Frame replacement parts for 2021 Yamaha YXE10WPZM

OEM Parts Yamaha 2021 Yamaha YXE10WPZM Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: B4M-F1110-00-00 Required per assembly: 1 $4,630.94 - + Add to cart
2	ENGINE BRACKET COMP. Part #: BG4-21410-00-00 Required per assembly: 1 $80.98 $72.91 - + Add to cart
3	ENGINE BRACKET COMP. 2 Part #: BG4-21420-00-00 Required per assembly: 1 $80.98 $72.91 - + Add to cart
4	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-10025-00 Required per assembly: 4 $1.55 $1.27 - + Add to cart
5	BRACKET 5 Part #: BG4-F161F-00-00 Required per assembly: 1 $13.49 $9.65 - + Add to cart
6	BRACKET 3 Part #: BG4-F161A-00-00 Required per assembly: 1 $8.99 $7.30 - + Add to cart
7	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-12065-00 Required per assembly: 2 $3.95 $3.30 - + Add to cart
8	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-10016-00 Required per assembly: 4 $1.39 $1.15 - + Add to cart
9	BRACKET, ENGINE, 1 Part #: B4J-21490-10-00 Required per assembly: 2 Not Available
10	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-12065-00 Required per assembly: 2 $3.95 $3.30 - + Add to cart
11	NUT Part #: 90179-10033-00 Required per assembly: 2 Not Available
12	SUPPORT, ENGINE Part #: B4J-F1283-03-00 Required per assembly: 1 $23.98 $19.70 - + Add to cart
13	SUPT., ENGINE, 2 Part #: B4J-F1284-03-00 Required per assembly: 1 $26.98 $21.91 - + Add to cart
14	BOLT, FLANGE, DEEP, RECESS Part #: 95D32-10025-00 Required per assembly: 4 $1.55 $1.27 - + Add to cart
15	BRACKET 2 Part #: B4J-F1239-00-00 Required per assembly: 1 $3.75 $3.08 - + Add to cart
16	BOLT, FLANGE Part #: 95812-12020-00 Required per assembly: 2 $9.49 $6.12 - + Add to cart
17	BRACKET Part #: B4J-F1249-00-00 Required per assembly: 1 $4.25 $3.52 - + Add to cart
18	BOLT, FLANGE Part #: 95812-12020-00 Required per assembly: 2 $9.49 $6.12 - + Add to cart
19	LUG, SEAT, RAIL, LH. Part #: BG4-F1143-10-00 Required per assembly: 1 $43.77 - + Add to cart
20	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
21	MEMBER, SEAT, SUPPORT Part #: BG4-F255G-01-00 Required per assembly: 1 $36.99 $32.99 - + Add to cart
22	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 4 $1.95 $1.47 - + Add to cart
23	BRACKET, LOCK, 2 Part #: BG4-F287M-00-00 Required per assembly: 1 $20.98 $15.98 - + Add to cart
24	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
25	DAMPER, BRACE, ASSEMBLY Part #: B4J-F110J-01-00 Required per assembly: 1 $411.87 - + Add to cart
26	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 6 $1.95 $1.47 - + Add to cart
27	STAY, MUFFLER, 2 Part #: B8K-F1446-00-00 Required per assembly: 1 $3.04 $2.53 - + Add to cart
28	COVER 3 Part #: 2MB-F198J-00-00 Required per assembly: 2 $4.90 $4.84 - + Add to cart
29	BOLT, SPECIAL, 1 Part #: JW1-K6179-01-00 Required per assembly: 2 $1.75 $1.21 - + Add to cart
30	PLUG (FRONT BUMPER) Part #: 5UG-F2417-00-00 Required per assembly: 2 $7.49 $5.22 - + Add to cart
31	REINFORCEMENT, FRAME, 1 Part #: B4J-F1986-00-00 Required per assembly: 1 $232.23 - + Add to cart
32	BOLT, FLANGE Part #: 90105-08867-00 Required per assembly: 3 $1.95 $1.47 - + Add to cart
33	TOOL KIT Part #: BG4-F8100-00-00 Required per assembly: 1 $24.98 $17.61 - + Add to cart
34	GAUGE, AIR Part #: 1XD-F811A-00-00 Required per assembly: 1 $7.49 $6.86 - + Add to cart
35	POUCH Part #: 1P0-F8186-01-00 Required per assembly: 1 $2.89 $2.62 - + Add to cart
36	MOLD, FUEL, TANK Part #: 3VD-24188-00-00 Required per assembly: 1 $41.99 $32.93 - + Add to cart
