear replacement parts for 2021 Honda SXS1000S2X

OEM Parts Honda 2021 Honda SXS1000S2X Rear Final Gear

REAR FINAL GEAR Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 3810
001	BEARING, SET, NEEDLE Part #: 06911-HL4-A00 Required per assembly: 1 ~~$27.64~~ $23.30 - + Add to cart
002	CAP, VALVE, ADJ. Part #: 12361-300-000 Required per assembly: 1 Not Available
003	STAY, HARNESS, CLIP Part #: 30535-HL6-A00 Required per assembly: 1 ~~$1.94~~ $1.78 - + Add to cart
004	SENSOR, RR., WHEEL, SPEED Part #: 38510-HL6-A01 Required per assembly: 1 ~~$135.36~~ $112.87 - + Add to cart
005	GEAR, ASSEMBLY, RR., FINAL, (FOR, 91055-HL6-A01) Part #: 41300-HL6-A01 Required per assembly: 1 ~~$760.35~~ $729.41 - + Add to cart
005	GEAR, ASSEMBLY, RR., FINAL, (FOR, 91051-HL6-A41) Part #: 41300-HL6-A40 Required per assembly: 1 ~~$1,027.93~~ $947.14 - + Add to cart
006	RING, STOPPER Part #: 41305-HL4-A00 Required per assembly: 1 ~~$2.60~~ $2.36 - + Add to cart
007	CASE, SUB-ASSEMBLY, RR., FINAL, GEAR Part #: 41311-HL6-A01 Required per assembly: 1 ~~$179.00~~ $142.75 - + Add to cart
008	COVER, SUB-ASSEMBLY, RR., FINAL, GEAR Part #: 41312-HL6-A01 Required per assembly: 1 ~~$122.38~~ $100.05 - + Add to cart
009	JOINT, RR., PINION Part #: 41330-HL6-A01 Required per assembly: 1 ~~$41.71~~ $34.61 - + Add to cart
010	GEAR, RR., PINION, (13T) Part #: 41421-HL6-A01 Required per assembly: 1 ~~$153.65~~ $122.54 - + Add to cart
011	GEAR, RR., RING, (46T) Part #: 41430-HL6-A01 Required per assembly: 1 ~~$349.51~~ $312.50 - + Add to cart
012	PIN Part #: 41436-MB0-310 Required per assembly: 1 ~~$34.86~~ $28.22 - + Add to cart
013	SHIM A (0.10) Part #: 41437-MB0-310 Required per assembly: 1 ~~$6.18~~ $5.50 - + Add to cart
013	SHIM B (0.15) Part #: 41438-MB0-310 Required per assembly: 1 ~~$6.18~~ $5.50 - + Add to cart
014	SHIM A (0.64) Part #: 41447-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM B (0.70) Part #: 41448-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM C (0.76) Part #: 41449-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM D (0.82) Part #: 41450-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM E (0.88) Part #: 41451-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM F (0.94) Part #: 41452-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM G (1.00) Part #: 41453-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM H (1.06) Part #: 41454-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM I (1.12) Part #: 41455-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM J (1.18) Part #: 41456-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM K (1.24) Part #: 41457-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM L (1.30) Part #: 41458-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM M (1.36) Part #: 41459-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM N (1.42) Part #: 41460-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM O (1.48) Part #: 41461-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM P (1.54) Part #: 41462-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
014	SHIM Q (1.60) Part #: 41463-HL4-A00 Required per assembly: 2 $3.41 - + Add to cart
015	SHIM A (1.32) Part #: 41450-MEC-000 Required per assembly: 1 ~~$6.25~~ $5.49 - + Add to cart
015	SHIM C (1.44) Part #: 41452-MEC-000 Required per assembly: 1 ~~$5.99~~ $5.27 - + Add to cart
015	SHIM D (1.50) Part #: 41453-MEC-000 Required per assembly: 1 ~~$5.99~~ $5.27 - + Add to cart
015	SHIM B (1.38) Part #: 41451-MEC-000 Required per assembly: 1 ~~$5.99~~ $5.27 - + Add to cart
015	SHIM G (1.68) Part #: 41456-MEC-000 Required per assembly: 1 ~~$5.99~~ $5.27 - + Add to cart
015	SHIM F (1.62) Part #: 41455-MEC-000 Required per assembly: 1 ~~$5.99~~ $5.27 - + Add to cart
015	SHIM E (1.56) Part #: 41454-MEC-000 Required per assembly: 1 ~~$5.99~~ $5.27 - + Add to cart
016	SPACER, RR., FINAL Part #: 41531-HL6-A00 Required per assembly: 1 ~~$5.82~~ $5.33 - + Add to cart
017	BOLT, SEALING, (8MM) Part #: 90109-371-000 Required per assembly: 2 ~~$3.73~~ $3.39 - + Add to cart
018	BOLT, FLANGE, (10X161) Part #: 90119-HL6-A00 Required per assembly: 1 $4.41 - + Add to cart
019	BOLT, FLANGE, (10X142) Part #: 90120-HL6-A00 Required per assembly: 1 $4.34 - + Add to cart
020	BOLT, FLANGE, (8X27) Part #: 90133-HP5-600 Required per assembly: 6 ~~$3.70~~ $3.36 - + Add to cart
021	BOLT, FLANGE, (10X35) Part #: 90134-HP5-600 Required per assembly: 2 ~~$4.85~~ $4.41 - + Add to cart
022	BOLT, PINION, JOINT Part #: 90138-MFR-670 Required per assembly: 1 ~~$20.39~~ $17.01 - + Add to cart
023	BOLT, FLANGE, (10X30) Part #: 90161-T2F-A01 Required per assembly: 2 ~~$2.32~~ $2.15 - + Add to cart
024	NUT, LOCK, (75MM) Part #: 90242-MCH-000 Required per assembly: 1 ~~$26.50~~ $21.46 - + Add to cart
025	NUT (10MM) Part #: 90305-HC0-770 Required per assembly: 2 ~~$4.30~~ $3.91 - + Add to cart
026	GASKET (8MM) Part #: 90471-580-000 Required per assembly: 2 $3.96 - + Add to cart
027	WASHER (16.2X32X2.0) Part #: 90501-HL6-A00 Required per assembly: 1 $4.12 - + Add to cart
028	WASHER (31X40X2.6) Part #: 90512-HL6-A00 Required per assembly: 1 ~~$8.30~~ $7.23 - + Add to cart
029	JOINT, BREATHER, TUBE Part #: 90652-HF7-003 Required per assembly: 1 ~~$11.04~~ $9.43 - + Add to cart
030	CLIP, CABLE Part #: 90682-MGS-D41 Required per assembly: 2 $3.96 - + Add to cart
031	BEARING, BALL, (40X75X16) Part #: 91003-RY0-003 Required per assembly: 2 ~~$37.88~~ $34.45 - + Add to cart
032	BEARING, RADIAL, BALL, (30X72X19), (CCTY) Part #: 91051-HL6-A41 Required per assembly: 1 ~~$29.36~~ $26.69 - + Add to cart
032	BEARING, RADIAL, BALL, (30X72X19), (SCHAEFFLER) Part #: 91055-HL6-A01 Required per assembly: 1 ~~$67.87~~ $56.70 - + Add to cart
033	OIL SEAL (37.1X57X7) Part #: 91258-HL6-A01 Required per assembly: 2 ~~$8.20~~ $7.21 - + Add to cart
034	OIL SEAL (40.5X79X10) Part #: 91259-HL6-A02 Required per assembly: 1 ~~$13.31~~ $10.89 - + Add to cart
035	O-RING (30.8MM) Part #: 91302-001-020 Required per assembly: 1 ~~$4.74~~ $4.31 - + Add to cart
036	O-RING (1.5X9.5) Part #: 91306-MG3-000 Required per assembly: 1 ~~$3.29~~ $3.06 - + Add to cart
037	O-RING (24X3) Part #: 91312-KM9-003 Required per assembly: 1 ~~$4.39~~ $3.44 - + Add to cart
038	PIN, DOWEL, (6X10) Part #: 94301-06100 Required per assembly: 1 ~~$3.21~~ $2.99 - + Add to cart
039	CLIP, TUBE, (B6.5) Part #: 95002-02650 Required per assembly: 1 ~~$2.49~~ $2.31 - + Add to cart
040	BULK HOSE (3.5X8000) Part #: 95005-35008-10M Required per assembly: 1 ~~$148.30~~ $140.69 - + Add to cart
041	BOLT, FLANGE, (6X14) Part #: 96001-06014-00 Required per assembly: 3 ~~$2.79~~ $2.60 - + Add to cart
