OEM Parts Yamaha 2021 Yamaha YXZ1000R EPS SS Oil Tank

2021 Yamaha YXZ1000R EPS SS YXZ10YEXML BASE - Oil Tank

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

TANK, OIL

Part #: 2HC-21751-02-00 Required per assembly: 1
$595.99
$582.80
-
+
Add to cart
2

OIL LEVEL GAUGE ASSEMBLY

Part #: 2HC-85720-00-00 Required per assembly: 1
$7.49
$5.88
-
+
Add to cart
3

O-RING

Part #: 93210-22006-00 Required per assembly: 1
$8.49
$5.32
-
+
Add to cart
4

OIL PIPE COMP. 2

Part #: 8GL-13406-00-00 Required per assembly: 1
$121.98
$86.63
-
+
Add to cart
5

O-RING

Part #: 93210-24001-00 Required per assembly: 1
$8.49
$5.50
-
+
Add to cart
6

BOLT, HEXAGON, SOCKET, HEAD

Part #: 91312-06016-00 Required per assembly: 2
$6.49
$4.81
-
+
Add to cart
7

BOLT, FLANGE

Part #: 95817-08012-00 Required per assembly: 1
$5.49
$3.90
-
+
Add to cart
8

GASKET

Part #: 90430-08204-00 Required per assembly: 1
$8.99
$6.42
-
+
Add to cart
9

BOLT, FLANGE

Part #: 95817-06016-00 Required per assembly: 3
$1.95
$1.47
-
+
Add to cart
10

WASHER, PLATE

Part #: 90201-06102-00 Required per assembly: 3
$4.20
$2.98
-
+
Add to cart
