Evap System (E33) replacement parts for 2022 Suzuki DR-Z400S, SM

OEM Parts Suzuki 2022 Suzuki DR Z400S, SM Evap System (E33)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HOSE, TANK, &, BRTHR, VALVE Part #: 44434-29F20 Required per assembly: 1 Not Available
2	PROTECTOR (L:600->280) Part #: 09351-14152-600 Required per assembly: 1 Note: PROTECTOR, NO.2 (L:600->90); $13.59 $12.23 - + Add to cart
3	CLIP Part #: 09401-11413 Required per assembly: 3 $2.80 $2.52 - + Add to cart
4	VALVE, BREATHER Part #: 44240-17C00 Required per assembly: 1 Note: VALVE, TANK BREATHER; $73.01 $62.43 - + Add to cart
5	BRACKET, VALVE Part #: 44890-29F00 Required per assembly: 1 Not Available
6	CUSHION Part #: 44894-24A00 Required per assembly: 1 $2.18 $1.96 - + Add to cart
7	PLATE, VALVE Part #: 44892-24A00 Required per assembly: 1 Note: PLATE, BREATHER VALVE; $5.11 $4.60 - + Add to cart
8	CUSHION Part #: 44894-24A00 Required per assembly: 1 $2.18 $1.96 - + Add to cart
9	SCREW, PLATE Part #: 02142-0408B Required per assembly: 2 Note: SCREW, PLATE; $2.13 $1.92 - + Add to cart
10	HOSE, BRTHR, VALVE, &, CSTR Part #: 44435-29F20 Required per assembly: 1 Not Available
11	PROTECTOR NO.1 Part #: 09351-14152-00B Required per assembly: 1 Note: L:2000->660 Not Available
12	CLIP Part #: 09401-12404 Required per assembly: 1 $2.95 $2.66 - + Add to cart
13	CANISTER Part #: 17210-26E00 Required per assembly: 1 $360.67 $308.37 - + Add to cart
14	CAP, CANISTER Part #: 17211-48E01 Required per assembly: 1 $22.04 $18.84 - + Add to cart
15	CAP Part #: 09251-07003 Required per assembly: 1 $2.68 $2.41 - + Add to cart
16	BRACKET, CANISTE Part #: 44881-29F00 Required per assembly: 1 Not Available
17	BOLT Part #: 01550-0816B Required per assembly: 1 $3.45 $3.11 - + Add to cart
18	BOLT, CENTER Part #: 09116-06165 Required per assembly: 1 $3.20 $2.88 - + Add to cart
19	CUSHION Part #: 44883-26E00 Required per assembly: 1 Note: CUSHION, CANISTER; Not Available
20	HOLDER, CANISTER Part #: 44882-29F00 Required per assembly: 1 Not Available
21	BOLT Part #: 01550-0612B Required per assembly: 1 Note: BOLT, BRACKET; $2.95 $2.66 - + Add to cart
22	HOSE, CSTR, &, CARB, PURGE Part #: 44436-29F20 Required per assembly: 1 Not Available
23	PROTECTOR (L:600->280) Part #: 09351-14152-600 Required per assembly: 1 Note: PROTECTOR, NO.2 (L:600->90); $13.59 $12.23 - + Add to cart
24	JOINT, HOSE Part #: 09364-06005 Required per assembly: 1 Note: JOINT, PURGE HOSE; $6.01 $5.41 - + Add to cart
25	HOSE, CSTR, &, CARB, PURGE, NO.2 Part #: 44437-29F20 Required per assembly: 1 Not Available
26	PROTECTOR (L:600->280) Part #: 09351-14152-600 Required per assembly: 1 Note: PROTECTOR, NO.2 (L:600->90); $13.59 $12.23 - + Add to cart
27	CLIP Part #: 09401-11413 Required per assembly: 5 $2.80 $2.52 - + Add to cart
28	CLAMP (L:140) Part #: 09407-14403 Required per assembly: 1 Note: CLAMP; $2.80 $2.52 - + Add to cart
29	BAND, BAR, PAD, (L, 145) Part #: 09407-14407 Required per assembly: 1 Note: BAND; $3.70 $3.33 - + Add to cart
