Transaxle replacement parts for 2022 Yamaha DRIVE2 PTV PowerTech AC IRS

OEM Parts Yamaha 2022 Yamaha DRIVE2 PTV PowerTech AC IRS Transaxle

TRANSAXLE Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	TRANSMISSION ASSEMBLY Part #: J0S-G6301-03-00 Required per assembly: 1 ~~$1,166.99~~ $1,148.81 - + Add to cart
2	BEARING Part #: 93306-007Y0-00 Required per assembly: 2 ~~$51.99~~ $46.84 - + Add to cart
3	CASE ASSEMBLY Part #: J0S-G6290-00-00 Required per assembly: 1 ~~$196.99~~ $173.85 - + Add to cart
4	COVER, TRANSMISSION Part #: J0S-G6314-00-00 Required per assembly: 1 ~~$177.99~~ $169.31 - + Add to cart
5	DIFFERENTIAL ASSY Part #: J0B-G6410-02-00 Required per assembly: 1 ~~$214.99~~ $204.10 - + Add to cart
6	GEAR, RING Part #: JW9-G6421-00-00 Required per assembly: 1 ~~$312.99~~ $308.34 - + Add to cart
7	INPUT SHAFT ASSEMBLY Part #: J0S-G6320-00-00 Required per assembly: 1 ~~$217.99~~ $188.97 - + Add to cart
8	COUNTER GEAR ASSEMBLY Part #: J0S-G6350-00-00 Required per assembly: 1 ~~$257.99~~ $252.49 - + Add to cart
9	PLUG Part #: J0S-G7339-00-00 Required per assembly: 1 ~~$41.99~~ $33.23 - + Add to cart
10	SEAL, DUST Part #: J0B-G3812-00-00 Required per assembly: 3 $12.82 - + Add to cart
11	BOLT Part #: JC1-G2544-00-00 Required per assembly: 4 $10.16 - + Add to cart
12	NUT, HEXAGON Part #: 90170-10840-00 Required per assembly: 4 $5.24 - + Add to cart
13	NIPPLE, HOSE Part #: JW8-G5378-00-00 Required per assembly: 1 $5.04 - + Add to cart
14	PIN, DOWEL Part #: J0D-E5614-00-00 Required per assembly: 2 $10.09 - + Add to cart
15	PLUG, DRAIN Part #: J0S-G5148-01-00 Required per assembly: 1 ~~$51.99~~ $48.35 - + Add to cart
16	BOLT Part #: J0S-G1148-00-00 Required per assembly: 12 $6.55 - + Add to cart
17	ELBOW Part #: J0S-F1828-00-00 Required per assembly: 1 ~~$7.49~~ $7.42 - + Add to cart
18	HOSE (L85) Part #: 90445-10056-00 Required per assembly: 1 $2.41 - + Add to cart
19	HOSE (L400) Part #: 90445-143G1-00 Required per assembly: 1 $14.36 - + Add to cart
20	CLAMP Part #: 1NS-F1338-00-00 Required per assembly: 1 $4.48 - + Add to cart
21	CLIP Part #: 90467-10846-00 Required per assembly: 1 ~~$0.75~~ $0.42 - + Add to cart
