Door replacement parts for 2022 Honda SXS1000S2X

OEM Parts Honda 2022 Honda SXS1000S2X Door

DOOR Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

F 28
001	CAP, PIPE, END Part #: 50190-HN6-F30 Required per assembly: 4 $2.33 $2.16 - + Add to cart
002	PANEL, R., FR., DOOR Part #: 67100-HL6-A00 Required per assembly: 1 $95.75 - + Add to cart
003	ROD, DOOR, LATCH Part #: 67102-HL6-A00 Required per assembly: 2 $6.24 $5.71 - + Add to cart
004	HANDLE, DOOR Part #: 67103-HL6-A00 Required per assembly: 2 $9.51 $8.08 - + Add to cart
005	PLATE, R., DOOR, HANDLE Part #: 67104-HL6-A00 Required per assembly: 1 $20.91 $17.33 - + Add to cart
006	STRIKER, DOOR Part #: 67106-HL6-A00 Required per assembly: 2 $9.20 $8.24 - + Add to cart
007	PIPE, R., HINGE, (LOWER) Part #: 67111-HL6-A00 Required per assembly: 1 $57.44 $48.53 - + Add to cart
008	WASHER (23X28X1.6) Part #: 67112-HL6-A00 Required per assembly: 4 $1.67 $1.54 - + Add to cart
009	COLLAR, HINGE Part #: 67113-HL6-A00 Required per assembly: 4 $1.98 $1.83 - + Add to cart
010	PIPE, HINGE, (UPPER) Part #: 67114-HL6-A00 Required per assembly: 2 $46.18 $39.02 - + Add to cart
011	COVER, R., HINGE, PIPE Part #: 67116-HL6-A00 Required per assembly: 1 $5.05 - + Add to cart
012	COVER, SET, R., FR., DOOR, (TYPE2)(WL) Part #: 67155-HL6-AA0ZD Required per assembly: 1 Note: Color: YR339-(PEARL TANGELO ORANGE), Area: A AC $401.35 - + Add to cart
012	COVER, SET, R., FR., DOOR, (TYPE1)(WL) Part #: 67155-HL6-AA0ZE Required per assembly: 1 Note: Color: NHC59-(MAT ABYSS BLACK), Area: ALL $401.35 - + Add to cart
012	COVER, SET, R., FR., DOOR, (TYPE3)(WL) Part #: 67155-HL6-AA0ZF Required per assembly: 1 Note: Color: R373-(PEARL REAPER RED), Area: 5A 5AC $426.54 - + Add to cart
012	COVER, SET, R., FR., DOOR, (TYPE4)(WL) Part #: 67155-HL6-AA0ZB Required per assembly: 1 Note: Color: PB424-(MAT BLISS BLUE METALLIC), Area: 5A 5AC $368.65 $366.35 - + Add to cart
013	PANEL, L., FR., DOOR Part #: 67200-HL6-A00 Required per assembly: 1 $95.75 - + Add to cart
014	PLATE, L., DOOR, HANDLE Part #: 67204-HL6-A00 Required per assembly: 1 $20.91 $17.33 - + Add to cart
015	PIPE, L., HINGE, (LOWER) Part #: 67211-HL6-A00 Required per assembly: 1 $57.44 $48.53 - + Add to cart
016	COVER, L., HINGE, PIPE Part #: 67216-HL6-A00 Required per assembly: 1 $5.05 - + Add to cart
017	LATCH, R., DOOR Part #: 67236-HL1-A01 Required per assembly: 1 $15.85 $14.63 - + Add to cart
018	LATCH, L., DOOR Part #: 67237-HL1-A01 Required per assembly: 1 $16.04 $14.82 - + Add to cart
019	STOPPER, DOOR Part #: 67239-HL1-A00 Required per assembly: 2 $2.50 $2.32 - + Add to cart
020	SPRING, DOOR, LEVER Part #: 67241-HL1-A00 Required per assembly: 4 $4.80 $4.36 - + Add to cart
021	BUSH, FLANGE, (6MM) Part #: 67243-HL1-A00 Required per assembly: 4 $3.09 $2.87 - + Add to cart
022	COVER, SET, L., FR., DOOR, (TYPE2)(WL) Part #: 67255-HL6-AA0ZD Required per assembly: 1 Note: Color: YR339-(PEARL TANGELO ORANGE), Area: A AC $384.07 - + Add to cart
022	COVER, SET, L., FR., DOOR, (TYPE1)(WL) Part #: 67255-HL6-AA0ZE Required per assembly: 1 Note: Color: NHC59-(MAT ABYSS BLACK), Area: ALL $385.94 - + Add to cart
022	COVER, SET, L., FR., DOOR, (TYPE3)(WL) Part #: 67255-HL6-AA0ZF Required per assembly: 1 Note: Color: R373-(PEARL REAPER RED), Area: 5A 5AC $404.21 - + Add to cart
022	COVER, SET, L., FR., DOOR, (TYPE4)(WL) Part #: 67255-HL6-AA0ZB Required per assembly: 1 Note: Color: PB424-(MAT BLISS BLUE METALLIC), Area: 5A 5AC $340.09 - + Add to cart
023	NET, ASSEMBLY, R., FR., SIDE Part #: 67310-HL6-A00 Required per assembly: 1 $137.91 $114.81 - + Add to cart
024	NET, ASSEMBLY, L., FR., SIDE Part #: 67320-HL6-A00 Required per assembly: 1 $137.91 $114.81 - + Add to cart
025	BOLT, SPECIAL, (8MM) Part #: 90104-HL5-A00 Required per assembly: 6 $1.61 $1.48 - + Add to cart
026	SCREW, PAN, (6X14) Part #: 90106-KBV-000 Required per assembly: 2 $5.28 $4.80 - + Add to cart
027	WASHER, WAVE, (20MM) Part #: 90114-Z32-000 Required per assembly: 4 $3.25 $3.02 - + Add to cart
028	SCREW, PAN, (6MM) Part #: 90117-HL6-A00 Required per assembly: 6 $11.16 $9.98 - + Add to cart
029	WASHER, WAVE, (10MM) Part #: 90510-HL6-A00 Required per assembly: 4 $10.73 $9.27 - + Add to cart
030	WASHER (10MM) Part #: 90511-HL6-A00 Required per assembly: 2 $17.53 $14.34 - + Add to cart
031	CLIP, SPLASH, GUARD, (EACH) Part #: 90653-HC4-900 Required per assembly: 8 $1.67 $1.52 - + Add to cart
032	SCREW, TAP, (5X16) Part #: 93903-25380 Required per assembly: 16 $1.95 $1.80 - + Add to cart
033	NUT, FLANGE, (8MM) Part #: 94050-08000 Required per assembly: 4 Note: Sold in multiples of 5 only $2.01 $1.96 - + Add to cart
034	PIN, LOCK, (6MM) Part #: 94251-06000 Required per assembly: 2 $2.07 $1.91 - + Add to cart
035	PIN, SPRING, (2.5X16) Part #: 94305-25162 Required per assembly: 2 Note: (2.5X16) (Honda Code 0671644) $2.50 $2.32 - + Add to cart
036	BOLT-WASHER (6X12) Part #: 93404-06012-07 Required per assembly: 8 $2.63 $2.44 - + Add to cart
037	BOLT, FLANGE, (6X20) Part #: 95701-06020-08 Required per assembly: 4 $1.47 $1.35 - + Add to cart
038	BOLT, FLANGE, (8X16) Part #: 95701-08016-07 Required per assembly: 4 $2.79 $2.60 - + Add to cart
039	BOLT, FLANGE, (8X55) Part #: 95701-08055-00 Required per assembly: 4 $3.50 $3.18 - + Add to cart
