Electrical (E03,E28) replacement parts for 2021 Suzuki GSX-R600

OEM Parts Suzuki 2021 Suzuki GSX R600 Electrical (E03,E28)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	RELAY, ASSEMBLY, STARTING, MOTOR Part #: 31800-06G02 Required per assembly: 1 $83.16 $71.09 - + Add to cart
2	FUSE, 30A Part #: 09481-30101 Required per assembly: 2 $2.75 $2.48 - + Add to cart
3	COVER Part #: 31861-47E00 Required per assembly: 1 Note: COVER, RELAY ASSY; $17.46 $14.92 - + Add to cart
4	SCREW Part #: 09128-06013 Required per assembly: 2 Note: BOLT, STG MOT TERM; $1.50 $1.35 - + Add to cart
5	RECTIFIER ASSEMBLY Part #: 32800-47H00 Required per assembly: 1 $338.10 $289.06 - + Add to cart
6	BRACKET, COM, RE Part #: 32830-14J00 Required per assembly: 1 $18.49 $16.64 - + Add to cart
7	SPACER, FUEL, CUT Part #: 09180-06325 Required per assembly: 2 $4.68 $4.21 - + Add to cart
8	CUSHION, RR, COVER Part #: 09320-08066 Required per assembly: 2 Note: CUSHION; $10.34 $9.31 - + Add to cart
9	BOLT Part #: 09116-06182 Required per assembly: 2 Note: BOLT (6X20); $2.64 $2.38 - + Add to cart
10	BOLT Part #: 01550-0616A Required per assembly: 2 $2.37 $2.13 - + Add to cart
11	CLAMP (L:80) Part #: 09404-06030 Required per assembly: 1 Not Available
12	NUT Part #: 08316-1006A Required per assembly: 2 $2.64 $2.38 - + Add to cart
13	COIL, ASSEMBLY, IGNITION Part #: 33410-37H00 Required per assembly: 4 $188.30 $169.47 - + Add to cart
14	CONTROL, UNIT, FI Part #: 32920-14J81 Required per assembly: 1 $1,618.51 $1,456.66 - + Add to cart
15	SENSOR, ASSEMBLY, FUEL, CUT Part #: 33960-27G00 Required per assembly: 1 Note: Tip Over Bank Angle Crash Sensor $118.68 $101.46 - + Add to cart
16	ACTUATOR ASSEMBLY Part #: 33970-47H03 Required per assembly: 1 $452.23 $407.01 - + Add to cart
17	BOLT NO.2 (6X32.5) Part #: 09116-06148 Required per assembly: 2 $3.91 $3.52 - + Add to cart
