Fuel Tank replacement parts for 2021 Yamaha Raptor 700 California

OEM Parts Yamaha 2021 Yamaha Raptor 700 California Fuel Tank

FUEL TANK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PIPE, FUEL, 1 Part #: BFK-13971-00-00 Required per assembly: 1 ~~$59.99~~ $53.52 - + Add to cart
2	CLAMP Part #: 90464-14004-00 Required per assembly: 1 ~~$8.49~~ $5.29 - + Add to cart
3	GROMMET Part #: 90480-17012-00 Required per assembly: 1 ~~$7.49~~ $6.41 - + Add to cart
4	FUEL TANK COMP. Part #: 1PE-F4110-21-00 Required per assembly: 1 $187.22 - + Add to cart
5	CAP ASSEMBLY Part #: BFK-24610-01-00 Required per assembly: 1 ~~$40.99~~ $33.88 - + Add to cart
6	BRACKET, SEAT Part #: 4EW-2412F-00-00 Required per assembly: 1 ~~$15.49~~ $12.47 - + Add to cart
7	SCREW, CROSSRECESS, (8G6) Part #: 90151-06005-00 Required per assembly: 1 ~~$10.49~~ $7.05 - + Add to cart
8	GROMMET Part #: 90480-01017-00 Required per assembly: 2 ~~$5.99~~ $4.52 - + Add to cart
9	COLLAR, LEVER, 1 Part #: 36Y-83913-01-00 Required per assembly: 2 ~~$10.99~~ $8.77 - + Add to cart
10	WASHER, PLATE Part #: 90201-06090-00 Required per assembly: 2 ~~$6.49~~ $5.07 - + Add to cart
11	BOLT, FLANGE, DEEP, RECESS Part #: 95D02-06035-00 Required per assembly: 2 ~~$0.50~~ $0.38 - + Add to cart
12	GROMMET Part #: 90480-18005-00 Required per assembly: 2 ~~$9.49~~ $6.12 - + Add to cart
13	WASHER, PLATE Part #: 90201-06033-00 Required per assembly: 2 ~~$3.20~~ $2.69 - + Add to cart
14	COLLAR Part #: 90387-06098-00 Required per assembly: 2 ~~$9.49~~ $6.92 - + Add to cart
15	BOLT, FLANGE, DEEP, RECESS Part #: 95D02-06035-00 Required per assembly: 2 ~~$0.50~~ $0.38 - + Add to cart
16	DAMPER, PLATE, 1 Part #: 1S3-2414H-00-00 Required per assembly: 1 ~~$34.99~~ $31.84 - + Add to cart
17	INSULATOR, FUEL, TANK, 1 Part #: 1PE-F416F-00-00 Required per assembly: 1 ~~$43.99~~ $33.67 - + Add to cart
18	FUEL PUMP COMP. Part #: BFK-13907-00-00 Required per assembly: 1 ~~$385.99~~ $373.37 - + Add to cart
19	BRACKET, FUEL, PUMP Part #: BFK-24491-00-00 Required per assembly: 1 ~~$32.99~~ $28.67 - + Add to cart
20	O-RING Part #: 1S3-24486-00-00 Required per assembly: 1 ~~$18.98~~ $16.37 - + Add to cart
21	NUT (4MY) Part #: 95307-06800-00 Required per assembly: 6 ~~$4.15~~ $2.81 - + Add to cart
22	STOPPER 1 Part #: 1S3-24278-00-00 Required per assembly: 1 ~~$19.98~~ $15.44 - + Add to cart
23	STOPPER 2 Part #: 1S3-24279-00-00 Required per assembly: 1 ~~$14.49~~ $10.21 - + Add to cart
24	COVER Part #: BFK-24452-00-00 Required per assembly: 1 ~~$13.49~~ $11.08 - + Add to cart
25	PLUG Part #: 90338-05008-00 Required per assembly: 2 ~~$4.65~~ $2.45 - + Add to cart
26	CLAMP Part #: 90464-66001-00 Required per assembly: 1 ~~$1.99~~ $1.81 - + Add to cart
27	RIVET Part #: 90269-07011-00 Required per assembly: 1 ~~$9.49~~ $6.12 - + Add to cart
28	DAMPER, PLATE Part #: 90520-15017-00 Required per assembly: 1 ~~$4.04~~ $2.74 - + Add to cart
29	DAMPER, PLATE, 4 Part #: 3C5-2414N-00-00 Required per assembly: 2 ~~$4.75~~ $3.93 - + Add to cart
30	PLATE Part #: 1S3-2413X-00-00 Required per assembly: 1 Not Available
31	RIVET, SPEC'L, SHAPE Part #: 90269-05055-00 Required per assembly: 2 Note: Sold in multiples of 5 only ~~$9.49~~ $6.88 - + Add to cart
32	HOSE (L400) Part #: 90445-16007-00 Required per assembly: 1 ~~$15.49~~ $11.79 - + Add to cart
33	PIPE Part #: 31A-14419-00-00 Required per assembly: 1 ~~$8.49~~ $6.49 - + Add to cart
34	GROMMET Part #: 31A-14435-01-00 Required per assembly: 1 ~~$5.99~~ $3.46 - + Add to cart
