Electrical 2 replacement parts for 2021 Yamaha Tenere 700

OEM Parts Yamaha 2021 Yamaha Tenere 700 Electrical 2

ELECTRICAL 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	SENSOR, PRESSURE Part #: 1WS-82380-00-00 Required per assembly: 1 $209.99 $180.71 - + Add to cart
2	BOLT, SOCKET Part #: 91317-05020-00 Required per assembly: 1 $3.54 $2.43 - + Add to cart
3	IGNITION COIL ASSEMBLY Part #: 1WS-82310-00-00 Required per assembly: 2 $119.98 $101.27 - + Add to cart
4	NEUTRAL SWITCH ASSEMBLY Part #: 1WS-82540-01-00 Required per assembly: 1 $77.98 $65.98 - + Add to cart
5	O-RING Part #: 93210-21001-00 Required per assembly: 1 $6.49 $4.69 - + Add to cart
6	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-05038-00 Required per assembly: 2 $8.49 $6.17 - + Add to cart
7	THERMO UNIT Part #: 52B-H3591-00-00 Required per assembly: 1 $37.99 $28.37 - + Add to cart
8	GASKET Part #: 90430-10004-00 Required per assembly: 1 $7.49 $6.47 - + Add to cart
9	OIL PRESSURE SWITCH ASSEMBLY Part #: 1WS-82504-01-00 Required per assembly: 1 $76.98 $65.92 - + Add to cart
10	LEAD WIRE ASSEMBLY Part #: 1WS-81315-00-00 Required per assembly: 1 $18.98 $15.83 - + Add to cart
11	PLUG, BLIND Part #: 3P6-15399-00-00 Required per assembly: 1 $20.98 $17.43 - + Add to cart
12	O-RING (22U) Part #: 93210-15566-00 Required per assembly: 1 Note: Sold in multiples of 5 only $8.49 $5.67 - + Add to cart
13	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-06016-00 Required per assembly: 1 $6.49 $4.81 - + Add to cart
14	ENGINE CONTROL UNIT ASSEMBLY Part #: BW3-8591A-20-00 Required per assembly: 1 $824.99 $807.73 - + Add to cart
15	BAND Part #: B34-H5546-00-00 Required per assembly: 1 $36.99 $30.39 - + Add to cart
16	WIRE, SUB, LEAD Part #: BW3-H2309-00-00 Required per assembly: 1 $80.98 $69.17 - + Add to cart
17	MAIN SWITCH STEERING LOCK Part #: BAU-82501-00-00 Required per assembly: 1 $248.99 $216.25 - + Add to cart
18	KEY, MAIN, SWITCH Part #: BAU-82511-09-00 Required per assembly: 1 $91.98 $78.25 - + Add to cart
19	BOLT Part #: 90109-08196-00 Required per assembly: 2 $9.49 $6.06 - + Add to cart
20	CAP, SWITCH Part #: 36P-82552-00-00 Required per assembly: 1 $16.48 $12.35 - + Add to cart
21	HOLDER, CONNECTOR Part #: BW3-H8195-01-00 Required per assembly: 1 $32.99 $27.10 - + Add to cart
22	BOLT, WITH, WASHER Part #: 90119-06209-00 Required per assembly: 2 $6.49 $5.35 - + Add to cart
23	COLLAR Part #: 90387-1001B-00 Required per assembly: 1 Not Available
24	COLLAR Part #: 90387-06106-00 Required per assembly: 1 $8.49 $5.32 - + Add to cart
25	CLAMP Part #: 90464-10800-00 Required per assembly: 1 $2.35 $1.21 - + Add to cart
26	CLAMP Part #: 90464-14010-00 Required per assembly: 3 $3.64 $3.05 - + Add to cart
27	CLAMP Part #: 90464-30009-00 Required per assembly: 2 $3.29 $3.24 - + Add to cart
28	CLAMP (4FM) Part #: 90464-15195-00 Required per assembly: 4 $4.41 $2.72 - + Add to cart
29	SENSOR, AIR, TEMPERATURE Part #: 5YU-85886-00-00 Required per assembly: 1 $37.99 $29.56 - + Add to cart
30	CLAMP Part #: 90464-24230-00 Required per assembly: 1 $8.49 $5.50 - + Add to cart
31	CLAMP Part #: 90464-65001-00 Required per assembly: 13 $5.99 $4.97 - + Add to cart
32	TERMINAL COMP. Part #: B56-8254B-01-00 Required per assembly: 1 $319.99 $287.95 - + Add to cart
33	DAMPER, SEAT Part #: 2BS-24747-00-00 Required per assembly: 1 $5.49 $4.22 - + Add to cart
34	FLASHER RELAY ASSEMBLY Part #: 5C4-83350-01-00 Required per assembly: 1 $70.98 $57.50 - + Add to cart
35	HORN Part #: 1WS-83371-00-00 Required per assembly: 1 $62.99 $51.62 - + Add to cart
36	NUT Part #: 90179-06018-00 Required per assembly: 1 $6.49 $5.13 - + Add to cart
