Transaxle replacement parts for 2022 Yamaha DRIVE2 Fleet AFI

OEM Parts Yamaha 2022 Yamaha DRIVE2 Fleet AFI Transaxle

TRANSAXLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	TRANS AXLE ASSEMBLY Part #: J0A-G6300-10-00 Required per assembly: 1 $2,176.74 - + Add to cart
2	BOLT, FLANGE Part #: 90105-10840-00 Required per assembly: 4 ~~$3.60~~ $2.78 - + Add to cart
3	BEARING(JH8) Part #: 93306-303Y6-00 Required per assembly: 3 ~~$53.99~~ $51.39 - + Add to cart
4	SHIM, 076MM, (0030IN) Part #: JN3-G6344-00-00 Required per assembly: 1 Note: UR $8.95 - + Add to cart
5	BAR 1 Part #: JW8-G633E-01-00 Required per assembly: 1 $24.42 - + Add to cart
6	RETAINER Part #: JU0-F722H-00-00 Required per assembly: 2 $7.73 - + Add to cart
7	INPUT SHAFT ASSY Part #: JW8-G6320-01-00 Required per assembly: 1 ~~$340.99~~ $323.55 - + Add to cart
8	BEARING (J17) Part #: 93306-00511-00 Required per assembly: 1 Note: SEAL TYPE ~~$32.99~~ $27.23 - + Add to cart
9	COVER, TRNSMISSION Part #: JW8-G6313-10-00 Required per assembly: 1 ~~$232.99~~ $225.18 - + Add to cart
10	BRACKET 2 Part #: JW8-G6555-00-00 Required per assembly: 1 $11.07 - + Add to cart
11	SPRING SET Part #: JU0-G6376-00-00 Required per assembly: 1 ~~$33.99~~ $31.72 - + Add to cart
12	BOLT, SET Part #: 90113-08803-00 Required per assembly: 1 $3.56 - + Add to cart
13	SPRING, COMPRESSION Part #: 90501-10852-00 Required per assembly: 1 $6.25 - + Add to cart
14	BALL Part #: 93500-06826-00 Required per assembly: 1 ~~$4.75~~ $4.40 - + Add to cart
15	OIL SEAL Part #: 93102-25868-00 Required per assembly: 1 $26.28 - + Add to cart
16	BOLT, FLANGE Part #: 90105-08859-00 Required per assembly: 7 $12.82 - + Add to cart
17	WASHER, PLATE Part #: 90201-208H9-00 Required per assembly: 3 $6.85 - + Add to cart
18	GEAR, IDLER Part #: JN3-G6356-00-00 Required per assembly: 1 $278.19 - + Add to cart
19	WASHER, PLATE Part #: 90201-208J0-00 Required per assembly: 1 $7.54 - + Add to cart
20	CIRCLIP Part #: JW8-F47E3-00-00 Required per assembly: 1 Note: Sold in multiples of 100 only ~~$5.49~~ $5.35 - + Add to cart
21	PIN, DOWEL Part #: 93606-10842-00 Required per assembly: 2 $8.31 - + Add to cart
22	WASHER, PLATE Part #: 90201-178H8-00 Required per assembly: 2 $14.49 - + Add to cart
23	GEAR, PINION, 1 Part #: JN3-G6316-00-00 Required per assembly: 1 ~~$356.99~~ $325.06 - + Add to cart
24	GEAR, WHEEL, 1 Part #: JN3-G6326-00-00 Required per assembly: 1 $559.60 - + Add to cart
25	SHAFT Part #: J0G-G633G-00-00 Required per assembly: 1 ~~$95.98~~ $92.22 - + Add to cart
26	COLLAR, GUIDE Part #: JN3-G6153-00-00 Required per assembly: 1 ~~$406.99~~ $340.08 - + Add to cart
27	BAR, SHIFT, 2 Part #: JN6-G638E-00-00 Required per assembly: 1 ~~$67.98~~ $65.00 - + Add to cart
28	BAR, SHIFT, 1 Part #: JW8-G638A-00-00 Required per assembly: 1 ~~$43.99~~ $36.26 - + Add to cart
29	GEAR, WHEEL, 1 Part #: JN3-G6327-00-00 Required per assembly: 1 $442.13 - + Add to cart
30	BRACKET 1 Part #: JW8-G1661-00-00 Required per assembly: 1 ~~$15.99~~ $15.45 - + Add to cart
31	GSKT., CASE Part #: JW9-G631A-00-00 Required per assembly: 1 ~~$25.98~~ $25.39 - + Add to cart
32	COVER, TRANSMISSION Part #: JW8-G6314-10-00 Required per assembly: 1 $43.23 - + Add to cart
33	STOPPER Part #: JN3-G6432-00-00 Required per assembly: 1 $7.05 - + Add to cart
34	BOLT, HEXAGON Part #: 90101-08856-00 Required per assembly: 12 $8.02 - + Add to cart
35	BEARING 1 Part #: J0K-G6164-00-00 Required per assembly: 2 $22.22 - + Add to cart
36	OIL SEAL Part #: 93109-10820-00 Required per assembly: 1 ~~$12.99~~ $12.82 - + Add to cart
37	WASHER, SPECIAL Part #: JU0-F723F-00-00 Required per assembly: 1 $11.95 - + Add to cart
38	CIRCLIP Part #: 93410-12822-00 Required per assembly: 1 $2.63 - + Add to cart
39	WASHER, PLATE Part #: 90202-12807-00 Required per assembly: 1 $4.21 - + Add to cart
40	OIL SEAL Part #: 93104-11829-00 Required per assembly: 1 $8.69 - + Add to cart
41	NIPPLE, HOSE Part #: JW8-G5378-00-00 Required per assembly: 1 $5.04 - + Add to cart
42	BOLT, HEXAGON Part #: 90101-08855-00 Required per assembly: 8 $4.30 - + Add to cart
43	NUT, HEXAGON Part #: 90170-08841-00 Required per assembly: 8 ~~$2.54~~ $2.20 - + Add to cart
44	SHAFT, REAR, AXLE, 1, (LH) Part #: JN3-G6511-00-00 Required per assembly: 1 $208.54 - + Add to cart
45	SHAFT, REAR, AXLE, 2, (RH) Part #: JN3-G6512-00-00 Required per assembly: 1 ~~$178.99~~ $169.31 - + Add to cart
46	PIN, COTTER Part #: 91490-30030-00 Required per assembly: 2 Note: Sold in multiples of 5 only $9.79 - + Add to cart
47	OIL, SEAL, S-TYPE Part #: 93101-24822-00 Required per assembly: 2 $13.67 - + Add to cart
48	CIRCLIP Part #: 93420-44805-00 Required per assembly: 4 $9.72 - + Add to cart
49	HUB, REAR, AXLE Part #: JW8-G6514-00-00 Required per assembly: 2 ~~$121.98~~ $116.39 - + Add to cart
50	BOLT, STUD Part #: JW8-G4178-00-00 Required per assembly: 8 $6.85 - + Add to cart
51	NUT Part #: JW8-G5244-00-00 Required per assembly: 2 $3.80 - + Add to cart
52	BEARING Part #: 93306-007Y0-00 Required per assembly: 2 ~~$51.99~~ $46.84 - + Add to cart
53	DIFFERENTIAL ASSEMBLY Part #: JW9-G6410-00-00 Required per assembly: 1 $214.08 - + Add to cart
54	BOLT Part #: JC1-G2544-00-00 Required per assembly: 4 $10.16 - + Add to cart
55	NUT, HEXAGON Part #: 90170-10840-00 Required per assembly: 4 $5.24 - + Add to cart
56	GEAR, PRIMARY Part #: JN3-G6355-00-00 Required per assembly: 1 ~~$671.99~~ $630.00 - + Add to cart
57	WASHER, THRUST, 2 Part #: JW8-G2536-00-00 Required per assembly: 2 $6.35 - + Add to cart
58	DRUM Part #: JW8-G6521-10-00 Required per assembly: 2 $78.02 - + Add to cart
59	COVER, HUB, DUST Part #: JW8-F5118-00-00 Required per assembly: 2 $4.40 - + Add to cart
60	PIPE 1 Part #: JW8-G2541-00-00 Required per assembly: 1 $5.63 - + Add to cart
