Stator Cover And Flywheel replacement parts for 2021 Polaris Sportsman 450 HO (R03)

OEM Parts Polaris 2021 Polaris Sportsman 450 HO (R03) Stator Cover And Flywheel

STATOR COVER and FLYWHEEL Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WASHER-19X34X3, HARD Part #: 7556878 Required per assembly: 1 Currently Not Available
2	ASM-IGNITION COVER Part #: 3023796 Required per assembly: 1 Note: INCL. 8,18 Currently Not Available
3	FLYWHEEL Part #: 4018939 Required per assembly: 1 Currently Not Available
4	BEARING-SHAFT WATERPUMP Part #: 3514696 Required per assembly: 1 Currently Not Available
5	SEAL-WATERPUMP SHAFT WATER Part #: 3610173 Required per assembly: 1 Currently Not Available
6	STATOR-660W W/CPS Part #: 4018938 Required per assembly: 1 Currently Not Available
7	SHAFT, PUMP, DRIVE Part #: 5138035 Required per assembly: 1 Currently Not Available
8	BEARING-BALL 9X24X7 Part #: 3514717 Required per assembly: 1 Currently Not Available
9	SEAL, TYPE, S Part #: 5411197 Required per assembly: 1 Currently Not Available
10	SCREW Part #: 7510005 Required per assembly: 3 Currently Not Available
11	SCR-SH-M5X0.8X16 8.8 SPC P30 Part #: 7521228 Required per assembly: 2 Currently Not Available
12	SCREW Part #: 7518576 Required per assembly: 15 Currently Not Available
13	GASKET-STATOR, COVER, SILICONE Part #: 5415086 Required per assembly: 1 Currently Not Available
14	NUT-HEX M18X1.5 4 JAM RH Part #: 7547488 Required per assembly: 1 ~~$6.99~~ $4.03 - + Add to cart
15	ASM-COVER, ENGINE, INTER, MAG Part #: 3023795 Required per assembly: 1 Currently Not Available
16	PIN, DOWEL Part #: 5132835 Required per assembly: 1 Currently Not Available
17	GASKET, MAG/INTER, COVER Part #: 5415085 Required per assembly: 1 Currently Not Available
18	RING-SNAP DIN472 24X1.2MM Part #: 7710654 Required per assembly: 1 Currently Not Available
19	SCR-HXFL-M6X1.0X45 8.8 ZY3D204 Part #: 7519209 Required per assembly: 1 Currently Not Available
20	PLUG-HEX, SCKT, W/O-RING, M14X1.5 Part #: 7052641 Required per assembly: 1 Currently Not Available
