Front Fork (E03) replacement parts for 2022 Suzuki DR-Z50

OEM Parts Suzuki 2022 Suzuki DR Z50 Front Fork (E03)

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FORK, SET, FRONT Part #: 51100-14831 Required per assembly: 1 $1,023.19 $874.82 - + Add to cart
2	RACE, STEERING, OUTER Part #: 51622-14H00 Required per assembly: 1 Not Available
3	SEAL, STEERING, LWR Part #: 51644-14H01 Required per assembly: 1 $8.17 $7.35 - + Add to cart
4	TUBE, ASSEMBLY, FRONT, FORK, LOWER Part #: 51110-14H00 Required per assembly: 1 Note: R $454.33 $408.90 - + Add to cart
5	TUBE, ASSEMBLY, FRONT, FORK, LOWER Part #: 51120-14H00 Required per assembly: 1 Note: L $412.49 $371.24 - + Add to cart
6	STOPPER Part #: 51116-14H00 Required per assembly: 2 $11.07 $9.96 - + Add to cart
7	SPRING Part #: 51171-14H00 Required per assembly: 2 Not Available
8	STOPPER RUBBER Part #: 51292-14H00 Required per assembly: 4 $11.51 $10.36 - + Add to cart
9	SPRING, JOINT, B Part #: 51422-14H00 Required per assembly: 2 Not Available
10	WASHER, FR, FORK, UPPER, B Part #: 09160-10144 Required per assembly: 2 Note: WASHER, GEAR SHIFT LEVER, R; 10X30X2.5 $5.56 $5.00 - + Add to cart
11	BOLT, FR, FORK, UPPER Part #: 01550-1035A Required per assembly: 1 $4.55 $4.10 - + Add to cart
12	BOLT, FR, FORK, UPPER Part #: 01550-1035A Required per assembly: 2 $4.55 $4.10 - + Add to cart
13	BRACKET, UPPER Part #: 51310-14H00 Required per assembly: 1 $70.18 $63.16 - + Add to cart
14	WASHER Part #: 09160-10128-XC0 Required per assembly: 1 Note: WASHER, FR FORK UPPER A; $3.20 $2.88 - + Add to cart
15	PROTECTOR, FRONT, FORK, RH, (BLACK) Part #: 51501-14H00-019 Required per assembly: 1 $20.69 $18.62 - + Add to cart
16	PROTECTOR, FRONT, FORK, LH, (BLACK) Part #: 51511-14H00-019 Required per assembly: 1 $20.69 $18.62 - + Add to cart
17	WASHER Part #: 09169-06071 Required per assembly: 4 $3.02 $2.72 - + Add to cart
18	BOLT Part #: 01547-0612A Required per assembly: 4 $2.45 $2.21 - + Add to cart
19	RACE, STEERING, INNER, LOWER Part #: 51611-14H00 Required per assembly: 1 $14.03 $12.63 - + Add to cart
20	RACE, INNER, UPPER Part #: 51611-20002 Required per assembly: 1 $12.92 $11.63 - + Add to cart
21	RACE, OUTER, UPPER Part #: 51621-28000 Required per assembly: 1 $12.92 $11.63 - + Add to cart
22	NUT, STEERING, STEM Part #: 51631-28000 Required per assembly: 1 Note: NUT; $18.76 $16.03 - + Add to cart
23	DUST SEAL Part #: 51643-25001 Required per assembly: 1 $5.89 $5.30 - + Add to cart
24	BEARING, STEERING Part #: 09269-27001 Required per assembly: 2 $16.09 $14.48 - + Add to cart
