Windshield replacement parts for 2022 Yamaha XMAX

OEM Parts Yamaha 2022 Yamaha XMAX Windshield

WINDSHIELD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GRILL, AIR, INTAKE Part #: B74-F837N-01-00 Required per assembly: 1 $17.57 - + Add to cart
2	BOLT, WITH, WASHER Part #: 90119-06051-00 Required per assembly: 3 ~~$9.49~~ $8.48 - + Add to cart
3	SCREW, ROUND, TAPPING, (50C1) Part #: 90160-05808-00 Required per assembly: 2 $0.60 - + Add to cart
4	RIVET Part #: 90269-06816-00 Required per assembly: 4 $2.05 - + Add to cart
5	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 ~~$5.59~~ $4.65 - + Add to cart
6	STAY 1 Part #: B74-F8321-10-00 Required per assembly: 1 ~~$90.98~~ $79.49 - + Add to cart
7	GROMMET Part #: 90480-10289-00 Required per assembly: 1 ~~$9.49~~ $8.67 - + Add to cart
8	GROMMET Part #: 90480-14229-00 Required per assembly: 3 ~~$9.49~~ $8.31 - + Add to cart
9	COLLAR Part #: 90387-068N8-00 Required per assembly: 3 $2.67 - + Add to cart
10	BOLT, WITH, WASHER Part #: 90119-06268-00 Required per assembly: 3 $2.93 - + Add to cart
11	BOLT, FLANGE Part #: 95817-08055-00 Required per assembly: 2 ~~$4.21~~ $3.96 - + Add to cart
12	BOX, BATTERY, 1 Part #: B74-H212B-00-00 Required per assembly: 1 $46.07 - + Add to cart
13	BOLT Part #: 90109-068B5-00 Required per assembly: 1 $0.56 - + Add to cart
14	COLLAR Part #: 90387-09805-00 Required per assembly: 2 ~~$2.35~~ $1.77 - + Add to cart
15	NUT, SPEC'L, SHAPE Part #: 90179-06403-00 Required per assembly: 2 $7.20 - + Add to cart
16	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 ~~$5.59~~ $4.65 - + Add to cart
17	NUT, SPRING Part #: 90183-06818-00 Required per assembly: 5 Not Available
18	COLLAR Part #: 90387-06048-00 Required per assembly: 2 ~~$9.49~~ $8.19 - + Add to cart
19	COLLAR Part #: 90387-09808-00 Required per assembly: 8 ~~$2.35~~ $1.77 - + Add to cart
20	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06839-00 Required per assembly: 4 $0.58 - + Add to cart
21	BOLT, FLANGE, DEEP, RECESS Part #: 95E32-06012-00 Required per assembly: 2 ~~$0.28~~ $0.25 - + Add to cart
22	PLATE, WINDSHIELD Part #: B74-F8306-00-00 Required per assembly: 1 $16.45 - + Add to cart
23	PLATE, WINDSHIELD, 2 Part #: B74-F835P-00-00 Required per assembly: 1 ~~$25.98~~ $25.35 - + Add to cart
24	STAY 2 Part #: B74-F8322-00-00 Required per assembly: 1 ~~$21.98~~ $20.77 - + Add to cart
25	STAY, LEG, SHIELD Part #: B74-F8332-00-00 Required per assembly: 1 ~~$21.98~~ $20.77 - + Add to cart
26	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06380-00 Required per assembly: 2 ~~$9.49~~ $8.52 - + Add to cart
27	BOLT Part #: 90109-06009-00 Required per assembly: 2 ~~$10.49~~ $10.18 - + Add to cart
28	NUT Part #: 90179-05003-00 Required per assembly: 4 $6.71 - + Add to cart
29	COVER, FRONT, 2 Part #: B74-F286F-00-00 Required per assembly: 1 $27.02 - + Add to cart
30	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 ~~$5.59~~ $4.65 - + Add to cart
31	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 2 $2.82 - + Add to cart
32	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 5 ~~$4.62~~ $3.18 - + Add to cart
33	GROMMET(4DN) Part #: 90480-01558-00 Required per assembly: 2 $5.47 - + Add to cart
34	BODY, COWLING Part #: B74-F8351-00-3E Required per assembly: 1 ~~$29.98~~ $27.53 - + Add to cart
35	BOLT, FLANGE, DEEP, RECESS Part #: 95D02-06025-00 Required per assembly: 1 ~~$1.00~~ $0.80 - + Add to cart
36	GROMMET Part #: 90480-14023-00 Required per assembly: 1 ~~$7.49~~ $4.79 - + Add to cart
37	COLLAR Part #: 90387-06158-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
38	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 2 ~~$4.62~~ $3.18 - + Add to cart
39	BODY, FRONT, UNDER, 1 Part #: B74-F835J-10-P2 Required per assembly: 1 ~~$32.99~~ $29.83 - + Add to cart
40	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 3 $2.82 - + Add to cart
41	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 5 ~~$5.59~~ $4.65 - + Add to cart
42	BODY, COWLING, 2 Part #: B74-F8377-00-3E Required per assembly: 1 ~~$29.98~~ $27.53 - + Add to cart
43	BOLT, FLANGE, DEEP, RECESS Part #: 95D02-06025-00 Required per assembly: 1 ~~$1.00~~ $0.80 - + Add to cart
44	GROMMET Part #: 90480-14023-00 Required per assembly: 1 ~~$7.49~~ $4.79 - + Add to cart
45	COLLAR Part #: 90387-06158-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
46	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 2 ~~$4.62~~ $3.18 - + Add to cart
47	BODY, FRONT, UNDER, 2 Part #: B74-F835K-10-P2 Required per assembly: 1 ~~$32.99~~ $29.83 - + Add to cart
48	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 3 $2.82 - + Add to cart
49	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 5 ~~$5.59~~ $4.65 - + Add to cart
50	COVER, FRONT Part #: B74-F2865-00-3E Required per assembly: 1 ~~$37.99~~ $32.64 - + Add to cart
51	CLAMP Part #: 90464-07018-00 Required per assembly: 2 ~~$0.31~~ $0.28 - + Add to cart
52	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 ~~$5.59~~ $4.65 - + Add to cart
53	COVER, BATTERY Part #: B74-H2129-00-00 Required per assembly: 1 $38.11 - + Add to cart
54	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 2 ~~$4.62~~ $3.18 - + Add to cart
55	NUT, SPRING, (1YT) Part #: 90183-05042-00 Required per assembly: 2 ~~$5.59~~ $4.65 - + Add to cart
56	RIVET Part #: 90269-06816-00 Required per assembly: 1 $2.05 - + Add to cart
57	SCREEN Part #: B74-F837U-00-00 Required per assembly: 1 $204.08 - + Add to cart
58	SCREW, BINDING Part #: 90154-05011-00 Required per assembly: 4 $5.20 - + Add to cart
59	COVER 5 Part #: B74-F842A-00-00 Required per assembly: 1 $10.02 - + Add to cart
60	COVER 6 Part #: B74-F843C-00-00 Required per assembly: 1 $10.02 - + Add to cart
61	RIVET Part #: 90269-08007-00 Required per assembly: 2 ~~$5.49~~ $5.20 - + Add to cart
62	EMBLEM Part #: 2PH-F1737-00-00 Required per assembly: 1 Not Available
63	COVER, FLASHER, 1 Part #: B74-F83D3-00-P2 Required per assembly: 1 ~~$29.98~~ $24.66 - + Add to cart
64	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 2 ~~$4.62~~ $3.18 - + Add to cart
65	CLAMP Part #: 90464-04004-00 Required per assembly: 1 ~~$0.54~~ $0.46 - + Add to cart
66	COVER, FLASHER, 2 Part #: B74-F83D4-00-P2 Required per assembly: 1 ~~$29.98~~ $24.66 - + Add to cart
67	SCREW, TRUSS, HEAD, TAPPING Part #: 97707-50012-00 Required per assembly: 2 ~~$4.62~~ $3.18 - + Add to cart
68	CLAMP Part #: 90464-04004-00 Required per assembly: 1 ~~$0.54~~ $0.46 - + Add to cart
