2021 Yamaha VX Cruiser with Audio VX1800CW F4S3 - Steering 3

STEERING 3 Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

STEERING PAD COMP

Part #: F4N-U142A-00-00 Required per assembly: 1
$131.56
$103.75
-
+
Add to cart
1

STEERING PAD COMP

Part #: F4N-U142A-10-00 Required per assembly: 1
$104.03
$88.63
-
+
Add to cart
2

PAD, STEERING, 1

Part #: F4N-U143D-00-00 Required per assembly: 1
$92.81
$72.56
-
+
Add to cart
3

PAD, STEERING, 2

Part #: F4N-U143E-00-00 Required per assembly: 1
$92.81
$72.56
-
+
Add to cart
4

COVER, PAD

Part #: F4N-U142D-00-00 Required per assembly: 1
$126.47
$93.73
-
+
Add to cart
5

BASE, PAD

Part #: F4N-U142M-00-00 Required per assembly: 1
$82.60
$63.49
-
+
Add to cart
5

BASE, PAD

Part #: F4N-U142M-10-00 Required per assembly: 1
$82.60
$63.49
-
+
Add to cart
6

SCREW

Part #: F2S-U13C1-00-00 Required per assembly: 3
$7.12
$2.65
-
+
Add to cart
7

NUT

Part #: F3X-U517E-00-00 Required per assembly: 2
$6.11
$1.36
-
+
Add to cart
8

BOLT

Part #: F3Y-U1355-01-00 Required per assembly: 2
$5.08
$2.10
-
+
Add to cart
9

BOLT

Part #: F3Y-U2624-09-00 Required per assembly: 2
$7.12
$2.42
-
+
Add to cart
10

SCREW

Part #: F4N-U13C1-00-00 Required per assembly: 2
$4.07
$2.10
-
+
Add to cart
11

SCREW

Part #: F2S-U13C1-00-00 Required per assembly: 2
$7.12
$2.65
-
+
Add to cart
