Seat Cushion replacement parts for 2022 Yamaha 255XE

OEM Parts Yamaha 2022 Yamaha 255XE Seat Cushion

SEAT CUSHION Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CUSHION, FORE, 5 Part #: F5K-U35A5-00-00 Required per assembly: 1 ~~$532.42~~ $499.49 - + Add to cart
2	CUSHION, FORE, 6 Part #: F5K-U35A6-00-00 Required per assembly: 1 ~~$532.42~~ $499.49 - + Add to cart
3	CUSHION, FORE, 1 Part #: F5K-U35A1-00-00 Required per assembly: 1 ~~$402.88~~ $395.90 - + Add to cart
4	CUSHION, SEAT, FRONT, RIGHT Part #: F5K-U35A2-00-00 Required per assembly: 1 $580.38 - + Add to cart
5	BACK REST 3 Part #: F5K-U3796-00-00 Required per assembly: 1 $1,570.37 - + Add to cart
6	BACK, REST, 4 Part #: F5K-U3798-00-00 Required per assembly: 1 $1,334.92 - + Add to cart
7	CUSHION 5 Part #: F5K-U372F-00-00 Required per assembly: 1 ~~$534.47~~ $500.90 - + Add to cart
8	BACKREST, MAIN, 1 Part #: F5K-U35E1-00-00 Required per assembly: 1 ~~$275.38~~ $249.34 - + Add to cart
9	PAD 2 Part #: F5K-U36A2-00-00 Required per assembly: 1 ~~$284.56~~ $258.42 - + Add to cart
10	CUSHION 1 Part #: F5K-U371D-00-00 Required per assembly: 1 $837.05 - + Add to cart
11	CUSHION, SEAT Part #: F5K-U3713-00-00 Required per assembly: 1 ~~$355.97~~ $318.90 - + Add to cart
12	BRACKET, SEAT Part #: F3F-U3714-21-00 Required per assembly: 4 ~~$32.63~~ $26.28 - + Add to cart
13	BRACKET, SEAT Part #: F3F-U3714-31-00 Required per assembly: 4 ~~$26.51~~ $22.80 - + Add to cart
14	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 16 ~~$4.99~~ $0.56 - + Add to cart
15	WASHER, LOCK, (#10) Part #: 90204-10S00-00 Required per assembly: 16 ~~$7.12~~ $3.69 - + Add to cart
16	NUT Part #: 90170-10S00-00 Required per assembly: 16 ~~$6.11~~ $2.20 - + Add to cart
17	SCREW, COUNTERSUNK Part #: 90151-10S16-00 Required per assembly: 16 ~~$6.11~~ $1.98 - + Add to cart
18	WASHER, #10, FLAT Part #: 90201-10S00-00 Required per assembly: 16 ~~$4.99~~ $0.56 - + Add to cart
19	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 16 ~~$5.08~~ $1.55 - + Add to cart
20	BACK REST 1 Part #: F5K-U3791-00-00 Required per assembly: 1 $745.93 - + Add to cart
21	BACKREST, MAIN, 2 Part #: F5K-U35E2-00-00 Required per assembly: 1 $633.36 - + Add to cart
22	PAD 1 Part #: F5K-U36A1-00-00 Required per assembly: 1 ~~$202.97~~ $190.36 - + Add to cart
23	CUSHION, SEAT, REAR Part #: F5K-U3724-01-00 Required per assembly: 1 ~~$252.94~~ $232.71 - + Add to cart
24	SNAP, CARPET Part #: F1C-U5192-00-00 Required per assembly: 1 $0.89 - + Add to cart
25	WASHER, PLATE Part #: 90202-06SA3-00 Required per assembly: 1 $0.11 - + Add to cart
26	BACKREST, MAIN, 4 Part #: F5K-U35E4-00-00 Required per assembly: 1 ~~$250.91~~ $248.18 - + Add to cart
27	BACK, REST, 6 Part #: F5K-U379A-01-00 Required per assembly: 1 $3,726.10 - + Add to cart
28	BACK, REST, 7 Part #: F5K-U379B-01-00 Required per assembly: 1 $3,726.10 - + Add to cart
29	WASHER, FENDER Part #: 90209-14SA3-00 Required per assembly: 12 ~~$6.11~~ $1.87 - + Add to cart
30	WASHER, 1/4", LOCK Part #: 90204-14S00-00 Required per assembly: 12 ~~$6.11~~ $1.66 - + Add to cart
31	NUT, 1/4-20 Part #: 90170-14S00-00 Required per assembly: 12 ~~$5.08~~ $0.89 - + Add to cart
32	CUSHION 1 Part #: F5K-U828B-00-00 Required per assembly: 1 ~~$728.99~~ $724.24 - + Add to cart
33	CUSHION 2 Part #: F5K-U828C-00-00 Required per assembly: 1 ~~$728.99~~ $724.27 - + Add to cart
34	HOLDER Part #: F5K-U724H-00-00 Required per assembly: 2 ~~$64.25~~ $52.90 - + Add to cart
35	SCREW, TAPPING Part #: 90161-04S12-00 Required per assembly: 6 ~~$5.08~~ $1.00 - + Add to cart
36	PAD 3 Part #: F5K-U521E-00-00 Required per assembly: 1 ~~$137.69~~ $122.32 - + Add to cart
37	PAD 4 Part #: F5K-U521F-00-00 Required per assembly: 1 ~~$137.69~~ $122.32 - + Add to cart
38	CUSHION, MAIN, 5 Part #: F5K-U35C5-00-00 Required per assembly: 1 $703.47 - + Add to cart
39	CUSHION, MAIN, 6 Part #: F5K-U35C6-00-00 Required per assembly: 1 $677.91 - + Add to cart
40	CLIP, 1 Part #: F1C-U5195-00-00 Required per assembly: 1 ~~$8.15~~ $5.43 - + Add to cart
41	SCREW, TAPPING Part #: 90167-08SA8-00 Required per assembly: 1 ~~$6.11~~ $1.66 - + Add to cart
42	SCREW, TAPPING Part #: 90167-08SB1-00 Required per assembly: 10 ~~$6.11~~ $2.20 - + Add to cart
