Radiator replacement parts for 2022 Honda SXS1000M5D

OEM Parts Honda 2022 Honda SXS1000M5D Radiator

RADIATOR Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 49
001	FAN SUB-ASSEMBLY Part #: 19006-HL4-AK1 Required per assembly: 1 $203.76 - + Add to cart
002	RADIATOR (TOYO) Part #: 19010-HL4-AK1 Required per assembly: 1 $146.95 - + Add to cart
003	SHROUD, RADIATOR Part #: 19014-HL4-AK0 Required per assembly: 1 $78.83 - + Add to cart
004	FAN, COOLING Part #: 19020-HL4-AK1 Required per assembly: 1 ~~$60.18~~ $48.00 - + Add to cart
005	PLATE, RADIATOR, GRILLE Part #: 19035-HL4-AK0 Required per assembly: 1 ~~$34.75~~ $27.71 - + Add to cart
006	CAP, RADIATOR Part #: 19037-GEE-710 Required per assembly: 1 ~~$35.08~~ $29.26 - + Add to cart
007	LABEL, RADIATOR, CAP Part #: 19046-PAA-A00 Required per assembly: 1 ~~$4.36~~ $3.96 - + Add to cart
008	RUBBER Part #: 19051-HL4-A00 Required per assembly: 2 $3.39 - + Add to cart
009	RUBBER Part #: 19051-KA3-830 Required per assembly: 2 ~~$4.64~~ $4.22 - + Add to cart
010	COLLAR, RADIATOR, MOUNTING Part #: 19052-HR6-MF0 Required per assembly: 2 $3.07 - + Add to cart
011	CAP, RESERVE, TANK Part #: 19104-MB0-700 Required per assembly: 1 ~~$14.10~~ $11.75 - + Add to cart
012	TANK, RADIATOR, RESERVE Part #: 19110-HL4-AK0 Required per assembly: 1 ~~$15.56~~ $12.89 - + Add to cart
013	TUBE, B, RESERVE, TANK Part #: 19112-HL4-AK0 Required per assembly: 1 $3.87 - + Add to cart
014	SCREW, PAN, (6X14) Part #: 90106-KBV-000 Required per assembly: 1 ~~$5.28~~ $4.80 - + Add to cart
015	BOLT, FLANGE, (6MM) Part #: 90111-187-000 Required per assembly: 2 ~~$8.75~~ $8.45 - + Add to cart
016	NUT, SERRATE, (5MM) Part #: 90315-MK3-003 Required per assembly: 1 ~~$3.29~~ $3.06 - + Add to cart
017	CLIP, SPLASH, GUARD, (EACH) Part #: 90653-HC4-900 Required per assembly: 9 ~~$1.67~~ $1.52 - + Add to cart
018	CLIP, WASHER, MOUTH Part #: 91504-SD5-003 Required per assembly: 1 $4.89 - + Add to cart
019	BOLT-WASHER (6X12) Part #: 93404-06012-07 Required per assembly: 2 ~~$2.63~~ $2.44 - + Add to cart
020	SCREW, TAP, (5X16) Part #: 93904-25320 Required per assembly: 3 ~~$1.50~~ $1.38 - + Add to cart
021	CLIP, TUBE, (B10) Part #: 95002-02100 Required per assembly: 3 ~~$2.88~~ $2.68 - + Add to cart
022	BULK HOSE (5.5X3000) Part #: 95005-55003-20M Required per assembly: 1 Not Available
023	BOLT, FLANGE, (6X22) Part #: 95701-06022-08 Required per assembly: 2 ~~$2.79~~ $2.60 - + Add to cart
