OEM Parts Yamaha 2021 Yamaha Wabash Frame

2021 Yamaha Wabash WBASHLCOR X1MV-10A - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

FRAME COMP.

Part #: X1M-F1110-90-P0 Required per assembly: 1
$1,388.16
$1,311.96
-
+
Add to cart
2

BOLT

Part #: X1M-F1531-00-00 Required per assembly: 2
$2.33
$1.47
-
+
Add to cart
3

REAR DERAILLER

Part #: X1M-F535B-20-00 Required per assembly: 1
$462.99
$452.38
-
+
Add to cart
4

BRACKET, DERAILLER, REAR

Part #: X1M-F114D-10-00 Required per assembly: 1
$11.49
$7.92
-
+
Add to cart
5

BRACKET 5

Part #: X1M-F112K-00-00 Required per assembly: 1
$9.49
$7.64
-
+
Add to cart
6

SCREW 2

Part #: X1M-F11C6-00-00 Required per assembly: 2
Not Available
7

BOLT

Part #: X0N-F2125-10-00 Required per assembly: 3
$3.54
$2.34
-
+
Add to cart
8

NUT, SPECIAL

Part #: X0N-F3393-00-00 Required per assembly: 3
$11.49
$8.06
-
+
Add to cart
9

GUIDE, WIRE

Part #: X1M-F1339-00-00 Required per assembly: 2
$3.35
$2.42
-
+
Add to cart
10

SCREW 6

Part #: X1M-F11D3-00-00 Required per assembly: 2
$2.27
$1.30
-
+
Add to cart
11

BRACKET

Part #: X1M-F256L-00-00 Required per assembly: 1
$7.49
$5.03
-
+
Add to cart
12

SCREW 3

Part #: X1M-F11C7-00-00 Required per assembly: 1
$2.39
$1.38
-
+
Add to cart
13

LOCK COMP.

Part #: X1M-H256A-00-00 Required per assembly: 1
$105.98
$83.81
-
+
Add to cart
14

BOLT

Part #: X1M-F1738-00-00 Required per assembly: 1
$3.54
$2.86
-
+
Add to cart
15

SCREW 4

Part #: X1M-F11C8-00-00 Required per assembly: 2
$2.43
$1.69
-
+
Add to cart
16

GROMMET

Part #: X1M-F1719-30-00 Required per assembly: 2
$13.49
$10.27
-
+
Add to cart
17

CLAMP, WIRE, HARNESS

Part #: X0N-F1999-00-00 Required per assembly: 3
$2.87
$2.10
-
+
Add to cart
18

LABEL INFORMATION

Part #: X1M-F11A5-00-00 Required per assembly: 1
$2.20
$1.32
-
+
Add to cart
19

LABEL, CAUTION

Part #: X1M-H4306-00-00 Required per assembly: 1
$2.39
$1.60
-
+
Add to cart
20

LABEL, CAUTION

Part #: X1M-F2298-00-00 Required per assembly: 1
$2.39
$1.51
-
+
Add to cart
21

FORK COMP. 1

Part #: X1M-F3780-90-P0 Required per assembly: 1
$331.20
-
+
Add to cart
22

GUIDE, WIRE

Part #: X0N-F1339-00-00 Required per assembly: 1
$2.33
$1.59
-
+
Add to cart
23

SCREW 6

Part #: X1M-F11D3-00-00 Required per assembly: 1
$2.27
$1.30
-
+
Add to cart
24

STEERING SET

Part #: X0N-F341A-00-00 Required per assembly: 1
$74.98
$62.67
-
+
Add to cart
25

CAP ASSEMBLY

Part #: X0N-F287K-10-00 Required per assembly: 1
$8.49
$5.94
-
+
Add to cart
26

COLLAR 1

Part #: X0N-F3363-00-00 Required per assembly: 2
$7.49
$4.78
-
+
Add to cart
27

COLLAR 2

Part #: X0N-F3364-00-00 Required per assembly: 2
$5.59
$4.05
-
+
Add to cart
28

LABEL, CAUTION

Part #: X1M-F389C-00-00 Required per assembly: 1
$2.39
$1.81
-
+
Add to cart
29

CAP

Part #: X1M-F143A-10-00 Required per assembly: 2
$2.39
$1.09
-
+
Add to cart
30

CAP

Part #: X1M-F1399-00-00 Required per assembly: 1
$7.49
$5.53
-
+
Add to cart
31

CAP

Part #: X1M-F1399-10-00 Required per assembly: 1
$8.49
$5.53
-
+
Add to cart
32

BOLT 2

Part #: X1M-F1532-00-00 Required per assembly: 2
$2.39
$1.56
-
+
Add to cart
33

CRANK SET

Part #: X1M-F781A-10-00 Required per assembly: 1
$66.98
$52.06
-
+
Add to cart
34

PEDAL SET

Part #: X1M-F785A-00-00 Required per assembly: 1
$23.98
$17.96
-
+
Add to cart
