Frame replacement parts for 2021 Yamaha YUM1A21 UM

OEM Parts Yamaha 2021 Yamaha YUM1A21 UM Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: J0F-F2501-00-00 Required per assembly: 1 Not Available
2	MEMBER, SEAT, SUPPORT Part #: J0G-F255G-01-00 Required per assembly: 1 $120.81 - + Add to cart
3	BOLT, FLANGE Part #: 95817-08040-00 Required per assembly: 2 ~~$7.49~~ $7.38 - + Add to cart
4	STAY, RELAY Part #: J0B-F253B-02-00 Required per assembly: 1 $13.67 - + Add to cart
5	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 1 $2.13 - + Add to cart
6	FOOTREST 1 Part #: J0G-F7411-00-00 Required per assembly: 1 $846.54 - + Add to cart
7	BOLT Part #: J0B-F1738-01-00 Required per assembly: 1 ~~$2.39~~ $1.98 - + Add to cart
8	BOLT Part #: J0B-F1738-01-00 Required per assembly: 1 ~~$2.39~~ $1.98 - + Add to cart
9	BOLT Part #: J0B-F1738-01-00 Required per assembly: 7 ~~$2.39~~ $1.98 - + Add to cart
10	BRACKET, DAMPER Part #: J0L-F1121-00-00 Required per assembly: 2 ~~$29.98~~ $24.92 - + Add to cart
11	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 4 $3.25 - + Add to cart
12	SUPPORT, FRONT, COWL Part #: J0G-F258E-00-00 Required per assembly: 1 $545.12 - + Add to cart
13	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $2.13 - + Add to cart
14	BOLT, FLANGE Part #: 95817-08055-00 Required per assembly: 2 ~~$4.21~~ $3.96 - + Add to cart
15	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 2 ~~$9.49~~ $9.46 - + Add to cart
16	SHIM Part #: J0B-F2127-01-00 Required per assembly: 1 $3.80 - + Add to cart
17	BRACKET, UPPER Part #: J0G-F2219-00-00 Required per assembly: 1 ~~$28.98~~ $24.42 - + Add to cart
18	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 2 $2.13 - + Add to cart
19	PAD, SILENCER, 10 Part #: J0F-K825A-00-00 Required per assembly: 1 $17.59 - + Add to cart
20	PLATE, BATTERY, 3 Part #: J0B-F258R-01-00 Required per assembly: 1 $18.31 - + Add to cart
21	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 2 $2.13 - + Add to cart
22	RR. SUB-FRAME COMP. Part #: J0F-F2504-01-00 Required per assembly: 1 Not Available
23	BOLT, FLANGE Part #: 90105-088A7-00 Required per assembly: 4 $5.00 - + Add to cart
24	WASHER, PLATE Part #: 90201-08843-00 Required per assembly: 4 ~~$1.85~~ $1.55 - + Add to cart
25	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 4 ~~$9.49~~ $9.46 - + Add to cart
26	BRACKET, REAR, UPPER, 1 Part #: J0F-F1425-00-00 Required per assembly: 1 $5.63 - + Add to cart
27	BOLT, FLANGE, (SELF, TAPPING) Part #: 90105-06832-00 Required per assembly: 1 $1.44 - + Add to cart
