2022 Honda SXS1000S2R Talon 1000R - Roll Bar - Roof

ROLL BAR - ROOF Full screen diagram
Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
F 47
001

ROOF

Part #: 70100-HL6-A00 Required per assembly: 1
$1,670.65
-
+
Add to cart
002

PIPE, RR., ROLL, BAR, *NHC12*(MAT, SATIN, BLACK)

Part #: 71910-HL6-AA0ZA Required per assembly: 1
$4,078.38
-
+
Add to cart
003

PIPE, FR., ROLL, BAR, *NHC12*(MAT, SATIN, BLACK)

Part #: 71950-HL6-AA0ZA Required per assembly: 1
$2,158.46
-
+
Add to cart
004

BOLT, FLANGE, (10X25)

Part #: 90114-HL6-A00 Required per assembly: 12
$1.53
$1.42
-
+
Add to cart
005

SCREW, SPECIAL, (6X14)

Part #: 90114-KWL-000 Required per assembly: 2
$3.51
$3.19
-
+
Add to cart
006

SCREW, PAN, (8X20)

Part #: 90121-HL6-A00 Required per assembly: 4
$1.94
$1.83
-
+
Add to cart
007

NUT, SELF-LOCK, (10MM)

Part #: 90305-HE0-670 Required per assembly: 12
$6.57
$5.81
-
+
Add to cart
008

NUT

Part #: 90305-SH3-000 Required per assembly: 2
$7.78
$7.47
-
+
Add to cart
009

COLLAR (5MM)

Part #: 90513-HL6-A00 Required per assembly: 4
$8.27
$7.40
-
+
Add to cart
010

BOLT, FLANGE, (10X16)

Part #: 95701-10016-00 Required per assembly: 4
$2.30
$2.09
-
+
Add to cart
011

BOLT, FLANGE, (10X20)

Part #: 95701-10020-00 Required per assembly: 2
$3.21
$2.99
-
+
Add to cart
