Step replacement parts for 2022 Honda CBF300NA

OEM Parts Honda 2022 Honda CBF300NA Step

STEP Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 30
001	SPRING Part #: 28333-300-000 Required per assembly: 2 $4.11 $3.74 - + Add to cart
002	HOLDER, R., STEP Part #: 50600-K94-T00 Required per assembly: 1 $33.64 $26.83 - + Add to cart
003	PIN, STEP, BAR, JOINT Part #: 50603-K94-T00 Required per assembly: 2 $5.22 - + Add to cart
004	PIN, STEP, BAR, JOINT Part #: 50603-KB4-000 Required per assembly: 2 $5.30 $5.28 - + Add to cart
005	BRACKET, MAIN, STEP Part #: 50612-K94-T00 Required per assembly: 2 $11.07 $9.33 - + Add to cart
006	ARM, R., STEP, (COO) Part #: 50612-KYJ-305 Required per assembly: 1 $31.38 $25.03 - + Add to cart
007	SPRING, R. Part #: 50617-445-840 Required per assembly: 1 $6.55 $5.79 - + Add to cart
008	PLATE, STEP, SETTING Part #: 50619-K0A-E10 Required per assembly: 1 $6.55 $5.72 - + Add to cart
009	PLATE, STEP, SETTING Part #: 50619-MM5-000 Required per assembly: 1 $9.50 $8.20 - + Add to cart
010	ARM, L., STEP, (COO) Part #: 50642-KYJ-305 Required per assembly: 1 $31.38 $25.03 - + Add to cart
011	SPRING, L. Part #: 50644-445-840 Required per assembly: 1 $6.55 $5.79 - + Add to cart
012	RUBBER, MAIN, STEP Part #: 50661-MJE-D00 Required per assembly: 2 $3.87 - + Add to cart
013	HOLDER, L., STEP Part #: 50700-K94-T00 Required per assembly: 1 $32.18 $25.67 - + Add to cart
014	HOLDER, R., PILLION, STEP Part #: 50715-K0A-E10 Required per assembly: 1 $44.40 $35.41 - + Add to cart
015	COVER, PILLION, STEP Part #: 50716-K0A-E10 Required per assembly: 4 $2.06 $1.90 - + Add to cart
016	PLATE Part #: 50718-MN8-000 Required per assembly: 2 $3.51 $3.19 - + Add to cart
017	ARM, R., PILLION, STEP Part #: 50720-K94-T00 Required per assembly: 1 $14.20 $11.32 - + Add to cart
018	HOLDER, L., PILLION, STEP Part #: 50725-K94-T00 Required per assembly: 1 $29.20 $23.29 - + Add to cart
019	ARM, L., PILLION, STEP Part #: 50730-K94-T00 Required per assembly: 1 $14.20 $11.32 - + Add to cart
020	BOLT, SOCKET, (8X20) Part #: 90106-K94-T00 Required per assembly: 4 $2.26 $2.09 - + Add to cart
021	BOLT Part #: 90115-MV9-000 Required per assembly: 4 $5.04 $4.58 - + Add to cart
022	BOLT, FLANGE, (8X28) Part #: 90131-KWN-900 Required per assembly: 2 $1.99 $1.84 - + Add to cart
023	BOLT, SOCKET, (8X22) Part #: 90161-K94-T00 Required per assembly: 2 $2.29 $2.12 - + Add to cart
024	WASHER (15.5X27X2.0) Part #: 90502-K94-T00 Required per assembly: 2 $1.98 $1.83 - + Add to cart
025	WASHER (8.5X22X2.0) Part #: 90503-K94-T00 Required per assembly: 2 $1.98 $1.83 - + Add to cart
026	BOLT, CAP, (8X10) Part #: 92501-08010-0A Required per assembly: 2 $4.68 - + Add to cart
027	WASHER, PLAIN, (8MM) Part #: 94102-08000 Required per assembly: 2 $1.98 $1.83 - + Add to cart
028	PIN, COTTER, (1.6X25) Part #: 94201-16250 Required per assembly: 4 $2.07 $1.91 - + Add to cart
029	BALL (#8) (1/4) Part #: 96211-08000 Required per assembly: 2 $2.30 $2.13 - + Add to cart
